Vetus WC12S2 Installation And User Manual
Vetus WC12S2 Installation And User Manual

Vetus WC12S2 Installation And User Manual

Electric marine toilets
Table of Contents

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 8

Quick Links

Installatie- en gebruikershandleiding
Elektrische scheepstoiletten
Installation and user manual
Electric marine toilets
Installations- und Benutzerhandbuch
Elektrische Bordtoilete
Installation and user manual
WC12S2 - WC24S2 - WC110S - WC220S
Electric marine toilet
Copyright © 2025 VETUS B.V. Schiedam Holland
NEDERLANDS
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
Manuel d'Installation et d'utilisation
Toilettes de bord électriques
Manual de instalación y usuario
Inodoros marinos eléctricos
Manuale d'installazione e d'uso
Toilets marine elettriche
4
8
12
16
20
24
110123.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WC12S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vetus WC12S2

  • Page 1 Electric marine toilets Inodoros marinos eléctricos Installations- und Benutzerhandbuch Manuale d'installazione e d'uso Elektrische Bordtoilete Toilets marine elettriche Installation and user manual Electric marine toilet WC12S2 - WC24S2 - WC110S - WC220S Copyright © 2025 VETUS B.V. Schiedam Holland 110123.02...
  • Page 2: Table Of Contents

    Inhoud Content Inhalt Veiligheid Safety Sicherheitsbestimmungen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
  • Page 3 Sommaire Índice Indice Sécurité Seguridad Sicurezza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
  • Page 4: Veiligheid

    NEDERLANDS Veiligheid Inleiding De VETUS toiletten WC..S(2) zijn toiletten met een geïntegreerd ver- Waarschuwingsaanduidingen maalsysteem. Bij correcte installatie en gebruik functioneren deze Indien van toepassing worden in deze handleiding in verband met toiletten als een normaal toilet. veiligheid de volgende waarschuwingsaanduidingen gebruikt:...
  • Page 5: Aansluitingen 12 V / 24 V

    1,5 bar zijn; dit is de mini- male druk om een optimale spoeling te verkrijgen. - Gebruik als afvoerleiding slang ø 19 mm (bijvoorbeeld ‘VETUS geurdichte vuilwaterslang’ ø 19 mm). Wanneer de druk van het waterdruksysteem minder dan 1,5 bar is, of...
  • Page 6: Elektrische Installatie

    120 / 230 V systeem 3 .7 Elektrische installatie Er kan, met behulp van de dub- bele drukknop op de toiletpot, 3 .7 .1 12 V / 24 V systeem een korte of een lange spoeling worden uitgevoerd. • Controleer of de spanning, vermeld op het typeplaatje van de mo- tor, overeenkomt met de boordspanning.
  • Page 7: Technische Gegevens

    NEDERLANDS Technische gegevens • 12 V / 24 V - Pomp het toilet leeg door op de toets met het pomp- symbool te drukken en deze ingedrukt te houden. • 120 V / 230 V - Voer een cyclus uit zonder water. Spanning : 12 / 24 / 120 / 230 V Stroom...
  • Page 8: Safety

    ENGLISH Safety Introduction The VETUS WC..S(2) toilets are marine toilets with an integrated Warning indications pump system. With correct installation and operation, these toilets Where applicable, the following warning indications are used in this function like a normal toilet. manual in connection with safety:...
  • Page 9: Connections 12 V / 24 V

    3. Mount the drain hose (ø 19 • Fit the outlet pipe (E) (19 mm. internal diameter (1”)) to the reduc- mm) and secure it with hose tion piece using the hose clamp supplied. Use VETUS odour-free clamp (H). waste water pipe as outlet pipe.
  • Page 10: Electrical Installation

    3 .7 Electrical installation 120 / 230 V system A short or long flush can be per- formed, using the double push- 3 .7 .1 12 V / 24 V system button on the toilet bowl. • Check that the voltage given on the type plate on the motor is the same as the voltage on board.
  • Page 11: Technical Data

