Network Video Recorder
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the NVR-100MH-C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION NVR-100MH-C Series

Summary of Contents for HIKVISION NVR-100MH-C Series

  • Page 1 Network Video Recorder User Manual...

  • Page 2: About This Manual

    WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 3 Network Video Recorder User Manual YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.

  • Page 4: Regulatory Information

    Network Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for pursuant to part 15 of the FCC Rules.
  • Page 5 Network Video Recorder User Manual purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: http://www.recyclethis.info . 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information.

  • Page 6: Applicable Model

    Network Video Recorder User Manual Applicable Model This manual is applicable to the following models. Table 1-1 Applicable Model Series Model NVR-100MH-C NVR-104MH-C NVR-108MH-C NVR-116MH-C NVR-100MH-C/P NVR-104MH-C/4P NVR-108MH-C/8P NVR-200MH-C NVR-208MH-C NVR-216MH-C NVR-200MH-C/P NVR-208MH-C/8P NVR-216MH-C/16P NVR-100MH-K NVR-104MH-K NVR-108MH-K NVR-116MH-K NVR-100MH-K/P NVR-104MH-K/4P NVR-108MH-K/8P NVR-200MH-K NVR-208MH-K...

  • Page 7: Symbol Conventions

    Network Video Recorder User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...

  • Page 8: Safety Instruction

    Network Video Recorder User Manual Safety Instruction Proper configuration of all passwords and other security settings is the responsibility of the ● installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations ●...

  • Page 9: Preventive And Cautionary Tips

    Network Video Recorder User Manual Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: The device is designed for indoor use only. Install it in a well-ventilated, dust-free environment ● without liquids. Ensure recorder is properly secured to a rack or shelf.
  • Page 10 Network Video Recorder User Manual For the device with sticker , pay attention to the following cautions: CAUTION: Hot ● parts! Do not touch. Burned fingers when handling the parts. Wait one-half hour after switching off before handling the parts. If the device needs to be installed on the wall or ceiling, ●...

  • Page 11: Table Of Contents

    Network Video Recorder User Manual Contents Chapter 1 Startup ........................1 1.1 Activate Your Device ......................1 1.2 Login ............................2 1.2.1 Log in via Unlock Pattern ....................2 1.2.2 Log in via Password ....................... 3 Chapter 2 Live View ........................5 2.1 GUI Introduction ........................
  • Page 12 Network Video Recorder User Manual 5.2.1 General ........................21 5.2.2 HiLookVision ....................... 21 5.2.3 Email ........................... 22 5.3 Camera Management ......................24 5.3.1 Network Camera ......................24 5.3.2 OSD Settings ........................ 27 5.3.3 Motion ........................28 5.4 Device Access ........................31 5.4.1 Switch ..........................
  • Page 13 Network Video Recorder User Manual 6.2.5 NTP ..........................47 6.2.6 Upload Logs to the Server ................... 47 6.2.7 Ports (More Settings) ....................48 6.2.8 OTAP Service ....................... 48 6.2.9 Email ........................... 49 6.3 Camera Management ......................49 6.3.1 Network Camera ......................49 6.3.2 Display Settings ......................
  • Page 14 Network Video Recorder User Manual 6.8.3 Storage Device ......................81 6.8.4 Configure Storage Mode ..................... 83 6.8.5 Advanced Settings ....................... 83 6.9 Face Picture Library Management ..................84 6.9.1 Add a Face Picture Library ................... 84 6.9.2 Upload Face Pictures to the Library ................84 Chapter 7 Maintenance ......................
  • Page 15 Network Video Recorder User Manual 9.6 Log ............................94 Chapter 10 Appendix ........................ 96 10.1 Glossary ..........................96...

  • Page 16: Chapter 1 Startup

    Network Video Recorder User Manual Chapter 1 Startup 1.1 Activate Your Device For the first-time access, you need to activate the video recorder by setting an admin password. No operation is allowed before activation. You can also activate the video recorder via web browser, SADP or client software.

  • Page 17: Login

    Network Video Recorder User Manual Note When you forget your password, the hint will help you remember it. It is recommended to set the password hint. 6. Optional: Set Unlock Pattern. 1) Enable Unlock Pattern. 2) Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done.

