Fiat Strada 2024 Replacement Manual

Fiat Strada 2024 Replacement Manual

Pickup (178 series) – how to change spark plugs, front wheel bearing, engine oil and filter, fuel filter, air filter, rear wheel bearing
Hide thumbs

Advertisement

Quick Links

Download this manual
How to change spark
plugs on FIAT Strada
Pickup (178_) –
replacement guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Strada 2024 and is the answer not in the manual?

Questions and answers

Related Manuals for Fiat Strada 2024

Summary of Contents for Fiat Strada 2024

  • Page 1 How to change spark plugs on FIAT Strada Pickup (178_) – replacement guide...
  • Page 2 Important! This replacement procedure can be used for: FIAT Strada Pickup (178_) 1.4, FIAT Strada Pickup (178_) 1.2 The steps may slightly vary depending on the car design. This tutorial was created based on the replacement procedure for a similar car part on: FIAT PUNTO (188) 1.2 60...
  • Page 3 REPLACEMENT: SPARK PLUGS – FIAT STRADA PICKUP (178_). LIST OF THE TOOLS YOU'LL NEED: High-temperature anti-seize lubricant Torque wrench Drive socket # 10 Crow bar Drive socket # 16 Flat Screwdriver Spark plug socket # 16 Microfibre towel Ratchet wrench...
  • Page 4 Replacement: spark plugs – FIAT Strada Pickup (178_). Tip from AUTODOC: The replacement procedure is the same for all spark plugs. All work should be done with the engine stopped. REPLACEMENT: SPARK PLUGS – FIAT STRADA PICKUP (178_). TAKE THE FOLLOWING STEPS: Open the hood.
  • Page 5 Remove the air filter housing. Cover the throttle body with a microfibre towel to prevent dust and dirt from getting into the system. Detach the crankcase ventilation hose from the engine cover at the left. Use a crowbar. Detach the throttle valve connectors. Use a crowbar. Remove the spark plug wire connectors from the spark plug wells.
  • Page 6 Replacement: spark plugs – FIAT Strada Pickup (178_). AUTODOC recommends: Be careful to avoid damaging spark plug wires. Remember the sequence of the spark plug wires connectors. Clean dirt, dust and debris from inside the spark plug wells. Unscrew the spark plugs. Use the spark plug socket #16. Use a ratchet wrench.
  • Page 7 Screw new spark plugs and tighten them. Use the spark plug socket #16. Use a torque wrench. Tighten it to 27 nm torque. Replacement: spark plugs – FIAT Strada Pickup (178_). Professionals recommend: Don't tighten the plugs with excessive force. Exceeding tightening torque can damage the thread connection.
  • Page 8 Install the spark plug wire connectors into the spark plug wells. Make sure you hear a click indicating that it is locked in place. AUTODOC recommends: Replacement: spark plugs – FIAT Strada Pickup (178_). Follow the installation steps. Attach the throttle valve connectors.
  • Page 9 Attach the crankcase ventilation hose to the engine cover at the left. Remove the microfibre towel from the throttle body. Reinstall the air filter housing. AUTODOC recommends: Make sure the air filter body is properly seated. It should not be displaced with respect to the air intake hose of the throttle body and the guiding fasteners.
  • Page 10 Screw the filter housing fastening bolts. Use a drive socket #10. Use a ratchet wrench. Install the air filter housing retaining spring. Run the engine for a few minutes. This is necessary in order to make sure that the component operates properly. Shut off the engine.
  • Page 11 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR SPARK PLUGS: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
  • Page 12 How to change front wheel bearing on FIAT Strada Pickup (178_) – replacement guide...
  • Page 13 Important! This replacement procedure can be used for: FIAT Strada Pickup (178_) 1.9 JTD, FIAT Strada Pickup (178_) 1.3 D Multijet The steps may slightly vary depending on the car design. This tutorial was created based on the replacement procedure for a similar car part on: FIAT PUNTO (188) 1.3 JTD 16V...
  • Page 14 REPLACEMENT: WHEEL BEARING – FIAT STRADA PICKUP (178_). TOOLS YOU'LL NEED: Wire brush Ratchet wrench WD-40 spray Torque wrench Copper grease Flat screwdriver Combination spanner №13 Tap wrench Combination spanner №16 Hammer Drive socket # 10 Flat chisel Drive socket # 12...