    ENGLISH Technical data • 12 V / 24 V - Pump the toilet empty by pressing and holding the button with the pump symbol. • 120 V / 230 V - Perform a cycle without water. Voltage : 12 / 24 / 120 / 230 V Current : 25 / 15 / 9 / 2,8 A •...
  • Page 12: Sicherheitsbestimmungen

    DEUTSCH Sicherheitsbestimmungen Einführung Bei den VETUS-Toiletten des Typs WC..S(2) handelt es sich um Toilet- Gefahrenhinweise ten mit einem integrierten Zermahlungssystem. Bei korrektem Ein- In dieser Anleitung werden, soweit zutreffend, die folgenden Warn- bau und Gebrauch funktionieren diese Toiletten wie eine reguläre hinweise im Zusammenhang mit der Sicherheit verwendet: Toilette.
  • Page 13: Anschlüsse 12 V / 24 V

    Der Wasserdruck eines solchen Systems hat allerdings minimal 1,5 - Als Abflussleitung einen ø 19 mm Schlauch benutzen (zum Bei- bar zu betragen. Ohne diesen Mindestdruck ist keine optimale Spü- spiel den geruchsfreien VETUS-Abwasserschlauch ø 19 mm). lung möglich. - Die Abflussleitung an einen Abwassertank oder eine Schiffs- wanddurchführung mit Absperrventil anschließen.
  • Page 14: Elektrische Installation

    3 .7 Elektrische Installation 120 V / 230 V-Netz Mit der Doppeltaste auf der To- ilettenschüssel kann eine kurze 3 .7 .1 12 V / 24 V System oder lange Spülung durchge- • Überprüfen, ob die auf der Typenplatte des Motors angegebene führt werden.
  • Page 15: Technische Daten

    DEUTSCH • Die Wasserversorgung abdrehen (Kugelhahn schließen) Falls mit Meerwasser gespült werden soll, muss dennoch ab und zu mit Süßwasser gespült werden, damit sich kein Salz ablagern kann. • 12 V / 24 V - Pumpen Sie die Toilette leer, indem Sie die Taste mit dem Pumpensymbol drücken und gedrückt halten.
  • Page 16: Sécurité

    FRANÇAIS Sécurité Introduction Les toilettes VETUS WC..S(2) comportent un système de broyage Messages d’avertissement intégré. Lors d’une installation et d’un emploi corrects, ces toilettes Dans ce manuel, les indications d’avertissement suivantes sont utili- fonctionnent comme les toilettes habituelles. sées au besoin en rapport avec la sécurité :...
  • Page 17: Raccordements 12 V / 24 V

    - Comme conduite d’évacuation prendre un tuyau de ø 19 mm optimal des toilettes. (par exemple le ‘tuyau anti-odeurs pour eaux usées de VETUS’ ø 19 mm). Si la pression du système est inférieure à 1,5 bar, ou si l’on utilise de l’eau de mer pour le rinçage, installer une pompe d’alimentation...
  • Page 18: Installation Électrique

    3 .7 Installation électrique Système à 120 V / 230 V Une chasse d'eau courte ou longue peut être effectuée à 3 .7 .1 Système 12 V / 24 V l'aide du double bouton-pous- soir situé sur la cuvette. • Contrôler que la tension indiquée sur la plaque signalétique du moteur correspond à...
  • Page 19: Renseignements Techniques

    FRANÇAIS • Fermer l’arrivée d’eau (fermer le robinet à boule). Si l’on utilise de l’eau de mer pour rincer, utiliser de temps en temps de l’eau douce pour éviter la formation de dépôts de sel. • 12 V / 24 V - Videz la toilette en appuyant sur le bouton portant le symbole de la pompe et en le maintenant enfoncé.
  • Page 20: Seguridad

    ESPAÑOL Seguridad Introducción Los inodoros VETUS WC..S(2) son inodoros con un sistema pulveriza- Indicadores de advertencias dor incorporado. A condición de una instalación y un uso correctos, Cuando corresponda, se utilizan las siguientes indicaciones de ad- estos inodoros funcionan como un inodoro normal y corriente.
  • Page 21: Conexiones 12 V / 24 V

