Summary of Contents for thomann t.amp PA4080
- Page 1 PA 4080 Package Powermixer...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 19.02.2024, ID: 143753 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features and scope of delivery......................10 Installation and starting up........................ 11 4.1 Tips on handling speakers......................12 Connections and operating elements................... 13 Operation.............................. - Page 4 PA 4080 Package Powermixer...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used for amplification and playback of signals from musical instruments and microphones. Use the unit only as described in this manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 8 Safety instructions DANGER! Danger to life due to electric current! A short circuit could lead to a fire hazard and risk of death. Always use proper ready-made insulated triple-core mains cable with a safety plug. Do not modify the mains cable or the plug. In case of isolation damage, disconnect immediately the power supply and arrange repair.
- Page 9 Safety instructions NOTICE! Damage to the device due to high voltages! The device can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess vol‐ tages can also cause a risk of injury and fires. Make sure that the voltage specification on the device matches the local power grid before plugging in the device.
-
Page 10: Features And Scope Of Delivery
Features and scope of delivery Features and scope of delivery Special features of this 4-channel powermixer: Output power 80 watt (sinus) Built-in spring reverb 1 × MIC-input (XLR, balanced) and 1 × MIC/LINE-input (6.35-mm jack) per channel Each channel with an independent control for volume, sound and reverb. 2 additional tape inputs and outputs Master 3-band EQ A looping-in of external effects is possible... -
Page 11: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 12: Tips On Handling Speakers
Installation and starting up 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 13: Connections And Operating Elements
Connections and operating elements Connections and operating elements Front ö & PA 4080 Package Powermixer... - Page 14 Connections and operating elements 1 [TONE] | Tone control for setting the required sound in the respective channel. 2 [REVERB] | Reverb control for adjusting the reverb level in the respective channel 3 [MIC] | Microphone input (for the respective channel), balanced. Use XLR cables to connect microphones to the MIC inputs. 4 [MIC/LINE] | Microphone/line input (for the respective channel), unbalanced.
- Page 15 Connections and operating elements 16 [REVERB] | Use this control to set the overall reverb level. 17 [VOLUME] | Use this control to set the volume of the master signal. PA 4080 Package Powermixer...
- Page 16 Connections and operating elements Back 18 [AC INPUT] | Rubber panel plug for the power supply 19 [EXTERNAL SPEAKER] | Connect the speaker boxes to these 6.35-mm jack sockets. The impedance of the external speakers must be at least 4 Ω. 20 [CD/TAPE PLAY] | Here you can connect the line output of tape devices, CD or MP3 players for additional audio input.
-
Page 17: Operation
Operation Operation Wiring Connect microphones to the low-impedance XLR inputs (MIC, 3) or the high-impedance 1/4" inputs (MIC/LINE, 4). Connect musical instruments to the 1/4" inputs (MIC/LINE, 4). Connect the speaker boxes via the supplied speaker cables to the [SPEAKER OUT] sockets (19) on the rear panel of the unit. - Page 18 Operation Turning on When all connections have been established, turn on the device using the main switch (9). The power LED (10) lights up. Adjusting sound and volume You can adjust the volume of the individual signals with the [VOLUME] controls (5) in each channel.
-
Page 19: Technical Specifications
Technical specifications Technical specifications Powermixer Input connections Power supply 1 × rubber panel plug C14 4 × XLR panel socket, 3-pin, balanced MIC/LINE 4 × 6.3-mm jack socket, unbalanced AUX IN 1 × 6.3-mm jack socket, unbalanced Foot switch 1 × 6.3-mm jack socket, unbalanced Output connections REVERB OUT 1 ×... - Page 20 Technical specifications MIC inputs 56 dB TAPE input 42 dB ±15 dB @ 5 kHz Channel tone control ±15 dB @ 10 kHz Master section EQ Treble ±15 dB @ 1 kHz Mids ±15 dB @ 100Hz Bass Protection circuitry Mute after powering on 2 seconds Power consumption at 1/8 of the original output power...
- Page 21 Technical specifications Speakers Configuration 1 × 10-inch woofer 1 × Piezo tweeter Input connections 2 × 6.3-mm jack socket Frequency range 110 Hz … 20 kHz, –20 dB Load capacity 60 W (RMS peak) Sensitivity (1 W/1 m) 93 dB (±3 dB) Rated impedance 8 Ω...
- Page 22 Technical specifications Further information Powermixer included Stand included Plastic housing Power amplifier included PA 4080 Package Powermixer...
-
Page 23: Plug And Pin Assignments
Plug and pin assignments Plug and pin assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 24 Plug and pin assignments 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground 1/4" TRS phone plug (stereo, unbalanced) Signal (left) Signal (right) Ground PA 4080 Package Powermixer...
- Page 25 Plug and pin assignments XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 PA 4080 Package Powermixer...
-
Page 26: Cleaning
Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth. -
Page 27: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 28 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
- Page 29 Notes PA 4080 Package Powermixer...
- Page 30 Notes PA 4080 Package Powermixer...
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
