KOEAP31WT
EN
Oven
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOEAP31WT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux KOEAP31WT

Summary of Contents for Electrolux KOEAP31WT

  • Page 1 KOEAP31WT Oven User Manual...

  • Page 2: Table Of Contents

    WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3 11. CARE AND CLEANING......27 15. IT'S EASY!..........39 11.1 Notes on cleaning......27 16. ENVIRONMENTAL CONCERNS.....40 11.2 How to remove: Shelf supports ...28 11.3 How to use: Pyrolytic Cleaning..28 My Electrolux Kitchen app Subject to change without notice. 3/44...

  • Page 4: Safety Information

    Children should be supervised to ensure that they do not • play with the appliance and mobile devices with My Electrolux Kitchen . Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become •...
  • Page 5 SAFETY INFORMATION This appliance may be used in, offices, hotel guest rooms, • bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and •...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS 2. SAFETY INSTRUCTIONS 2.1 Installation WARNING! Only a qualified person must install this appliance. • Remove all the packaging. • Do not install or use a damaged appliance. • Follow the installation instructions supplied with the appliance. • Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.

  • Page 7: Electrical Connection

    SAFETY INSTRUCTIONS 2.2 Electrical connection WARNING! Risk of fire and electric shock. • All electrical connections should be made by a qualified electrician. • The appliance must be earthed. • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.

  • Page 8: Care And Cleaning

    SAFETY INSTRUCTIONS WARNING! Risk of damage to the appliance. • To prevent damage or discoloration to the enamel: – do not put ovenware or other objects in the appliance directly on the bottom. – do not put aluminium foil directly on the bottom of cavity of the appliance. –...

  • Page 9: Internal Lighting

    SAFETY INSTRUCTIONS • Do not spill or apply water on the oven door during and after the pyrolytic cleaning to avoid damaging the glass panels. • Fumes released from all pyrolytic ovens / cooking residues as described are not harmful to humans, including children, or persons with medical conditions.

  • Page 10: Product Description

    PRODUCT DESCRIPTION 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Display Socket for the food sensor Heating element Lamp Shelf support, removable Shelf positions 3.2 Accessories Wire shelf For cookware, cake tins, roasts. Baking tray For cakes and biscuits. Grill- / Roasting pan To bake and roast or as a pan to collect fat.

  • Page 11: Control Panel

    CONTROL PANEL Food sensor To measure the temperature inside food. Telescopic runners For inserting and removing trays and wireshelf more easily. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. Display Shows the current settings of the appliance.

  • Page 12: Display

    CONTROL PANEL 4.2 Display The display with the maximum number of func‐ B C D tions set. A. Menu / Back Conventional cooking B. Wi-Fi (selected models only) C. Time of day D. Information E. Timer H G F E F.

  • Page 13: Before First Use

    To connect the appliance you need: • Wireless network with the Internet connection. • Mobile device connected to the same wireless network. Step 1 Download the mobile app My Electrolux Kitchen and follow the instructions for the next steps. Step 2 Turn on the appliance.

  • Page 14: Software Licences

    5.4 Software licences The software in this product contains components that are based on free and open source software. Electrolux acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, visit: http://electrolux.opensoftwarerepository.com (folder GTM3).

  • Page 15: How To Set: Heating Functions

    DAILY USE 6.1 How to set: Heating functions Step 1 Turn on the oven. Step 2 Select a heating function. The display shows the default heating functions. To see more heating functions press: Step 3 Press: . The display shows the temperature settings. 170°C 70°C 170°C...

  • Page 16: Heating Functions

    DAILY USE Step 5 Press: 6.3 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to three shelf positions at the same time and to dry food.
  • Page 17 DAILY USE SPECIALS Heating function Application To preserve vegetables (e.g., pickles). Preserving To dry sliced fruit, vegetables and mushrooms. Dehydrating To preheat plates for serving. Plate Warming To speed up the rising of the yeast dough. It prevents dough surface from drying and keeps the dough elastic.

  • Page 18: Notes On: Moist Fan Baking

    CLOCK FUNCTIONS 6.4 Notes on: Moist Fan Baking This function was used to comply with the energy efficiency class and ecodesign requirements (according to EU 65/2014 and EU 66/2014). Tests according to: IEC/EN 60350-1 The oven door should be closed during cooking so that the function is not interrupted and the oven operates with the highest energy efficiency possible.
  • Page 19 CLOCK FUNCTIONS How to set the clock Step 2 Press: Settings / Setup / Time of day. Step 3 Slide and press to set the clock. Press: or . How to set cooking time Step 1 Choose a heating function and set the temperature. Step 2 Press: Step 3...

  • Page 20: Using The Accessories

    USING THE ACCESSORIES How to delay start without setting the end of cooking Step 2 Press: Step 3 Press: Step 4 Press: Delayed start. Step 5 Choose the value. Press: How to set extra time When 10% of cooking time is left and the food seems not to be ready, you can extend cooking time.

  • Page 21: Inserting Accessories

    USING THE ACCESSORIES 8.1 Inserting accessories A small indentation at the top increases safety. The indentations are also anti-tip devices. The high rim around the shelf prevents cookware from slipping of the shelf. Wire shelf: Push the shelf between the guide bars of the shelf support.

  • Page 22: How To Use: Food Sensor

    USING THE ACCESSORIES 8.3 How to use: Food Sensor Step 1 Turn on the oven. Step 2 Set a heating function and, if necessary, the oven temperature. Step 3 Insert: Food Sensor. Meat, poultry and fish Casserole Insert the tip of Food Sensor into the centre Insert the tip of Food Sensor exactly in the centre of meat, fish, in the thickest part if possible.