  • Page 18: Log In Via Password

    Network Video Recorder User Manual Figure 1-1 Draw the Unlock Pattern 2. Draw the pre-defined pattern to enter the menu operation. Note If you have forgotten your pattern, you click Forgot My Pattern or Switch User to log in via ●...
  • Page 19 Network Video Recorder User Manual Figure 1-2 Login Interface 2. Input password. 3. Click Login. Note When you forget the password of the admin, you can click Forgot Password to reset the ● password. If you enter the wrong password 7 times, the current user account will be locked for 60 ●...

  • Page 20: Chapter 2 Live View

    Network Video Recorder User Manual Chapter 2 Live View 2.1 GUI Introduction Click Target Detection at the upper-left corner, and select to display the specified live ● target detection results. For result details, click View More. Note Target Detection is only available for certain models. ○...
  • Page 21 Network Video Recorder User Manual Button Description Click to start two-way audio between NVR and network camera. Note Ensure that the network camera supports two-way audio. Switch video stream. Display rule frame and target frame. Adjust image display effect according to the screen size. In the live view interface, there are icons at the upper-right corner of the screen for each ●...

  • Page 22: Ptz Control

    Network Video Recorder User Manual 2.2 PTZ Control 2.2.1 Configure PTZ Parameter You shall configure PTZ parameters before controlling a PTZ camera. Steps 1. Preview a camera in live view and click on shortcut menu. Figure 2-3 PTZ Settings 2. Click 3.

  • Page 23: Ptz Control Panel Introduction

    Network Video Recorder User Manual 2.2.2 PTZ Control Panel Introduction Table 2-3 PTZ Panel Description Icon Description Direction buttons, and the auto-cycle button. The speed of the PTZ movement. Zoom -/+. Focus -/+. Iris -/+. 2.2.3 Customize Preset Set a preset location where the PTZ camera would point to when an event occurs. Steps 1.

  • Page 24: Customize Pattern

    Network Video Recorder User Manual 2. Click Patrol. 3. Click of a desired patrol. 4. Click 5. Configure key point parameters, such as the key point No., duration of staying for one key point and speed of patrol. The key point is corresponding to the preset. The preset number determines the order at which the PTZ will follow while cycling through the patrol.

  • Page 25: Chapter 3 Playback

    Network Video Recorder User Manual Chapter 3 Playback 3.1 GUI Introduction Go to Playback . Figure 3-1 Playback Table 3-1 Playback Interface Description Button Operation Button Operation 30 s reverse. 30 s forward. Full screen. Start playback. Speed down. Speed up. Speed.

  • Page 26: Normal Playback

    Network Video Recorder User Manual 3.2 Normal Playback Play back normal videos. Steps 1. Go to Playback . 2. Select a camera from the camera list. 3. Select a date on the calendar for playback. Note The blue triangle at the calendar date corner indicates there are available videos. For example, means video is available.
  • Page 27 Network Video Recorder User Manual Button Description Button Description Lock/unlock video. Clip video. Show videos that contain Show videos that contain human. vehicle. Skip Normal Videos If you have clicked Display rule frame and target the device will hide other frame.

  • Page 28: Event Playback

    Network Video Recorder User Manual 3) Filter time and channel in search results. 4) Click a picture to play a video before and after that moment. Note When searching for a target on the AcuSearch interface, you can slide the mouse wheel to switch between the previous frame and the next frame.

  • Page 29: Slice Playback

    Network Video Recorder User Manual Play Speed of Smart/Custom Video Set playback speed of videos with smart information. The option is only valid when Do not Play Normal Videos is enabled. 3.4 Slice Playback Divide the video into slices and play them back. Steps 1.

  • Page 30: Back Up Clip

    Network Video Recorder User Manual Table 3-4 Slice Playback Icon Description Icon Name Description AcuSearch a. Click to show all the targets. b. Select a target and click to search for pictures that contain the target. c. Filter time and channel in search results. d.
  • Page 31 Network Video Recorder User Manual 4. Click Save. 5. Select the backup device and folder. 6. Click Save to export the clip to backup device.

