Instructions - Parts List
APEX
Oil Transfer Pump
For pumping non-flammable fluids including motor oils, hydraulic
fluid, and antifreeze. Do not use to pump water.
Model 260105, 3.0 gpm (11 lpm), 115 VAC (wall mount)
Model 260106, 3.0 gpm (11 lpm), 115 VAC
Model 260108, 4.2 gpm (16 lpm), 115 VAC
Model 260109, 7.9 gpm (30 lpm), 115 VAC
Model 260240, 6.3 gpm (24 lpm), 12 VDC (reversible)
150 psi (1.03 MPa, 10.3 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Pump on Barrel or Tank . . . . . . . . . . . . . . . . 4
Mounting Pump In-line . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical Installation
12 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Performance Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
311306E
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 260106
Summary of Contents for Graco 260106
-
Page 1: Table Of Contents
Notes ......... 13 Graco Standard Warranty ......14 Graco Information . -
Page 2: Warnings
All manuals and user guides at all-guides.com Warnings Warnings The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Additional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appearing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard. - Page 3 Graco replacement parts only. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your Graco distributor for informa- tion. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
-
Page 4: Installation
Models 260106, 260108, and 260109 5. Insert the suction tube through the bung include a bung adapter for mounting on any adapter into the tank, and lower the pump standard 2 inch barrel or tank bung. -
Page 5: Electrical Installation
115 VAC single phase, requiring a 3-wire tinuously in 1 hour. grounded electrical service. Follow these instructions for operation of the 260105, 260106, 260108, 260109, and Electrical Installation 260240 oil transfer pumps. See Parts, page 8 12 VDC for reference. -
Page 6: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting Troubleshooting Problem Cause Solution Motor runs but pump will not Dirt under pressure relief valve Remove pressure relief valve prime. or seal. and inspect, clean, or replace if damaged. Worn or damaged gears. Remove cover and inspect gears. - Page 7 All manuals and user guides at all-guides.com Troubleshooting Problem Cause Solution Unit pumps but output flow is Clogged inlet strainer (12). Clean or replace. low. Air leak in suction tube. Check to make sure all joints in suction tube are sealed. Suction tube too close to tank Suction tube must have a 2 in.
-
Page 8: Parts
All manuals and user guides at all-guides.com Parts Parts Models 260105, 260106, 260108, 260109 Ref. No. Description Qty. Ref. No. Description Qty. SCREW, cap, 5/16-18 x 1 in. PUMP BODY, with swivel SCREW, cap, 5/16-18 x 1.5 in. PUMP BODY, without swivel... - Page 9 1c, 2, 3b, 4, 7, 8, 9, 10, 14, 15 (models 260108, 260109, 260240) 260248 KIT, motor, 115 VAC 3/4 HP 5a, 6, 12 (models 260105, 260106, 260108) 260249 KIT, motor, 115 VAC 1 HP 5b, 6, 12 (model 260109)
-
Page 10: Technical Data
Dimensions See page 11 Power cord 30 in. (762 mm), 3 prong grounded (AC models only) Horsepower Model 260105, 260106, 260108, 260240: 3/4 hp Model 260109: 1 hp Max current Model 260105, 7.5 amps Model 260106, 7.5 amps Model 260108: 9.0 amps Model 260109: 11.0 amps... -
Page 11: Dimensions
All manuals and user guides at all-guides.com Technical Data Dimensions Length (A) Height (B) Width (C) Models Inches Inches Inches 260105 330.2 203.2 7.75 196.8 260106 330.2 203.2 7.75 196.8 260108 330.2 203.2 7.75 196.8 260109 330.2 203.2 6.25 158.7 260240 330.2... -
Page 12: Performance Chart
All manuals and user guides at all-guides.com Technical Data Performance Chart 311306E... -
Page 13: Notes
All manuals and user guides at all-guides.com Notes Notes 311306E... -
Page 14: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
