- Page 1 EchoLife EG8145V5-V2 Quick Start Issue Date 2021-12-23 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Copyright © Huawei Technologies Co., Ltd. 2021. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders.
-
Page 3: Table Of Contents
EchoLife EG8145V5-V2 Quick Start Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................4 3 Indicator Description......................6 4 Technical Specifications......................8 5 FAQs............................9 Issue 01 (2021-12-23) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
EchoLife EG8145V5-V2 Quick Start 1 Placing the Device Placing the Device NO TE ● Do not install the ONT outdoors or in an outdoor cabinet. ● The ONT can be mounted onto a wall or placed on a desk. Do not install the ONT in other modes, such as ceiling. - Page 5 EchoLife EG8145V5-V2 Quick Start 1 Placing the Device NO TE The appearance shown in this document may be different from the actual appearance of the product. The actual product prevails. Mounting an ONT onto the wall Mark two positions with the same spacing as that between the two mounting holes of the ONT using a marker on a wall.
- Page 6 EchoLife EG8145V5-V2 Quick Start 1 Placing the Device NO TE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. Issue 01 (2021-12-23) Copyright © Huawei Technologies Co., Ltd.
-
Page 7: Connecting Cables
EchoLife EG8145V5-V2 Quick Start 2 Connecting Cables Connecting Cables Issue 01 (2021-12-23) Copyright © Huawei Technologies Co., Ltd. - Page 8 EchoLife EG8145V5-V2 Quick Start 2 Connecting Cables NO TE ● The fiber connector connected to the optical port on the wall varies depending on actual conditions. ● To ensure normal use of fibers, make sure that the fiber bending radius is larger than 30...
-
Page 9: Indicator Description
EchoLife EG8145V5-V2 Quick Start 3 Indicator Description Indicator Description Indicator Status Description Power Steady on The ONT is powered on. The power supply is cut off. PON/LOS See the following table . LAN1- Steady on The Ethernet connection is in the normal state. - Page 10 EchoLife EG8145V5-V2 Quick Start 3 Indicator Description Indicator Status Description Steady on The WPS function is enabled. Blinking A Wi-Fi terminal is accessing the system. The WPS function is disabled. Status Description Status Status The ONT is prohibited by the upper-layer device or blinks abnormally.
-
Page 11: Technical Specifications
EchoLife EG8145V5-V2 Quick Start 4 Technical Specifications Technical Specifications Product Function EG8145V5-V2 ● 4 Ethernet ports ● 1 POTS port ● 1 USB port ● 2.4 GHz & 5 GHz Wi-Fi ● Power adapter input: See the nameplate on the adapter. -
Page 12: Faqs
EchoLife EG8145V5-V2 Quick Start 5 FAQs FAQs NO TE The following web page is only for reference. The actual web page of the product prevails. How do I log in to the Huawei ONT web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. - Page 13 EchoLife EG8145V5-V2 Quick Start 5 FAQs ● Wired login Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the For example, if the web address of the Huawei ONT is Huawei ONT.
- Page 14 EchoLife EG8145V5-V2 Quick Start 5 FAQs NO TE ● If you do not perform any operations after logging in to the system within five minutes, you will be logged out, and the system automatically returns to the login interface. ● The system will be locked for one minute if you input incorrect user name and password for three consecutive times.
- Page 15 EchoLife EG8145V5-V2 Quick Start 5 FAQs What can I do if I cannot connect to the Wi-Fi network? How to improve the Wi-Fi speed of a Huawei ONT? 1. Wi-Fi speed relies on the bandwidth provided by the ISP, so the simplest way is to upgrade to faster broadband.
- Page 16 EchoLife EG8145V5-V2 Quick Start 5 FAQs How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