  • Page 32: Chapter 4 Search File

    Network Video Recorder User Manual Chapter 4 Search File Steps 1. Go to Search. 2. Select a search type (video, picture, event, etc.). 3. Set search conditions. 4. Optional: Click Quick Backup to quickly export videos to the device. Note Quick backup is available for video and event search.

  • Page 33: Chapter 5 Configuration (Easy Mode)

    Network Video Recorder User Manual Chapter 5 Configuration (Easy Mode) Easy mode contains basic configurations. Go to Configuration , and click Easy Mode. 5.1 System Configuration 5.1.1 General You can configure the output resolution, system time, etc. Steps 1. Go to Configuration → System → General . 2.
  • Page 34 Network Video Recorder User Manual Steps 1. Go to Configuration → System → User . 2. Click Add and confirm your admin password. 3. Enter user name. 4. Select user level. 5. Enter the same password in Create Password and Confirm. Warning We highly recommend you create a strong password of your own choosing in order to ●...

  • Page 35: Exception

    Network Video Recorder User Manual 3. Follow the wizard to reset password. 5.1.3 Exception You can receive exception events hint in alarm center, and set exception linkage actions. Steps 1. Go to Configuration → System → Exception . 2. Optional: Configure event hint. When the set events occur, you will receive hints in alarm center. 1) Enable Event Hint.

  • Page 36: Network Configuration

    Network Video Recorder User Manual 5.2 Network Configuration 5.2.1 General You shall properly configure the network settings before operating the device over network. Steps 1. Go to Configuration → Network → General . Figure 5-2 Network 2. Set network parameters. DHCP If the DHCP server is available, you can enable DHCP to automatically obtain an IP address and other network settings from that server.

  • Page 37: Email

    7. Bind your device with a HiLookVision account. 1) Use a smart phone to scan the QR code, and download HiLookVision app. You can also download it from https://appstore.hikvision.com , or the QR code below. Refer to HiLookVision Mobile Client User Manual for details.
  • Page 38 Network Video Recorder User Manual Before You Start Ensure SMTP service is available for your email. ● Configure your network parameters. Refer to General for details. ● Steps 1. Go to Configuration → Network → Email . Figure 5-4 Email 2.

  • Page 39: Camera Management

    Network Video Recorder User Manual Attached Picture (Optional) If events are triggered, it will send images as email attachment. Sender The sender name. Sender's Address The sender's email address. Select Receiver Select a receiver. Up to 3 receivers are available. Receiver The receiver name.
  • Page 40 Network Video Recorder User Manual Note If the camera is inactive, the device will activate it automatically with the password you have set during device activation. 4. Optional: If your network camera is not on the same network segment with the NVR and supports ONVIF protocol, click Advanced Search and fill in the first three octets of the camera IP address to add the camera(s).
  • Page 41 Network Video Recorder User Manual Figure 5-5 Add Network Camera Edit Connected Network Camera You can edit the IP address, protocol and other parameters of the added network cameras. Steps 1. Go to Configuration → Camera → IP Camera . 2.

  • Page 42: Osd Settings

    Network Video Recorder User Manual Upgrade Network Camera The Network camera can be remotely upgraded through the device. Before You Start Ensure you have inserted the USB flash drive to the device, and it contains the network camera ● upgrade firmware. Ensure your network camera is on the same network segment with your video recorder.

  • Page 43: Motion

    Network Video Recorder User Manual Figure 5-6 OSD 3. Set parameters as your desire. 4. Drag the text frames on the preview window to adjust the OSD position. 5. Click Apply. 5.3.3 Motion Motion Detection Motion detection enables the video recorder to detect the moving objects in the monitored area and trigger alarms.
  • Page 44 Network Video Recorder User Manual Figure 5-7 Motion Detection 2. Select a camera. 3. Turn on Enable. 4. Set VCA Mode as By NVR or By Camera. By NVR The motion detection event will be analyzed by NVR. The device can analyze videos that contain human and vehicle.

  • Page 45: Configure Arming Schedule

    Network Video Recorder User Manual Note When VCA Mode is set as By NVR, the human/vehicle target detection is conflicted with 4K/2K output resolution, please lower the resolution. 8. Set the arming schedule. Refer to Configure Arming Schedule for details. 9.

