- Page 1 USER MANUAL ELECTRIC SCOOTER...
-
Page 2: Table Of Contents
CONTENTS CONTENTS 1.General Information 1.1 Disclaimer and warning 1.2 Safety precautions 1.3 Strict prohibitions 1.4 Pre-ride checks 1.5 Waste disposal 2.Product Introduction 2.1 Product specifications 2.2 Packing list 2.3 Product schematic diagram 2.4 Display panel information 2.5 Button panel information 3.Operational Instructions 3.1 Handlebar mounting 3.2 Folding and unfolding... -
Page 3: General Information
Before each ride, check that the tires are in good condition, the brake works and that parts such as the clamp and bar handles are securely tightened. It is your sole responsibility to ensure your JOYOR scooter is regularly maintained to ensure it is safe to use. -
Page 4: Safety Precautions
Safety precautions Always wear a helmet when riding the e-scooter and comply with Local Laws. Wear safety helmets and protective gears which have been through relevant quality verification before driving. Do not ride on wet ground or in rain; Take corners slowly and look out for pedestrians; Avoid potholes, curbs, and debris on the ground;... -
Page 5: Strict Prohibitions
Strict prohibitions Prohibit using the e-scooter in areas where entry is prohibited by law in the country, region, state, or city; Prohibit one hand or both hands from leaving the handlebars; Avoid riding in the risky area where does not meet the requirements of the usage;... -
Page 6: Pre-Ride Checks
Pre-ride checks Before each and every ride, always: 1. Check your brakes’ function; 2. Check tires for the correct pressure and any signs of wear or damage. Make sure that the wheels are freely rotating and not obstructed by the brake pads;... -
Page 7: Product Introduction
2. Product Introduction Product specifications Model Max Load 120Kg Max Speed 25km/h limited 40km/h Max Gradeability 20° Max Range 35-40Km Frame Magnesium alloy Tyre size 10 in. Tyre type Air tire Brake Front & rear disk brakes Net weight 19.5kg Size unfolded 1160*620*1220mm Size folded... -
Page 8: Packing List
Packing list M5, 12mm, 4pcs Hexagon socket countersunk Allen wrench set head cap screws Product schematic diagram 1. Rear brake lever 5. Front brake lever 2. Button panel 6. Throttle 3. Handle Grip 7. Display bracket 4. Multi-function display 8. NFC keys... - Page 9 Body frame 1. Folding lever 11. Front turning light 2. Head light 12. Kickstand 3. Front suspension 13. Charging port 4. Front fender 14. Side light stripe 5. Reflector 15. Battery lock 6. Front brake 16. Battery cover handle 7. Front tire 17.
-
Page 10: Display Panel Information
Display panel information Home Screen 1. Error code display 6. Starting mode 2. Power gear display 7. Single/dual drive riding 3. Speed Display 8. Lighting 4. Cruise 9. 6km/h boost mode 5. Battery display 10. Multifunctional display... -
Page 11: Button Panel Information
Home screen description NFC Keys: When you use the key for the first time,Press and hold for 3s to turn on the power and apply the key to the display within 15s, you have successfully activate the keys.the key is valid within 72h if not been swithched of by button. - Page 12 Introduction to key functions Button Operation Function Turn on/off dual drive Press and hold mode. (Only works for electric for 3 seconds scooters with two motors) In the main interface, increase the Short press gear. In the main interface, start the Press and hold push function (need to be in 1-3 for 3 seconds...
- Page 13 Function menu settings Press for 3S to enter the setting interface or return to the main interface. Short press to switch setting options. After setting, long press to return to the main interface.Parameter setting and definition P02: Mileage unit After entering the setting interface, then press to switch to P02: press to select 0 (MILE-default) or 1 (KM).
- Page 14 P12: Strength setting Range: 0 to 5. After entering the setting interface, then press to switch to P12: press to select the strength (Default: 5). P15: Motor drive signal percentage Range: 1 to 100. After entering the setting interface, then press to switch to P15: press to select the percentage (Default: 100).
- Page 15 Error Codes The number corresponding to the multi-function area represents the corresponding fault content. The specific status is as follows: Error Definition Code ERRO 1 Rear motor hall sensor malfunction ERRO 2 Accelerator throttle malfunctio ERRO 3 Rear drive controller malfunction ERRO 4 Brake malfunction ERRO 5...
-
Page 16: Operational Instructions
3. Operational Instructions Handlebar mounting Use the Allen wrench M5 to Pre-tighten the four M5 screws first, then one each on the left and right in turn,until all 4 screws are tightened, the handlebar doesn't wobble. Folding and unfolding 1.Release the Folding Retaining Handle Release the safety catch by pressing the left button inward then gently release it. -
Page 17: Battery Removal And Assembly
2.Fold the handlebar and fix in the hook Gently lower the folding handle, tilt the riser slowly toward the back side, and snap the buckle to the hook Battery removal and assembly Removal: Insert the key into the hole at the rear end of the footrest, lift the cover handle and remove the battery. -
Page 18: Battery Charging
• When charging the battery, place it in a dry, ventilated environment. C10 charger: 54.6V: Input 100-240V ~, 2.8A (MAX) 50 / 60Hz; Output 54.6V = 2.0A; The dedicated charger provided by Joyor has a charging protection timing function. WARNING: For the purposes of recharging the battery, only use the... -
Page 19: Battery Information
Battery information • Joyor electric scooter is equipped with a lithium polymer battery. The average lifespan of the battery is 1000 cycles. Under normal use and maintenance, the battery lifespan can generally reach more than 1000 cycles. • Before using the scooter for the first time, please charge the battery to the full charge. -
Page 20: General Recommendations
• Always use only the original Joyor charger that corresponds to the model of the scooter. • Do not leave your electric scooter in the cold temperature below 0 or under the direct sun. Keep the battery dry. Negative environmental conditions can damage the battery. -
Page 21: Daily Care And Maintenance
5. Daily Care and Maintenance Cleaning and storeage After a long ride, you need to clean it to ensure that the electric scooter works well. • Turn the scooter before cleaning. • Wipe with a dry cloth. • Avoid contact with liquids. •... - Page 22 hechongyyds@sina.com...