  • Page 15 Replacement: wheel bearing – FIAT Strada Pickup (178_). AUTODOC recommends: Do not re-use the bearing assembly of your FIAT Strada Pickup (178_) car. The wheel hub bearing replacement procedure is identical for both wheels on the same axle. All work should be done with the engine stopped.
  • Page 16 Remove the wheel. Unscrew the brake caliper bracket fasteners. Use a drive socket #17. Use a ratchet wrench. Use a tap wrench. Remove the brake caliper together with its bracket. 4–13 CLUB.AUTODOC.CO.UK...
  • Page 17 Replacement: wheel bearing – FIAT Strada Pickup (178_). Professionals recommend: Tie the caliper to the suspension or to the body with a wire without disconnecting from the brake hose to prevent depressurization of the brake system. Make sure that the brake caliper is not hanging on the brake hose.
  • Page 18 Remove the brake disc. Unstake the wheel hub retaining nut. Use a flat metal-working chisel. Use a hammer. Unscrew the wheel hub fastening nut. Use a drive socket #36. Unscrew the end fastening nut to the steering knuckle. Use a drive socket #17. Use a ratchet wrench. Disconnect the tie rod end from the steering knuckle.
  • Page 19 Unscrew the lower fastener of the shock absorber strut. Use a combination spanner #17. Use a drive socket #17. Use a ratchet wrench. Unscrew the ball joint fastening to the steering knuckle. Use a combination spanner #13. Use a drive socket #13. Use a ratchet wrench.
  • Page 20 Remove the steering knuckle together with the hub. Press the wheel hub out from the tapered roller bearing. Use a hammer. Remove the retaining ring from the steering knuckle. Use a flat screwdriver. Press out the wheel hub bearing. Press the new bearing in the steering knuckle. Install the retaining ring in the steering knuckle.
  • Page 21 Press the wheel hub into the bearing inner race. Install the steering knuckle with a hub in assembly. Install the fastening bolts. Use a crowbar. Install the drive shaft into the wheel hub. Tighten the lower fasteners connecting the shock strut to the steering knuckle. Use a combination spanner #17. Use a drive socket #17.
  • Page 22 Screw the hub nut. Use a drive socket #36. Use a tap wrench. Restake the wheel hub retaining nut. Use a pin punch. Use a hammer. Install the brake disc and secure it. Use a drive socket #12. Use a ratchet wrench. Install the brake caliper together with its bracket.
  • Page 23 Tighten the brake caliper bracket fasteners. Use a drive socket #12. 39.2 Use a torque wrench. Observe the recommended tightening torque. 39.3 Connect the brake hose fastener to the shock absorber strut. Connect the tie rod end to the steering knuckle and tighten it. Use a drive socket #17. Use a torque wrench. Tighten it to 40 Nm torque.
  • Page 24 Install the wheel. Replacement: wheel bearing – FIAT Strada Pickup (178_). Tip from AUTODOC: To avoid injury, hold up the wheel when screwing in the fastening bolts. Screw in the wheel bolts. Use wheel impact socket #17. Lower the car and working in a cross order, tighten the wheel bolts. Use a torque wrench. Tighten it to 98 nm torque.
  • Page 25 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR WHEEL BEARING: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
  • Page 26 How to change engine oil and filter on FIAT Strada Pickup (178_) – replacement guide...
  • Page 27 This replacement procedure can be used for: FIAT Strada Pickup (178_) 1.2 The steps may slightly vary depending on the car design. This tutorial was created based on the replacement procedure for a similar car part on: FIAT 500 Hatchback (312) 1.4 1–12 CLUB.AUTODOC.CO.UK...
  • Page 28 REPLACEMENT: ENGINE OIL AND FILTER – FIAT STRADA PICKUP (178_). TOOLS YOU'LL NEED: All-purpose cleaning spray Torque wrench Combination spanner #13 Flat Screwdriver Drive socket # 10 Funnel Drive socket # 13 Oil drain pan Drive socket # 27 Microfibre towel...
  • Page 29 Unscrew the oil filler plug. Lift the car using a jack or place it over an inspection pit. Replacement: engine oil and filter – FIAT Strada Pickup (178_). AUTODOC recommends: The vehicle must be on even keel, and if it is at an angle, the drain plug must be at the lowest point.
  • Page 30 Clean the area of the oil pan drainage hole. Use all-purpose cleaning spray. Unscrew the drain plug. Use a combination spanner #13. Drain the used oil. Replacement: engine oil and filter – FIAT Strada Pickup (178_). Tip: Caution! The oil may be hot.