  • Page 46: Device Access

    Network Video Recorder User Manual Buzzer Alarm It will trigger a buzzer beep when an alarm is triggered. Notify Surveillance Center The device will send an exception or alarm signal to the remote client software when an alarm is triggered. Send Email It will send an email with alarm information when an alarm is triggered.

  • Page 47: Non-Video Event (Easy Mode)

    Network Video Recorder User Manual Parameter Description User Name / Password The user name / password of the switch. Use Camera Activation Use the camera activation password of the video recorder to add Password the switch. 3. Click Add and Continue and repeat operation until all devices have been added. 4.
  • Page 48 Network Video Recorder User Manual Note Up to 4 IP speakers can be added. Add IP Speaker Manually Steps 1. Go to Configuration → Device Access → IP Speaker . 2. In the Added Device List, click Add and set the parameters of the device. Table 5-2 Device Parameter Description Parameter Description...

  • Page 49: Media Library

    Network Video Recorder User Manual 3. Turn on Enable Time Sync. 4. Set Time Sync Interval. 5. Click OK. Configure Audio Parameters Steps 1. Go to Configuration → Device Access → IP Speaker . 2. Click Audio Parameter. 3. Configure the volume of the IP speaker. Media Library Supports importing audio from the external storage to the media library.

  • Page 50: Configure Poe Binding

    Network Video Recorder User Manual Note The PoE ports are enabled with the short distance mode by default. ● The bandwidth of IP camera connected to the PoE via long network cable (100 to 300 meters) ● cannot exceed 6 Mbps. The allowed max.

  • Page 51: Configure Recording Schedule

    Network Video Recorder User Manual Repair Database Repair an HDD that with error in database. Please operate it with the help of professional technical support. Add Network Disk You can add the allocated NAS or IP SAN disk to the video recorder, and use it as a network HDD. Steps 1.

  • Page 52: Configure Continuous Recording

    Network Video Recorder User Manual Configure Continuous Recording Steps 1. Go to Configuration → Record → Parameter . 2. Set the continuous main stream/sub-stream recording parameters for the camera. Refer to Configure Recording Parameter for details. 3. Go to Configuration → Record → Schedule . 4.

  • Page 53: Configure Recording Parameter

    Network Video Recorder User Manual Figure 5-10 Recording Schedule Continuous Continuous recording. Event Recording is triggered by events. 2. Select a camera in Camera No. 3. Turn on Enable. 4. Configure the recording schedule. Edit a. Click Edit. Schedule b. Select a day to configure in Weekday. c.
  • Page 54 Network Video Recorder User Manual 2. Configure recording parameters. Main Stream Main stream refers to the primary stream that affects data recorded to the hard disk drive and will directly determine your video quality and image size. Comparing with the sub- stream, the main stream provides a higher quality video with higher resolution and frame rate.

  • Page 55: Chapter 6 Configuration (Expert Mode)

    Network Video Recorder User Manual Chapter 6 Configuration (Expert Mode) Go to Configuration , and click Expert Mode at the lower-left corner. 6.1 System Configuration 6.1.1 General Configure Basic Settings You can configure the language, system time, output resolution, mouse pointer speed, lock screen password, etc.

  • Page 56: Live View

    Network Video Recorder User Manual Note After you change the region, the language, time zone. system date, system time, and DST settings will be changed in sync with the region. 3. Optional: Select the Date Format. 4. Click Apply. Configure More Settings You can configure your device name, lock screen time, output mode, etc.

  • Page 57: Configure Live View Layout

    Network Video Recorder User Manual Figure 6-1 Live View-General 2. Configure the Live View parameters. Window Division Select the live view window division. Auto Switch Interval The time to dwell in a camera before switching to next camera when auto-switch in live view is enabled.

  • Page 58: Configure Channel-Zero Encoding

    Network Video Recorder User Manual 3. Select a window, and double click a camera the list you would like to display. means no camera is displayed on the window. 4. Optional: Click to start or stop live view of all cameras. 5.

