Multitech MultiModem ZDX Series User Manual page 7

Cables
Diagnostics
Speaker
Speaker and Microphone Jacks MultiModemZDXV
Manual Controls
Environmental
Storage Temperature
Power Consumption
Dimensions
Weight
Operating Systems
Warranty
Multi-Tech Systems, Inc. MT5656ZDX User Guide
Downloaded from Elcodis.com electronic components distributor
One modular telephone cable
Local analog loop, local digital loop, remote digital loop
Speaker for call progress monitoring
Power switch
Temperature range 0°–50°C (32°–120°F); humidity range 20–90%
(non-condensing)
-10° to +85°C (14°- 185° F)
150 mA @ 9 VDC
10.8 cm wide x 14.8 cm long x 2.9 high (4.25" × 5.8" x 1.15")
224 g (8 oz)
Tested for use with Windows 2000+ and Linux (2.2.x kernal)
2 years
Chapter 2 – Hardware Installation
7