  • Page 31 Clean the oil filter housing cap. Use all-purpose cleaning spray. Unscrew the filter housing cap together with the old filter element. Use a drive socket #27. Use a ratchet wrench. Prepare a container for the old oil filter. Put the old oil filter in the container. AUTODOC recommends: Move up the container.
  • Page 32 Cover the oil filter housing with a microfibre towel to prevent dirt and foreign objects from getting into the system. Detach the oil filter from the filter cover. Clean the oil filter housing cap. Use all-purpose cleaning spray. Remove the oil filter cover O-ring. Use a flat screwdriver. Install a new O-ring to its mounting seat on the filter cover.
  • Page 33 Install the new oil filter to the mounting seat on the filter cover. Please note! Make sure to install the filter correctly. Don't mix up the sides of the part. Wait until the oil has completely drained from the drainage hole. Clean the area of the oil pan drainage hole.
  • Page 34 Clean the area of the oil pan drainage hole. Use all-purpose cleaning spray. Install the lower sound insulation. Screw in the fasteners of the lower sound insulation. Use a drive socket #10. Use a ratchet wrench. Lower the car. Remove the microfibre towel from the oil filter housing. Lubricate the rubber seal of the new filter with a little amount of fresh oil.
  • Page 35 Remove the oil filler cap. Insert the funnel. Pour new oil into the engine in the amount recommended by the car manufacturer. Replacement: engine oil and filter – FIAT Strada Pickup (178_). Professionals recommend: Use the oil recommended by the manufacturer.
  • Page 36 Check the oil level using the dipstick. Top up oil if necessary. Please note! The oil level should be between the Min and Max marks. Tighten the oil filler cap. Run the engine for a few minutes. After the oil pressure warning light goes out, stop the engine. Check the oil level 5 minutes after the stop of the engine operation using a dipstick and add oil if necessary.
  • Page 37 If necessary, carefully tighten them up. Remove the fender protection cover. Close the hood. Replacement: engine oil and filter – FIAT Strada Pickup (178_). Tip from AUTODOC experts: Note that oil pressure warning light, which indicates insufficient pressure in the lubrication system, may be on for a longer time than usual.
  • Page 38 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR OIL FILTER: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
  • Page 39 How to change fuel filter on FIAT Strada Pickup (178) – replacement guide...
  • Page 40 FIAT Strada Pickup (178) 1.3 D Multijet The steps may slightly vary depending on the car design. This tutorial was created based on the replacement procedure for a similar car part on: FIAT Doblo I Cargo (223) 1.3 D Multijet 1–8 CLUB.AUTODOC.CO.UK...
  • Page 41 REPLACEMENT: FUEL FILTER – FIAT STRADA PICKUP (178). TOOLS YOU NEED: Electronic spray Fender cover Fluid container Buy tools 2–8 CLUB.AUTODOC.CO.UK...
  • Page 42 Replacement: fuel filter – FIAT Strada Pickup (178). Tip from AUTODOC experts: Ensure adequate ventilation of the workplace. Fuel vapors are poisonous. Warning! Shut down the engine before starting any work – FIAT Strada Pickup (178) CARRY OUT REPLACEMENT IN THE FOLLOWING ORDER: Open the bonnet.
  • Page 43 Prepare a container for fluids. Unscrew the filter housing cap together with the old filter element. Put the old filter cartridge in the container. Remove the rubber strip. Take the fuel filter out of the bracket. Fasten the fuel filter in the holder. 4–8 CLUB.AUTODOC.CO.UK...
  • Page 44 Install the rubber strip. Install a new fuel filter. Replacement: fuel filter – FIAT Strada Pickup (178). AUTODOC recommends: Make sure that the fuel filter is positioned correctly. Consider the fuel flow direction mark. During installation, take care to prevent dust and dirt from getting into the fuel filter housing.
  • Page 45 Clean the connector of the fuel pressure sensor. Use electronic spray. Attach the fuel pressure sensor connector. AUTODOC recommends: Before starting off, switch the ignition on and off several times. This should be done to activate the fuel pump to make it pump fuel through the fuel system. Run the engine for a few minutes.
  • Page 46 Replacement: fuel filter – FIAT Strada Pickup (178). AUTODOC recommends: To protect the environment from pollution, be sure to dispose of the used filters at special collection points. WELL DONE! VIEW MORE TUTORIALS 7–8 CLUB.AUTODOC.CO.UK...