  • Page 59: Network Configuration

    Network Video Recorder User Manual 6.2 Network Configuration 6.2.1 TCP/IP TCP/IP must be properly configured before you operate video recorder over network. Steps 1. Go to Configuration → Network → General → TCP/IP . 2. Configure network parameters. Working Mode Multi-address Mode The parameters of the two NIC cards can be configured independently.

  • Page 60: Ddns

    Network Video Recorder User Manual 3. Click Apply. 6.2.2 DDNS Dynamic domain name server (DDNS) maps dynamic user IP addresses to a fixed domain name server. Before You Start Register DynDNS, PeanutHull and NO-IP services with your ISP. Steps 1. Go to Configuration → Network → General → DDNS . Figure 6-3 DDNS 2.

  • Page 61: Nat

    Network Video Recorder User Manual Steps 1. Go to Configuration → Network → General → PPPOE . 2. Check Enable. 3. Enter PPPoE user name and password. 4. Click Apply. Note PPPoE function will take effect after reboot. ● If you enable PPPoE, DHCP would be disabled. ●...

  • Page 62: Ntp

    Network Video Recorder User Manual The value of the RTSP port No. should be 554 or between 1024 and 65535, while the value of the other ports should be between 1 and 65535 and the value must be different from each other. If multiple devices are configured for the UPnP™ settings under the same router, the value of the port No.

  • Page 63: Ports (More Settings)

    Network Video Recorder User Manual 3. Set Upload Time Interval, Server IP Address, and Port. 4. Optional: Click Test to test if parameters are valid. 5. Click Apply. 6.2.7 Ports (More Settings) Set different port types to enable relevant functions as your desire. Go to Configuration →...

  • Page 64: Email

    Network Video Recorder User Manual 3. Turn on Enable. Note Enabling OTAP service will disable other platform access. 4. Set the related parameters. Server Address The platform server IP address. Port The platform server port ranges from 1 to 65535. The default value is 7800. The actual port shall be provided by the platform.
  • Page 65 Network Video Recorder User Manual 2. Click Online Device List. The online cameras on the same network segment will be displayed in the list. 3. Optional: Click Edit IP to edit camera IP addresses in batch. The system will allocate IP addresses to the selected cameras in order.
  • Page 66 Network Video Recorder User Manual Figure 6-6 Add IP Camera 3. Enter network camera parameters. Use Camera Activation Password If it is enabled, the video recorder will add the camera by the set channel default password. 4. Click Add. Add Network Camera on Different Network Segment If your network camera is on a different network segment, the device can search its IP address within a range of IP addresses, and add it.
  • Page 67 Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → Camera → IP Channel . 2. Click Advanced Search. 3. Enter Network Segment. Figure 6-7 Enter Network Segment 4. Click Add. Add Network Camera Through Plug-and-Play If an inactive network camera or third party ONVIF camera is connected to your network, the video recorder may automatically detect and add the camera, or notify you to manually add it.
  • Page 68 Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → Camera . 2. Click of an added network camera. Channel Port If the connected device is an encoding device with multiple channels, you can choose the channel to connect by selecting the channel port No. in the drop-down list. 3.
  • Page 69 Network Video Recorder User Manual Long-distance (100 to 300 meters) network transmissions via PoE interface. Short Distance Short-distance (< 100 meters) network transmission via PoE interface. Note The PoE ports are enabled with the short distance mode by default. ● The bandwidth of IP camera connected to the PoE via long network cable (100 to 300 meters) ●...
  • Page 70 Network Video Recorder User Manual Add Non-PoE Network Camera You can use the PoE channel resource to connect a non-PoE network camera. Steps 1. Go to Configuration → Camera → Camera → IP Channel . 2. Click of a channel with no linked network camera. 3.

  • Page 71: Advanced Settings

    Network Video Recorder User Manual 4. Set the storage device and folder path. 5. Click Export/Import. What to do next After the importing process is completed, you must restart the video recorder. Advanced Settings Steps 1. Go to Configuration → Camera → Camera . 2.

  • Page 72: Display Settings

    Network Video Recorder User Manual Note This function is only available for NVRs that support PoE function. 6.3.2 Display Settings Configure the OSD (On-Screen Display), image settings, exposure settings, day/night switch settings, etc. Steps 1. Go to Configuration → Camera → Display . 2.

