Liko UltraSling Mod. 06
Instructions for Use
Intended Use:
UltraSling is intended for lifting and transfer of heavy patients
in a seated position. UltraSling is used in combination with a
Liko lift System
It is intended for use in following environments: Health care,
Intensive care, Emergency ward, Rehabilitation, Habilitation and
Home healthcare environment.
Lifting extremely heavy patients demands specially developed
assistive devices and methods. Liko has developed the Ultra
product series to enable caregivers to lift heavy patients both
safely and comfortably.
In this document, the person being lifted is referred to as the patient and the person helping is referred to as the caregiver.
IMPORTANT!
Lifting and transferring a patient always involves a certain level of risk. Read the instructions for use for both the patient
lift and lifting accessories before use. It is important to completely understand the contents of the instructions for use.
The equipment should only be used by a trained caregiver. To be trained, a caregiver needs to read and understand this
Instructions for Use. Ensure that the lifting accessories are suitable for the lift used. Exercise care and caution during use.
As a caregiver, you are always responsible for the patient's safety. You must be aware of the patient's ability to make it
through the lifting situation. If something is unclear, contact the manufacturer or supplier.
7EN160121 Rev. 6
ENGLISH 2024
Product Description
UltraSling supports the entire back up to the shoulders. Its
design allows each leg support to be connected to the sling
bar individually. This allows more room for the stomach, and
optimal support for the legs.
We recommend that at least two caregivers assist during the
transfer.
Suitable lifts:
UltraSling is used with the Liko UltraTwin lift system. Depending
on which accessories are used, the system will lift a maximum
load of 500 kg (1100 lbs.). The UltraTwin system is available for
permanent installation and for freestanding installation, e.g.,
on Liko FreeSpan system.
Advertisement
Related Manuals for Hill-Rom Liko UltraSling 06
Summary of Contents for Hill-Rom Liko UltraSling 06
- Page 1 Liko UltraSling Mod. 06 Instructions for Use Product Description Intended Use: UltraSling supports the entire back up to the shoulders. Its design allows each leg support to be connected to the sling UltraSling is intended for lifting and transfer of heavy patients bar individually.
-
Page 2: Safety Information
Safety Information Before lifting, keep the following points in mind: • A responsible person within your organization should decide on a case-by-case basis whether one or more caregivers are needed. • Make sure that the sling selected meets the patient’s needs with reference to model, size, fabric and design. •... -
Page 3: Symbol Description
Symbol Description These symbols may be found in this document and/or on the product. Symbol Description Symbol Description Warning; this situation requires extra care and attention. This symbol is a yellow triangle with a black border, and a black exclamation mark at the center. Recyclable Read instructions for use before use. -
Page 4: Care And Maintenance
Care and Maintenance Check the sling before each use. Check the following points with regard to wear and damage: • Fabric • Straps • Seams • Loops Do not use damaged lifting accessories. If anything is unclear, please contact the manufacturer or supplier. Washing and Disinfection Instructions: Please see the sling’s product label and the attached appendix ”Care and Maintenance of Liko Slings”. - Page 5 How to Attach a UltraSling to a SlingBar Upper strap loop Outer leg support loop Inner leg support loop The illustrations 1, 2, and 3 shows the use of sling bars with two different width, the same principle applies if you use two Universal SlingBar 600.
- Page 6 How to Select Sling Size Only use a sling that is the correct size for the patient. Correct size must be assessed by a trained caregiver. Patient entrapment or asphyxiation could occur. The hip width measurement on the patient and on the sling gives guidance when choosing the size of the sling. Compare the measurement of the patient (see instruction for measuring) and the measurement of the sling (see table or instruction for measuring).
- Page 7 Dimensions A. Upper strap to outer leg support length B. Center back height C. Shoulder breadth D. Upper strap loop length E. Hip to knee length F. Outer leg support loop to inner support loop length G. Hip width of sling H.
- Page 8 Hillrom, Liko and Repo Sheet are trademarks of Baxter International Inc. or its subsidiaries. Any other trademarks, product names or brand images appearing herein are the property of their respective owners. www.hillrom.com Liko AB Nedre vägen 100 975 92 Luleå, Sweden +46 (0)920 474700 Liko AB is a subsidiary of Hill-Rom Holdings Inc.