  • Page 47 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR FUEL FILTER: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
  • Page 48 How to change air filter on FIAT Strada Pickup (178) – replacement guide...
  • Page 49 FIAT Strada Pickup (178) 1.3 D Multijet The steps may slightly vary depending on the car design. This tutorial was created based on the replacement procedure for a similar car part on: FIAT Doblo I Cargo (223) 1.3 D Multijet 1–6 CLUB.AUTODOC.CO.UK...
  • Page 50 REPLACEMENT: AIR FILTER – FIAT STRADA PICKUP (178). LIST OF THE TOOLS YOU'LL NEED: Drive socket # 8 Microfibre towel Ratchet wrench Fender cover Buy tools 2–6 CLUB.AUTODOC.CO.UK...
  • Page 51 Replacement: air filter – FIAT Strada Pickup (178). Tip from AUTODOC experts: Follow the terms, recommendations and requirements of the part operation provided by the manufacturer. All work should be done with the engine stopped. REPLACEMENT: AIR FILTER – FIAT STRADA PICKUP (178).
  • Page 52 Remove the filter element from the filter housing. Clean the air filter cover and housing. Replacement: air filter – FIAT Strada Pickup (178). Tip: Before cleaning the air filter cover and housing, cover the air duct parts, mass airflow sensor (if available), throttle valve with a clean cloth.
  • Page 53 Check out the correct location of the filter element. Do not skew. FIAT Strada Pickup (178) – It's important to only use high-quality filters. During installation, make sure to prevent dust and dirt from getting into the air filter housing.
  • Page 54 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR AIR FILTER: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
  • Page 55 How to change rear wheel bearing on FIAT Strada Pickup (178) – replacement guide...
  • Page 56 Important! This replacement procedure can be used for: FIAT Strada Pickup (178) 1.2, FIAT Strada Pickup (178) 1.7 TD, FIAT Strada Pickup (178) 1.9 D, FIAT Strada Pickup (178) 1.9 JTD The steps may slightly vary depending on the car design.
  • Page 57 REPLACEMENT: WHEEL BEARING – FIAT STRADA PICKUP (178). TOOLS YOU MIGHT NEED: Wire brush Ratchet wrench WD-40 spray Torque wrench All-purpose cleaning spray Hammer Copper grease Tap wrench Drive socket # 12 Rubber mallet Drive socket # 32 Crow bar...
  • Page 58 The wheel hub bearing replacement procedure is identical for both wheels on the same axle. Please note: all work on the car – FIAT Strada Pickup (178) – should be done with the engine switched off. CARRY OUT REPLACEMENT IN THE FOLLOWING ORDER: Secure the wheels with chocks.
  • Page 59 Unscrew the wheel bolts. AUTODOC recommends: Important! Hold the wheel while unscrewing the fastening bolts. FIAT Strada Pickup (178) Remove the wheel. Clean the brake drum. Use a wire brush. Use WD-40 spray. Unscrew the brake drum fastening. Use a drive socket #12. Use a ratchet wrench.
  • Page 60 Remove the brake drum. Replacement: wheel bearing – FIAT Strada Pickup (178). Tip from AUTODOC experts: Examine the brake drum. Replace it if necessary. Remove the hub bearing protection cap. Use a crowbar. Use a hammer. Replacement: wheel bearing – FIAT Strada Pickup (178). AUTODOC experts recommend: Some cars are not equipped with wheel hub caps.
  • Page 61 Install the new wheel hub with a bearing. Tighten the hub. Use a drive socket #32. Use a torque wrench. Tighten it to 280 nm torque. Replacement: wheel bearing – FIAT Strada Pickup (178). Tip: The wheel bearing unit must not tilt on the axle pin.
  • Page 62 Install the hub bearing protection cap. Use a rubber mallet. Treat the hub where it contacts the brake disk. Use copper grease. Install the brake drum and fasten it. Tigten the brake drum fasteners. Use a drive socket #12. Use a torque wrench. Tighten it to 15 Nm torque. Clean the wheel rim mounting seat.
  • Page 63 AUTODOC recommends: Warning! To avoid injury, hold the wheel while screwing in the fastening bolts on the car. FIAT Strada Pickup (178) Screw in the wheel bolts. Use wheel impact socket #19. Lower the car and working in a cross order, tighten the wheel bolts. Use a torque wrench. Tighten it to 86 nm torque.
  • Page 64 Remove the jacks and chocks. WELL DONE! VIEW MORE TUTORIALS 9–10 CLUB.AUTODOC.CO.UK...
  • Page 65 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR WHEEL BEARING: A WIDE SELECTION DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