  • Page 73: Privacy Mask

    Network Video Recorder User Manual Figure 6-10 OSD 4. Drag the text frames on the preview window to adjust the OSD position. 5. Click Apply. 6.3.3 Privacy Mask You are allowed to configure the privacy mask areas that cannot be viewed or recorded. Steps 1.

  • Page 74: Device Access

    Network Video Recorder User Manual Figure 6-11 Privacy Mask 4. Drag to draw an area on the window. The frames of the areas will be marked with different colors. Note Up to 4 privacy mask areas can be configured. The size of each area can be adjusted. 5.

  • Page 75: Ip Speaker

    Network Video Recorder User Manual Steps 1. Go to Configuration → Device Management → Switch. 2. In the Online Device List, check the switch(es) to be added and click Add to add switch(es) in the same network segment with the video recorder using the camera activation password. Add Switch Manually Steps 1.
  • Page 76 Network Video Recorder User Manual Add IP Speaker Manually Steps 1. Go to Configuration → Device Access → IP Speaker . 2. In the Added Device List, click Add and set the parameters of the device. Table 6-2 Device Parameter Description Parameter Description IP Address...

  • Page 77: Poe Settings

    Network Video Recorder User Manual Configure Audio Parameters Steps 1. Go to Configuration → Device Access → IP Speaker . 2. Click Audio Parameter. 3. Configure the volume of the IP speaker. Media Library Supports importing audio from the external storage to the media library. Steps 1.

  • Page 78: Configure Poe Binding

    Network Video Recorder User Manual Note The PoE ports are enabled with the short distance mode by default. ● The bandwidth of IP camera connected to the PoE via long network cable (100 to 300 meters) ● cannot exceed 6 Mbps. The allowed max.
  • Page 79 Network Video Recorder User Manual Figure 6-12 Video Tampering 2. Set Camera. 3. Turn on Enable. 4. Adjust Sensitivity as your desire. The higher the value is, the more easily the video tampering can be triggered. 5. Set the arming schedule. Refer to Configure Arming Schedule for details. 6.

  • Page 80: Alarm Input

    Network Video Recorder User Manual Alarm Input Set linkage actions for an external sensor alarm. Steps 1. Go to Configuration → Event → Normal Event → Alarm Input . Figure 6-13 Alarm Input Note Local alarm input: Local alarm input is triggered by the external device that connected to the video recorder's terminal block.
  • Page 81 Network Video Recorder User Manual Steps 1. Go to Configuration → Event → Normal Event → Alarm Output . Figure 6-15 Alarm Output 2. Click of a desired alarm output. 3. Customize Alarm Name. 4. Select Dwell Time. Figure 6-16 Edit Alarm Output 5.
  • Page 82 Network Video Recorder User Manual 3. Set the Flashing Time and Flashing Frequency. 4. Set the arming schedule. Refer to Configure Arming Schedule for details. 5. ClickSave. Audio Alarm Output When light and audio alarm camera is connected, you can set the parameters and arming schedule of the audio alarm.

  • Page 83: Perimeter Protection

    Network Video Recorder User Manual Figure 6-17 Exceptions 4. Set the arming schedule. Refer to Configure Arming Schedule for details. 5. Click Apply. 6.6.2 Perimeter Protection Perimeter protection includes line crossing detection, intrusion detection, region entrance detection, and region exiting detection. Note Perimeter protection is only available for certain device models or camera models.

  • Page 84: Intrusion Detection

    Network Video Recorder User Manual The event will be analyzed by NVR. The device can analyze videos that contain human and vehicle. Only the target of selected type (human or vehicle) will trigger alarms, which can reduce false alarms that are caused by other objects. By Camera The event will be analyzed by camera.

  • Page 85: Region Entrance Detection

    Network Video Recorder User Manual 3. Select VCA Mode. By NVR The event will be analyzed by NVR. The device can analyze videos that contain human and vehicle. Only the target of selected type (human or vehicle) will trigger alarms, which can reduce false alarms that are caused by other objects.

