- Page 1 Huawei OptiXstar EN8145B7Ns Quick Start for QR code Issue Date 2024-11-26 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
- Page 3 Security Declaration Vulnerability Vul. Response Process. For Huawei's regulations on product vulnerability management are subject to the details about this process, visit the following web page: https://www.huawei.com/en/psirt/vul-response-process For vulnerability information, enterprise customers can visit the following web page: https://securitybulletin.huawei.com/enterprise/en/security-advisory Issue 01 (2024-11-26)
-
Page 4: Table Of Contents
Huawei OptiXstar EN8145B7Ns Quick Start for QR code Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................4 3 Indicator Description......................7 4 Technical Specifications......................9 5 FAQs............................10 Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd. -
Page 5: Placing The Device
● When operating optical fibers, pay attention to the operation safety according to the following laser hazard level. Mounting an ONT on the Desk The figure below shows an ONT that is horizontally placed on a desk. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd. - Page 6 Using a Phillips screwdriver to remove the base of the Main FTTR before mounting it on a wall through gourd holes. Mark two positions with the same spacing as that between the two mounting holes of the ONT using a marker on a wall. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd.
- Page 7 NO TE It is recommended that the screw be about 4 mm in diameter and longer than 30 mm. The screw head should be between 6 mm and 9 mm in diameter. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd.
-
Page 8: Connecting Cables
Huawei OptiXstar EN8145B7Ns Quick Start for QR code 2 Connecting Cables Connecting Cables Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd. - Page 9 Power Connects to a power cable. 4-GE/3-GE/2- Connects to a computer, IP STB, or router. GE/1-2.5GE ● GE port supports 10/100/1000 Mbit/s auto-sensing. ● 2.5GE port supports 10/100/1000/2500 Mbit/s auto- sensing. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd.
- Page 10 Press and hold this button for more than 10 seconds to restore factory settings and restart the device. Connects to drop cables and supports XGS-PON upstream access. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd.
-
Page 11: Indicator Description
The phone is being used. The telephone service is disabled. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted. The WLAN function is disabled. Steady on WPS authentication is enabled. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd. - Page 12 ● If the red and green indicators blink slowly (once every 2 seconds) at the same time, the hardware is faulty. NO TE If the ONT is not powered on or the power switch is turned off, all indicators are off. Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd.
-
Page 13: Technical Specifications
Dimensions (H x W x D): 157 mm x 250 mm x 30 mm (excluding the base) ● Weight: About 543 g (excluding the base) ● Maximum system power consumption: 18 W Issue 01 (2024-11-26) Copyright © Huawei Technologies Co., Ltd. -
Page 14: Faqs
● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password. - Page 15 ● Change the initial password after logging in to the web page for the first time. How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 16 5 FAQs What can I do if I cannot connect to the Wi-Fi network? How to improve the Wi-Fi speed of a Huawei ONT? 1. Wi-Fi speed relies on the bandwidth provided by the ISP, so the simplest way is to upgrade to faster broadband.
- Page 17 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
