- Page 1 [ CARRIER AIR PURIFIER] USER MANUAL Please read this manual carefully, and follow the instructions strictly. Please keep this manual for future reference.
- Page 2 CONTENTS...
-
Page 3: Table Of Contents
- Q - ····· Q If Contents Security note Product Introduction Control panel Other items in the package Before use Record the beginning use date in the label Learning air quality indicator Method of dismounting and installation Placement sites of Air Purifier Install filters Filters and functions How to use... -
Page 4: Security Note
Security Note In order to avoid possible damage to you or others or financial damages, please be sure to pay attention to the following safety precautions. If the machine's power supply cord is damaged, you must call the manufacturer of the machine, maintenance service center or qualified technicians to assist you. - Page 5 Attention Attention This appliance contains a UV-C emitter. Any situation as below, please turn off Do not stare at the light source. the power of the machine. Unintended use of the appliance or damage to the housing may result in the escape of dangerous UV-C radiation.
-
Page 6: Product Introduction
Air outlet ® Handle Air quality indicator Air Quality Sensor Air inlet Back cover Power cord hole HEPA 13 filter Photoresistor Activated carbon filter + photo catalyst filter UV lamp Pre-filter Air inlet panel... -
Page 7: Control Panel
Control panel o Bh I O 5 o 4h oAUTO 00 0 o 1h oSILENT � 0 - ® ® SPEED TIMER MODE RESET ON/OFF Timing button ON/OFF button Wind speed adjustment Mode button Restoration button Other items in packing Air quality indicator Perfect Good... -
Page 8: Before Use
Record the beginning use date in the label In order to replace the filter on time, before using air purifier, please keep the date recorded in the bottom of the nameplate, thus to achieve the best performance. Tips After remo ving the plastic package of each filter, the efficient HEPA filter and activated carbon filter must be replaced once a year. -
Page 9: Method Of Dismounting And Installation
Method of dismounting and installing 2 Method of installing th e air inlet panel. 1 Method of removing the air inlet panel. Hold on the groove at both sides of the Reinstall the air inlet panel: align and air inlet panel, then gently pull it up. insert it into the fixed groove, and then gently push it towards the back of the unit to fit back in place. -
Page 10: Install Filters
Install Filter Please remove all the package of all the filters in the machine before using the air purifier, according to the below instruction. Attention • Please make sure the power plug have been put off before installation, maintenance and transportation. -
Page 12: Filters And Functions
Filters and function 4-points purification system, could effectively purify the air, make life more healthy. One: Pre-filter Use micron mesh filter, effectively block 2.5mm fibrous particulate matter, Blocking rate > 99.9%.lt can be cleaned easily by tens of thousands times. Preventing larger particles such as pet fur, d ander and coarse dust, etc. - Page 13 . . . • 0 • • • • ·' · Bacteria • • Yeast Mycotic spore Virus Mildew Mould Bacteria The allergens ;;rJ� Coarse dust Hair Harmful particles Dander Dust Pollen Pet fur Smoke � � Dust mites Odor Chemical substances USER MANUAL...
-
Page 14: How To Use
Control panel AUTO SILENT SPEED TIMER MODE RESET ON/OFF Starting air purifier Plug in the power .. ,, " AUTO SILENT SPEED TIMER MODE RESET Press the power switch to enter into auto mode with the lights on. When the machine start,the air quality indicator light will be slow flashing on,it begins to detect the air quality after preheating for 15 S. -
Page 16: Uv Function
5 Cleaning And UV function(Negative ion function) Maintenance Be sure to pull out plug before cleaning. i � AUTO Do not put the product into water or any SLENT ® other liquid. Do not use corrosive or flammable gas(e.g. bleach or alcohol)to clean any part of the product. -
Page 18: Operation Steps
Operation steps 1.Turn off the power to stop the air 4.Remove the handle of the filter purifier. before cleaning it AUTO SILENT SPEED TIMER MODE RESET 5.Use a soft brush or a vacuum cleaner 2.Pull out the power plug. to remove particles. please use water or soap water to clean the filter. -
Page 19: Replace Filters
Replace filters ?.Re-install the air inlet panel, align and Information insert into the fixed groove, then gently pushed it up. • AUTO SILENT SPEED TIMER MODE RESET ON/OFF 8.Plug in. A reminding of filter replacement comes when machine in normal working for more than 1600 hours.and the power lights flash slowly ( the red lights flashing,when standby, the blue lights flashing when it is... -
Page 20: Operation
Operation 1.Reminding to replace the filter. 4.Take off all filters inside. AUTO SILENT SPEED TIMER MODE ON/OFF � Flashing 2. Turn off the power, then pull out the 5.Remove all the plastic package of the power plug. filters , put back into the purifier. @ @ @ 3.Hold on the grooves of both side of the 6.Put back the pre-filter into the purifier. -
Page 21: Time For Filters Replacement
Unused for a long time Pull out the power plug.(because the ?.Re-install the air inlet panel , align and power consumption happened when it is insert into the fixed groove, then gently standby.) pushed it up. Thoroughly dry the inside.(otherwise it may lead to the equipment trouble.) Store the machine in a dry ventilated place.(lay flat or place upsight down may... -
Page 22: Fault Handling
Fault Handling This chapter list the possible problems when using this product. If you can't solve the problems based on the below information, please contact our customer center or dealers. condition possible reasons possible solutions Remove the front panel, then install the panel The front panel may not be installed. -
Page 23: Warranty And Service
Additional Ordering parts or accessories If you need to replace parts or need to purchase additional parts, please contact recycling your customer service center or dealer. Place the product, please don't put together with the general life garbage. Please check the local regulations on classified collection of electronic and electrical products. - Page 24 This manual provides certain general information and is intended for guidance only and Carrier is not liable for any damage arising out of the use of the manual. The manufacturer reserves the right to change any product specification without prior notice.
