Model No. PFEX92320.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.proform.com.
CUSTOMER CARE
For service at any time, go to
support.proform.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-FORM 505 SPX and is the answer not in the manual?

Questions and answers

Mike
July 1, 2025

Resistance knob set to minimum, but to much resistance still exists

Subscribe to Our Youtube Channel

Summary of Contents for ICON Health & Fitness PRO-FORM 505 SPX

  • Page 1 proform.com Model No. PFEX92320.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.proform.com. CUSTOMER CARE For service at any time, go to support.proform.com.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 STANDARD SERVICE PLANS...
  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM 505 SPX reading this manual, please see the front cover of this ® exercise bike. Cycling is an effective exercise for manual. To help us assist you, note the product model increasing cardiovascular fitness, building endurance, number and serial number before contacting us.
  • Page 6: Assembly

    ASSEMBLY • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tool(s): one adjustable wrench • Assembly requires two persons. one rubber mallet • Place all parts in a cleared area and remove the packing materials.
  • Page 7 3. Attach the Rear Stabilizer (5) to the Frame (1) with two M8 x 55mm Carriage Bolts (9), two M8 Washers (3), and two M8 Flange Nuts (2). 4. Orient the Saddle (31) as shown. Slide the Saddle (31) onto the Saddle Carriage (32);...
  • Page 8 5. Orient the Handlebar (7) as shown. Locate the Adjustment Knob (15) on the front of the Frame (1). Loosen the Adjustment Knob and pull it outward. Then, insert the Handlebar (7) into the Frame. Move the Handlebar (7) upward or downward to the desired position, release the Adjustment Knob (15) into an adjustment hole in the Handlebar, and then tighten the Adjustment...
  • Page 9 7. The Console (58) can use two AAA batteries (not included); alkaline batteries are recommended. Do not use old and new batteries together or alkaline, standard, and rechargeable batter- ies together. IMPORTANT: If the Console has been exposed to cold temperatures, allow it to warm to room temperature before you insert batteries.
  • Page 10 9. Hold the wire (C) on the Reed Switch (59) on the left side of the exercise bike as shown. Connect the wire (C) on the Reed Switch (59) to the wire on the Console (58). 10. Insert the wire (C) on the Reed Switch (59) into the Clip (64) on the left side of the Frame (1).
  • Page 11: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO ADJUST THE ANGLE OF THE SADDLE HOW TO ADJUST THE SADDLE POST You can adjust the angle of the saddle to the position For effective exercise, the saddle should be at the that is most comfortable.
  • Page 12 HOW TO ADJUST THE PEDALING RESISTANCE To clean the exercise bike, use a damp cloth and a small amount of mild detergent. IMPORTANT: To To increase the avoid damage to the console, keep liquids away from the console and keep the console out of resistance of the direct sunlight.
  • Page 13 FEATURES OF THE CONSOLE 2. Set a workout goal if desired. The easy-to-use console features six modes that To set a time, distance, or calorie-burning goal for provide instant exercise feedback during your your workout, press the Mode button repeatedly workouts.
  • Page 14: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 15: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 16 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 17 NOTES...
  • Page 18: Part List

    PART LIST Model No. PFEX92320.0 R1019A Key No. Qty. Description Key No. Qty. Description Frame #10 x 12mm Screw M8 Flange Nut Outer Guard M8 Washer Drive Belt Front Stabilizer Drive Belt Guard Cover Rear Stabilizer Inner Guard Saddle Post #12 x 15mm Screw Handlebar Brake Bracket Pad...
  • Page 19: Exploded Drawing

    EXPLODED DRAWING Model No. PFEX92320.0 R1019A...
  • Page 20: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
