- Page 1 EN User Manual | Hob KGV8473IK...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................13 5. DAILY USE....................15 6. -
Page 3: General Safety
• Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated. - Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the glass ceramic surface / glass surface is cracked, switch off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply.
-
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS • Before carrying out any operation make This appliance is suitable for the following sure that the appliance is disconnected markets: UA from the power supply. • Make sure that the parameters on the 2.1 Installation rating plate are compatible with the electrical ratings of the mains power supply. -
Page 6: Gas Connection
2.3 Gas connection • Make sure that the ventilation openings are not blocked. • Do not let the appliance stay unattended CAUTION! during operation. When using a gas cylinder, always keep • Set the cooking zone to “off” after each it on a flat horizontal surface (with the use. -
Page 7: Installation
• Do not use large cookware that overlap • Concerning the lamp(s) inside this product the edges of the appliance. This can and spare part lamps sold separately: cause damage to the worktop surface. These lamps are intended to withstand •... -
Page 8: Injectors Replacement
3.3 Injectors replacement Make sure that the gas supply pressure WARNING! of the appliance obeys the recommended Information for authorised installer only. values. The adjustable connection is fixed to the comprehensive ramp by 1. Remove the pan supports. means of a threaded nut G 1/2". Screw 2. -
Page 9: Adjustment Of Minimum Level
Gas selection G20 20 mbar Liquid gas 29 mbar G20 13 mbar 3.5 Adjustment of minimum level WARNING! Make sure the flame does not go out WARNING! when you move quickly from the Information for authorised installer only. maximum to the minimum heat setting position. - Page 10 1. Connect the green and yellow (earth) wire to the terminal which is marked with the letter 'E', or the earth symbol , or coloured green and yellow. 2. Connect the blue (neutral) wire to the terminal which is marked with the letter 'N' or coloured blue.
- Page 11 min. 38 mm min. 2 mm 1) Unless otherwise specified in the oven installation. CAUTION! Install the appliance only on a worktop with flat surface. ENGLISH...
- Page 12 INTEGRATED INSTALLATION min. 38 mm min. 2 mm min. 38 mm min. 2 mm 14,5 CAUTION! Install the appliance only on a worktop with flat surface. ENGLISH...
-
Page 13: Possibilities For Insertion
3.9 Installing hob under the hood A. Removable panel (optional) B. Space for connections Kitchen unit with oven If you install the hob under a hood, check The electrical connection of the hob and the the hood installation instructions for the oven must be installed separately for safety minimum distance between the reasons and to allow for easy removal of the... -
Page 14: Control Panel Layout
4.2 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function. -
Page 15: Hot Surface Indicator
4.4 Hot Surface Indicator WARNING! If the cooking zone becomes hot during cooking, the setting indicator shows a Hot Surface warning when the zone is turned off. The Hot Surface Indicator shows until the cooking zone cools, the hob is unplugged or there is a power cut. -
Page 16: Menu Structure
• you spill something or put something on the control panel for more than 10 seconds (a pan, a cloth, etc.). An acoustic If the warning appears, turn off and signal sounds and the hob deactivates. turn on again the hob. When the display Remove the object or clean the control function reappears, after light... -
Page 17: Offsound Control (Deactivating And Activating The Sounds)
To activate the function: press . Do not OffSound Control (Deactivating and activating the sounds) set any heat setting. Press and hold for 3 seconds, until the indicator above the symbol appears. Deactivate the hob with Sounds are activated by default. You can activate / deactivate the slider The function stays active when you sounds in the hob menu. -
Page 18: Minute Minder
recognizes temperature of the cookware Minute Minder automatically and adjusts the speed of the fan. You can use this function when the hob is activated but the cooking zones do not Automatic modes operate. The heat setting shows 00. Mode Mode de‐... -
Page 19: Hints And Tips
To activate automatic operation of the The light on the hood deactivates 2 function, deactivate the hob and activate minutes after deactivating the hob. it again. Activating the light You can set the hob to activate the light automatically whenever you activate the hob. To do so set the automatic mode to H1 –... -
Page 20: Suggested Recipes
Cooker hoods with the Hob²Hood function To find the full range of cooker hoods which work with this function refer to our consumer website. The Electrolux cooker hoods that work with this function must have the symbol Keep the window for Hob²Hood infrared signal communicator clean. -
Page 21: Care And Cleaning
Food categories Recipes Burner type Heat up phase Cooking phase power level power level 1) Mushrooms with sea‐ Medium sonings Caponata with vegeta‐ Large bles Vegetables Boiled potatoes Medium Frozen spinach with Large butter French fries Large Fried dishes Donuts Large Roasting nuts Large... -
Page 22: Pan Supports
WARNING! Do not use knives, scrapers or similar instruments to clean the surface of the glass or the rims of the burners and the frame (if applicable). You can wash the burner crown in a dishwasher. CAUTION! Do not clean the burner crown with abrasive products, abrasive cleaning pads, solvents or metal objects. -
Page 23: Troubleshooting
Heavy stains: cloth or sponge to prevent difficult lightning or Clean the flame spreader with warm water difficult flame recognition. Check if the burner and soap, then wash it in the dishwasher. If crown is not blocked with food residues. the stain is still present wash the top of the 7.7 Periodic maintenance flame spreader with a grill cleaner and run... - Page 24 Problem Possible cause Remedy You put something on the sensor Remove the object from the sensor The hob deactivates. field. field Refer to "Control panel layout" (as if The reset procedure required. The reset led indicator blinks. warning appears). Remove the object from the control Hob²Hood function does not work.
- Page 25 Problem Possible cause Remedy Follow the same procedure as if warning appeared. Temporary condition of failure. comes on. If the problem persist, contact an Authorised Service Centre. Wait for 15 minutes. Follow the same procedure as if Too many attempts to clear the comes on.
-
Page 26: Labels Supplied With The Accessories Bag
8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this C. -
Page 27: Energy Efficiency
Auxiliary Installation kit to be ordered from Authorised Service Centre. 10. ENERGY EFFICIENCY 10.1 Product Information according to EU Ecodesign regulation Model identification KGV8473IK Type of hob Built-in hob Number of gas burners Left - Ultra Rapid 58.0% Middle - Semi-rapid 58.7%... -
Page 28: Energy Saving
EN 30-2-1: Domestic cooking appliances burning gas - Part 2-1 : Rational use of energy - General 10.2 Energy saving • If it is possible, always put the lids on the cookware. • Before use, make sure that the burners •... - Page 32 867374321-B-202024...