  • Page 86: Region Exiting Detection

    Network Video Recorder User Manual By NVR The event will be analyzed by NVR. The device can analyze videos that contain human and vehicle. Only the target of selected type (human or vehicle) will trigger alarms, which can reduce false alarms that are caused by other objects. By Camera The event will be analyzed by camera.

  • Page 87: Facial Recognition

    Network Video Recorder User Manual 6. Set the detection rules and detection areas. 1) Set Arming Area. Up to 4 arming areas are selectable. 2) Adjust Sensitivity. Sensitivity: Range [0-100]. The higher the value is, the more easily the detection alarm can be triggered. 3) Optional: Set Detection Target as Human or Vehicle to discard alarms which are not triggered by human body or vehicle.
  • Page 88 Network Video Recorder User Manual Face Picture Comparison Face picture comparison compares the detected face pictures with face pictures in the face picture library. The device will trigger an alarm when comparison succeeded. Before You Start Ensure you have created at least one face picture library, and face pictures are added to the library. Refer to Face Picture Library Management for operation details.

  • Page 89: Non-Video Event

    Network Video Recorder User Manual 8. Click Apply. 6.6.4 Non-Video Event Configure non-video event. Steps 1. Go to Configuration → Device Management → Non-Video Event. 2. Select the device. 3. Select the Alarm Content. 4. Set the arming schedule. Refer to Configure Arming Schedule for details. 5.

  • Page 90: Configure Alarm Linkage Action

    Network Video Recorder User Manual Note Time periods shall not be repeated or overlapped. Figure 6-20 Set Arming Schedule 3. Click Apply. 6.6.7 Configure Alarm Linkage Action Configure Alarm Pop-up Window When an alarm is triggered, the local monitor displays in full screen the video image from the alarming channel configured for full screen monitoring.

  • Page 91: Notify Surveillance Center

    Network Video Recorder User Manual Configure Buzzer Alarm The audio warning enables the video recorder to trigger an audible beep when an alarm is detected. Steps 1. Go to Configuration → System → Live View → General . 2. Turn on Audio, and set Volume. 3.

  • Page 92: Intelligent Search

    Network Video Recorder User Manual 4. Go to Configuration → Event → Normal Event → Alarm Output . 5. Select an alarm output item from the list. Refer to Alarm Output for details. Configure PTZ Linkage Video recorder can trigger the PTZ actions (e.g., call preset/patrol/pattern) when the alarm event, or VCA detection events occur.

  • Page 93: Recording Management

    Network Video Recorder User Manual 6.8 Recording Management 6.8.1 Configure Recording Schedule Video recorder will automatically start/stop recording according to the configured schedule. Configure Continuous Recording Steps 1. Go to Configuration → Record → Parameter . 2. Set the continuous main stream/sub-stream recording parameters for the camera. 3.
  • Page 94 Network Video Recorder User Manual Figure 6-22 Recording Schedule Continuous Continuous recording. Event Recording triggered by all event triggered alarms. 2. Select a camera in Camera No. 3. Turn on Enable. 4. Configure the recording schedule. 1) Click Edit. 2) Select a day to configure in Weekday. 3) To set an all-day recording schedule, check All Day and select schedule Type.

  • Page 95: Configure Recording Parameter

    Network Video Recorder User Manual The time you set to record before the scheduled time or event. For example, when an alarm triggers the recording at 10:00, and if you set the pre-record time as 5 seconds, the camera records at 9:59:55. Post-Record The time you set to record after the event or the scheduled time.

  • Page 96: Storage Device

    Network Video Recorder User Manual Image resolution is a measure of how much detail a digital image can hold: the greater the resolution, the greater the level of detail. Resolution can be specified as the number of pixel- columns (width) by the number of pixel-rows (height), for example, 1024 × 768. Bitrate Type Variable bitrate: The bitrate would be adjusted based on different scenarios, which leads to ●...
  • Page 97 Network Video Recorder User Manual Add Network Disk You can add the allocated NAS or IP SAN disk to the video recorder, and use it as a network HDD. Steps 1. Go to Configuration → Record → Storage . 2. Click Add. 3.