    (ø 19 mm) y fíjela con la de manguera suministrada en el accesorio reductor. Aplique como abrazadera de la manguera tubo de desagüe la manguera para aguas sucias inodoro de VETUS. (H). • Preste atención a no doblar la manguera de desagüe (B).
  • Page 22: Instalación Eléctrica

    3 .7 Instalación eléctrica Sistema de 120 V / 230 V Se puede realizar un lavado cor- to o largo, utilizando el doble 3 .7 .1 Sistema 12 V / 24 V botón en el inodoro. • Asegure que la tensión, indicada en la placa del motor, sea igual a la tensión a bordo.
  • Page 23: Especificaciones Técnicas

    ESPAÑOL ESPAÑOL • Interrumpa la alimentación de agua (cierre completamente el ta- Si se emplea agua del mar para vaciar el inodoro, de vez en cuando se pón esférico). ha de vaciar con agua dulce para evitar sedimentos de sal. •...
  • Page 24: Sicurezza

    ITALIANO Sicurezza Introduzione Le toilette VETUS WC..S(2) dispongono di un sistema di smaltimento Indicazioni di avvertimento incorporato. Con una installazione ed un uso coretto, queste toilette Ove applicabile, in questo manuale vengono utilizzate le seguenti funzionano come una toilette normale.
  • Page 25: Allacciamenti 12 V / 24 V

    Usare come condotto di scarico scetta stringitubo (H). il tubo antiodore VETUS per lo scarico di acqua sporca. 4. Il connettore del tubo può • Assicurarsi che il tubo di scarico (B) non presenti strozzature.
  • Page 26: Empianto Elettrico

    3 .7 Empianto elettrico Impianto da 120 V o 230 V Uno scarico corto o lungo può essere eseguito utilizzando il 3 .7 .1 Sistema 12 V / 24 V doppio pulsante presente sulla vaschetta del water. • Controllare che la tensione, indicata sulla targhetta identificativa del motore, corrisponda alla tensione di bordo.
  • Page 27: Dati Tecnici

    ITALIANO Dati tecnici • 12 V / 24 V - Svuotare la toilette premendo e tenendo premuto il pulsante con il simbolo della pompa. • 120 V / 230 V - Eseguire un ciclo senza acqua. Tensione : 12 / 24 / 120 / 230 V Corrente : 25 / 15 / 9 / 2,8 A •...
  • Page 28: Installatievoorbeeld

    Installatievoorbeelden Einbaubeispiele Ejemplos de instalación Installation examples Exemples d’installation Esempi di installazione Watertoevoer Water supply Wasserzufuhr Amenée d’eau Alimentación de agua Mandata d’acqua MIN. 50 cm Afvoer Outlet Ablass Écoulement Desagüe Scarico Pomp Pump Pumpe Pompe Bomba Pompa Filter Filter Filter Filtre Filtro...
  • Page 29: Aansluitschema's

    Aansluitschema Schaltplan Esquema de conexiones Wiring Diagram Schéma de câblage Schema di collegamento 12 V 30 A @ 12 V 20 A @ 24 V 24 V 'medium time lag' Rood Zwart Black Schwarz Rouge Noir 12 V Rojo Negro 24 V Rosso Nero...
  • Page 30: Hoofdafmetingen

    Hauptabmessungen Dimensiones principales 10 Hoofdafmetingen Dimensions principales Dimensioni principali Principal dimensions 72 (2 ”) 430 (16 ”) 460 (18 ”) 51 (2”) 390 (15 ”) 400 (15 ”) 250 (9 ”) ø 4,5 ( ”) (4x) Installation and user manual WC_S(2) electric marine toilet 110123.01...
  • Page 31 Installation and user manual WC_S(2) electric marine toilet 110123.01...
  • Page 32 Havenstraat 11 - 3115 HC Schiedam - The Netherlands Tel.: +31 (0)88 4884700 - sales@vetus.com - www.vetus.com Printed in the Netherlands 110123.02 2025-03...

This manual is also suitable for:

Wc24s2Wc110sWc220s
