- Page 1 KGV7539IK User Manual...
-
Page 2: Table Of Contents
10. ENVIRONMENTAL CONCERNS..............26 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Children And Vulnerable People Safety
ENGLISH instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance is not intended for use by persons • (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 4 Never use water to extinguish the cooking fire. Switch • off the appliance and cover flames with e.g. a fire blanket or lid. WARNING: The appliance must not be supplied • through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
-
Page 5: Safety Instructions
ENGLISH overvoltage category III must be guaranteed. The earth cable is excluded from this. When you route the mains cable, make sure that the • cable doesn't come into direct contact (for example using insulating sleeving) with parts that can reach temperatures of more than 50°C above room temperature. -
Page 6: Gas Connection
• Do not let the electricity mains cable adjustment of the appliance are tangle. compatible. • Make sure that a shock protection is • Make sure that there is air circulation installed. around the appliance. • Use the strain relief clamp on the •... - Page 7 ENGLISH • Do not put cutlery or saucepan lids on • Use only the accessories supplied the cooking zones. They can become with the appliance. hot. • Do not install a flame diffuser on the • Do not operate the appliance with wet burner.
-
Page 8: Installation
• Flat the external gas pipes. your local solid waste operator. • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to the appliance and dispose of 3. INSTALLATION... -
Page 9: Injectors Replacement
ENGLISH • the material is not hardened, but You can find this label in the package shows its correct elasticity; supplied with the appliance. • the fastening clamps are not rusted; If the supply gas pressure is changeable • expired term is not due. or different from the necessary pressure, If one or more defects are visible, do not you must fit an applicable pressure... -
Page 10: Electrical Connection
8. Check it the minimum level is correct and touch To confirm the minimum level. If the minimum level is incorrect, repeat the steps 6 and 7. 9. Touch to select the next burner and repeat the steps 5-8. - Page 11 ENGLISH 3.8 Assembly min. 650mm min. 150mm min. 38 mm min. 2 mm 1) Unless otherwise specified in the oven installation. < 20 mm 12 mm 45 mm 28 mm 29 mm 38 mm 19 mm...
- Page 12 3.10 Possibilities for insertion The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance intervention is necessary. Kitchen unit with door min 6 mm min 5 mm 60 mm A.
-
Page 13: Product Description
ENGLISH 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Multi Crown burner Auxiliary burner Control panel 4.2 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sen‐ Function Comment field ON / OFF... -
Page 14: Heat Setting Displays
Sen‐ Function Comment field Reset the hob To reset the hob (Refer to "Troubleshoot‐ ing"). Reset led indicator To show activated function. Reset proce‐ dure required. To activate and deactivate the Timer. To increase or decrease the time. Area for Hob²Hood infra‐... -
Page 15: Daily Use
ENGLISH 5. DAILY USE WARNING! WARNING! Refer to Safety chapters. Be very careful when you use open fire in the kitchen environment. The 5.1 Burner overview manufacturer declines any responsibility in case of the flame misuse. 1. Touch for 1 second to activate the hob. -
Page 16: Turning The Burner Off
5.3 Turning the burner off To unlock the control panel, touch again. To put the flame out, touch the control You can turn the burners off bar to the off position while the control panel is WARNING! locked. Use... -
Page 17: Minute Minder
ENGLISH 5.7 Minute Minder Hob²Hood You can use this function as a Minute It is an advanced automatic function Minder when the hob is activated. which connects the hob to a special hood. Both the hob and the hood have 1. -
Page 18: Hints And Tips
4. Touch a few times until comes WARNING! After end of cooking, the hood does not turn off 5. Touch of the Timer to select an automatically. Turn it off automatic mode. manually. Touch to set the speed manually. -
Page 19: Examples Of Cooking Applications
Heat to boiling function To find the full range of cooker hoods which work with this function refer to our Simmering consumer website. The Electrolux cooker hoods that work with this function must Blending, melting in‐ have the symbol gredients 6.5 Examples of cooking... -
Page 20: Care And Cleaning
Bur‐ gers Bur‐ gers Bur‐ gers Fries 20-30 Be‐ cha‐ 5-10 5-10 Rice por‐ 10-20 30-40 ridg 1) Stirring continuously 2) Without lid 7. CARE AND CLEANING WARNING! WARNING! Refer to Safety chapters. Do not use knives, scrapers or similar instruments to clean the surface of the 7.1 General information... -
Page 21: Removing Pan Supports
ENGLISH hand and dry them. If necessary, remove stubborn stains with a paste cleaner. 3. After you clean the pan supports, make sure that they are in correct positions. 4. For the burner to operate correctly, make sure that the arms of the pan supports are aligned with the centre of the burner. -
Page 22: Periodic Maintenance
7.6 Periodic maintenance conditions of the gas supply pipe and the pressure adjuster, if fitted. Speak to your local Authorised Service Centre periodically to check the 8. TROUBLESHOOTING WARNING! Refer to Safety chapters. 8.1 What to do if... Problem... - Page 23 ENGLISH Problem Possible cause Remedy There is no sound when The sounds are deactiva‐ Activate the sounds. Refer you touch the panel sensor ted. to "Daily use". fields. You can hear sparking for Air currents around the Make sure that air currents a few seconds after the burner.
- Page 24 Problem Possible cause Remedy Too many attempts to clear Wait for 15 minutes. comes on. Follow the same procedure the warning as if warning appeared. If the problem persist, con‐ tact an Authorised Service Centre. There is an error in the Contact an Authorised come on.
-
Page 25: Labels Supplied With The Accessories Bag
ENGLISH 8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send C. -
Page 26: Environmental Concerns
Appliance class: 9.3 Gas burners for NATURAL GAS G20 20 mbar BURNER NORMAL POWER MINIMUM POWER INJECTOR MARK Multi Crown 1,75 Semi-rapid Auxiliary 0,38 9.4 Gas burners for NATURAL GAS G20 13 mbar BURNER NORMAL POWER MINIMUM POWER INJECTOR MARK... - Page 28 www.electrolux.com/shop...