  • Page 98: Configure Storage Mode

    Network Video Recorder User Manual 6.8.4 Configure Storage Mode Configure HDD Quota Each camera can be configured with an allocated quota for storing videos. Steps Note This function is only available for certain models. 1. Go to Configuration → Record → Storage Mode . 2.

  • Page 99: Face Picture Library Management

    Network Video Recorder User Manual When the HDD free space is not enough, you can disable it to save space, but your device will stop storing pictures. 6.9 Face Picture Library Management Face picture library is mainly used for face picture storage and face picture comparison. Note The section is only available for certain models.
  • Page 100 Network Video Recorder User Manual Note Only JPG and JPEG formats are supported. ● Each picture size should be less than 1 MB. ● The picture resolution shall be between 80 × 80 and 1920 × 1080. ●...

  • Page 101: Chapter 7 Maintenance

    Network Video Recorder User Manual Chapter 7 Maintenance 7.1 Upgrade Warning Do not shutdown or turn off the power during upgrade. 7.1.1 Local Upgrade Before You Start Store the upgrade firmware to a backup device, and connect it to your device. Steps 1.

  • Page 102: Restore Default

    Network Video Recorder User Manual 7.2 Restore Default Steps 1. Click at the upper-right corner. 2. Select the restoring type. Simple Restore Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.

  • Page 103: Buzzer Switch

    Network Video Recorder User Manual Two authentication types are selectable, if you select digest, only the request with digest authentication can access the video stream by the RTSP protocol via the IP address. For security reasons, it is recommended to select digest as the authentication type. ISAPI ISAPI (Internet Server Application Programming Interface) is an open protocol based on HTTP, which can realize the communication between the system devices (e.g., network camera,...

  • Page 104: Camera Upgrade

    Network Video Recorder User Manual Steps 1. Click at the upper-right corner. 2. Click More. 3. Go to Device Maintenance → Enable Schedule Reboot . 4. Turn on Enable. 5. Set the reboot schedule. 6. Click Apply. Note The device cannot record video during restart. 7.6.2 Camera Upgrade Upgrade the camera(s) in the added device list.
  • Page 105 Network Video Recorder User Manual View the current time sync information. 4. Click Time Sync Configuration. 5. Turn on Enable Time Sync Exception Detection. Note Supports detection of multiple time sync sources. If multiple time sync sources are detected, ● you need to turn off unnecessary time sync sources in time, otherwise it may cause device time changes, which will affect the recording.

  • Page 106: Chapter 8 Alarm

    Network Video Recorder User Manual Chapter 8 Alarm When events occur, you can view their details in alarm center. 8.1 Set Event Hint Select the events to hint in alarm center. Steps 1. Click at the upper-right corner. 2. Select event type as your desire. 3.

  • Page 107: Chapter 9 Web Operation

    Network Video Recorder User Manual Chapter 9 Web Operation 9.1 Introduction You can get access to the video recorder via web browser. You may use one of the following listed web browsers: Internet Explorer 11.0, Apple Safari, Mozilla Firefox, and Google Chrome. The supported resolutions include 1024×768 and above. For certain models, you will have to download a web component plug-in, and install it.

  • Page 108: Live View

    Network Video Recorder User Manual 9.3 Live View After login, live view interface shows. Figure 9-2 Live View 9.4 Playback Click Playback to enter playback interface. Figure 9-3 Playback 9.5 Configuration Click Configuration to enter configuration interface.
  • Page 109 Network Video Recorder User Manual Figure 9-4 Configuration 9.6 Log Steps 1. Go to Maintenance → System → Maintenance → Log . 2. Set the search conditions. 3. Click Search.
  • Page 110 Network Video Recorder User Manual Figure 9-5 Log...

  • Page 111: Chapter 10 Appendix

    Network Video Recorder User Manual Chapter 10 Appendix 10.1 Glossary Dual-Stream Dual-stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 1080P and the sub-stream having a maximum resolution of CIF.
  • Page 112 Network Video Recorder User Manual NTSC Acronym for National Television System Committee. NTSC is an analog television standard used in such countries as the United States and Japan. Each frame of an NTSC signal contains 525 scan lines at 60Hz. Acronym for Network Video Recorder.
  • Page 113 UD39044B...