  • Page 23: Additional Functions

    ADDITIONAL FUNCTIONS Step 8 Press: When food reaches the set temperature, the signal sounds. You can choose to stop or to continue cooking to make sure the food is well done. Step 9 Remove Food Sensor plug from the socket and remove the dish from the oven. WARNING! There is a risk of burns as Food Sensor becomes hot.

  • Page 24: Cooling Fan

    HINTS AND TIPS (°C) 250 - maximum The Automatic switch-off does not work with the functions: Light, Food sensor, End time, Slow Cooking. 9.3 Cooling fan When the appliance operates, the cooling fan turns on automatically to keep the surfaces of the appliance cool.

  • Page 25: Moist Fan Baking - Recommended Accessories

    HINTS AND TIPS (°C) (min) Cookies, 16 baking tray or dripping 20 - 30 pieces Macaroons, 24 baking tray or dripping 25 - 35 pieces Muffins, 12 baking tray or dripping 20 - 30 pieces Savory pastry, baking tray or dripping 20 - 30 20 pieces Short crust bis‐...
  • Page 26 HINTS AND TIPS Baking on one level - baking in tins °C Fatless sponge cake True Fan Cooking 45 - 60 Fatless sponge cake Conventional Cook‐ 45 - 60 Apple pie, 2 tins Ø20 cm True Fan Cooking 55 - 65 Apple pie, 2 tins Ø20 cm Conventional Cook‐...

  • Page 27: Care And Cleaning

    CARE AND CLEANING °C Apple pie, 1 tin per grid True Fan Cooking 55 - 65 2 / 4 (Ø 20 cm) Grill Preheat the empty oven for 5 minutes. Grill with the maximum temperature setting. Toast Grill 1 - 2 Beef steak, turn halfway Grill 24 - 30...

  • Page 28: How To Remove: Shelf Supports

    CARE AND CLEANING Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged Accessories objects.

  • Page 29: Cleaning Reminder

    CARE AND CLEANING Step 1 Step 2 Step 3 Turn on the oven. Press: Menu / Cleaning. Select the cleaning mode. Option Cleaning mode Duration Pyrolytic cleaning, quick Light cleaning Pyrolytic cleaning, normal Normal cleaning 1 h 30 min Pyrolytic cleaning, intense Thorough cleaning When the cleaning starts, the lamp is off and the cooling fan works at a higher speed.

  • Page 30: How To Replace: Lamp

    CARE AND CLEANING Step 1 Fully open the door. Step 2 Lift and press the clamping levers (A) on the two door hinges. Step 3 Close the oven door to the first opening position (approximately 70° angle). Hold the door at both sides and pull it away from the oven at an upwards angle. Put the door with the outer side down on a soft cloth on a stable surface.

  • Page 31: Troubleshooting

    TROUBLESHOOTING Before you replace the lamp: Turn off the oven. Wait until Disconnect the oven from the Put a cloth on the bottom of the oven is cold. mains. the cavity. Top lamp Step 1 Turn the glass cover to remove it. Step 2 Clean the glass cover.

  • Page 32: What To Do If

    TROUBLESHOOTING 12.1 What to do if... The appliance does not turn on or does not heat up Possible cause Remedy The appliance is not connected to an electrical Check if the appliance is correctly connected to supply or it is connected incorrectly. the electrical supply.

  • Page 33: How To Manage: Error Codes

    TROUBLESHOOTING Problems with Wi-Fi signal Possible cause Remedy Trouble with wireless network signal. Check if your mobile device is connected to the wireless network. Check your wireless network and router. Restart the router. New router installed or router configuration To configure appliance and mobile device changed.

  • Page 34: Service Data

    We recommend that you write the data here: Model (MOD.) ......... Product number (PNC) ......... Serial number (S.N.) ......... 13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet Supplier's name Electrolux Model identification KOEAP31WT 944184868 Energy Efficiency Index 61.2 34/44...

  • Page 35: Energy Saving

    ENERGY EFFICIENCY Energy efficiency class Energy consumption with a standard load, conventional 1.09 kWh/cycle mode Energy consumption with a standard load, fan-forced 0.52 kWh/cycle mode Number of cavities Heat source Electricity Volume 71 l Type of oven Built-In Oven Mass 37.0 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.

  • Page 36: Menu Structure

    MENU STRUCTURE Moist Fan Baking Function designed to save energy during cooking. When you use this function the lamp automatically turns off after 30 sec. You may turn on the lamp again but this action will reduce the expected energy savings. Standby mode After 2 min the display switches to standby mode.

  • Page 37: Submenu For: Options

    MENU STRUCTURE 14.3 Submenu for: Options Submenu Application Light Turns the lamp on and off. Lamp Icon visible Lamp icon appears on the screen. Child Lock Prevents accidental activation of the appliance. When the option is on, the text Child Lock appears in the display when you turn on the appli‐ ance.

  • Page 38: Submenu For: Setup

    MENU STRUCTURE 14.5 Submenu for: Setup Submenu Description Language Sets the appliance language. Time of day Sets the current time and date. Time indication Turns the clock on and off. Digital clock style Changes the format of the displayed time indication. Cleaning Reminder Turns the reminder on and off.

  • Page 39: S Easy

    IT'S EASY! 15. IT'S EASY! Before the first use you have to set: Language Display brightness Buzzer volume Time of day Familiarize yourself with the basic icons on the control panel and the display: Menu / Informa‐ Food sen‐ ON / OFF Timer More Back...

  • Page 40: Environmental Concerns

    IT'S EASY! Get to know how to cook quickly Assisted Step 1 Step 2 Step 3 Step 4 Cooking Choose the Press: Press: Press: Assis‐ dish. ted Cooking. Use quick functions to set the cooking time or change the cooking function Quick timer settings Step 1 Step 2...
  • Page 44 www.electrolux.com/shop...
