- Page 1 EchoLife EG8145V5 Quick Start for QR code Issue Date 2023-07-17 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
EchoLife EG8145V5 Quick Start for QR code Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................4 3 Indicator Description......................6 4 Technical Specifications......................8 5 FAQs............................9 Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
Internet cafes, studios, enterprises, or other densely populated scenarios. Mounting an ONT on the desk The figure below shows an ONT that is horizontally placed on a desk. Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd. - Page 5 Use a screwdriver to fasten the screws into the expansion bolts, reserving 5 mm ends out of the wall, and mount the ONT onto the screws. Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd.
- Page 6 NO TE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. The screw head should be between 6 mm and 9 mm in diameter. Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd.
-
Page 7: Connecting Cables
EchoLife EG8145V5 Quick Start for QR code 2 Connecting Cables Connecting Cables Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd. - Page 8 NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
-
Page 9: Indicator Description
The system is not powered on or the USB port is not connected. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted over the WLAN port. The WLAN function is disabled. Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd. - Page 10 The hardware is faulty. every 2 once seconds every 2 seconds NO TE If the ONT is not powered on or the power switch is turned off, all indicators are off. Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd.
-
Page 11: Technical Specifications
● Dimensions (H x W x D): 30 mm x 155 mm x 105 mm (without external antenna and pads) ● Weight: About 220g ● Maximum system power consumption: 12 W Issue 02 (2023-07-17) Copyright © Huawei Technologies Co., Ltd. -
Page 12: Faqs
How do I log in to the Huawei ONT web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password. - Page 13 ● Wired login Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the For example, if the web address of the Huawei ONT is Huawei ONT.
- Page 14 ● Change the initial password after logging in to the web page for the first time. How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 15 2. Wi-Fi speed is affected by the Wi-Fi signal strength and quality. Ensure that the Huawei ONT is far away from interference sources such as TVs, microwave ovens, refrigerators, cordless phones, and Bluetooth devices, and reduce the number of obstacles between the Huawei ONT and Wi-Fi devices (such as pads, mobile phones, and laptops).
- Page 16 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
