Table of Contents

Advertisement

Quick Links

Download this manual
F
I
A
T
5
0
0
X
ENGLISH
O
W
N
E
R
H
A
N
D
B
O
O
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500X 2024 and is the answer not in the manual?

Questions and answers

Related Manuals for Fiat 500X 2024

Summary of Contents for Fiat 500X 2024

  • Page 1 ENGLISH...
  • Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format. ONLINE VEHICLE OWNER HANDBOOK The following symbol ...
  • Page 3 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate and the detail of the terms and conditions for maintaining its validity.
  • Page 4 If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), contact a Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle's electric system can support the required load.
  • Page 5 to minimise the risk of cyber-attacks or the installation of viruses or malware which could compromise the performance of the car and/or allow stealing of personal data of the buyers and/or users and/or unauthorised dissemination of said information. The car's purchaser must not remove, modify or tamper with these anti-hacking security devices. The Manufacturer will therefore not be liable for negative consequences and/or damage to the vehicle and/or to the buyer and/or to third parties deriving from the removal, modification or alteration of the security devices performed by the car's purchaser and/or user.
  • Page 6 SYMBOLS Some car components have coloured labels whose symbols indicate precautions to be observed when using this component. A plate summarising these symbols can also be found under the bonnet. J0A2300C...
  • Page 7 If after buying the car, you decide to install electrical accessories that require a permanent electrical supply (e.g. satellite anti- theft system, etc.) or accessories that influence the electrical supply requirements, contact a Fiat Dealership. Their personnel will check whether the electrical system of the car is able to withstand the load required or needs to be integrated with a more powerful battery.
  • Page 8 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be understood as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your car.
  • Page 9 GETTING TO KNOW YOUR CAR KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS MULTIMEDIA CONTENTS...

  • Page 11: Table Of Contents

    THE KEYS........11 The handbook that you are reading IGNITION DEVICE ......14 simply and directly explains how it is FIAT CODE........16 made and how it works. ALARM ........17 That’s why we advise you to read DOORS ........18 it seated comfortably on board, so SEATS........

  • Page 12: Dashboard

    DASHBOARD   F1B0755 1. Adjustable side air diffusers 2. Left stalk: direction indicators, main beam headlights, flashing, Lane change function 3. Instrument cluster 4. Steering wheel controls: Cruise Control (where provided), Speed Limiter (where provided) 5. Right stalk: windscreen wiper/washer, rear window wiper/washer, rain sensor sensitivity level setting 6. Uconnect™ 7. Start&Stop, Auto OFF, hazard warning lights, passenger airbag LED status 8.

  • Page 13: The Keys

    OPERATION Door and boot locking metal insert. Unlocking doors and boot Briefly press the or "FIAT" button Briefly press the button (based on (depending on the type of key): locking the type of key): unlocking of doors and ELECTRONIC KEY...
  • Page 14 (where provided). The doors will be If, when 90 seconds have passed, locked if the tailgate is open however. the button is pressed, the main For cars with electronic keys , if one or beam headlights and the side/tail lights more doors are open, the doors are will stay on for a further 30 seconds.
  • Page 15 possible to use the flat part of the WARNING The battery replacement screwdriver supplied with the car) operation must be carried out with remove the battery (B) fig. 9 (CR2032 care, in order not to damage the type) electronic key. Version (B) To replace the battery, proceed as follows:...

  • Page 16: Ignition Device

    Fiat Dealership, taking an ID document and the car ownership documents. IMPORTANT 1) Used batteries may be harmful to the environment if not disposed of correctly.
  • Page 17 “Knowing the instrument panel” chapter, where available, and contact F1B0014C WARNING the Fiat Dealership as soon as possible. For more information on the engine The ignition device has the following 3) If the ignition device has been tampered...

  • Page 18: Fiat Code

    WARNINGS the car's doors are locked or unlocked. the parking brake, steer the wheels, put Do not tamper with the Fiat Code the gear lever in P (Park) and turn press When the ignition device is set to MAR, the ignition device to set it the STOP system.

  • Page 19: Alarm

    (where provided) and enables door locking. TURNING THE ALARM WARNING The engine immobiliser With the alarm on, warning light (A) function is ensured by the Fiat Code fig. 15 flashes on the instrument panel. Press the button. The following system, which is automatically...

  • Page 20: Doors

    With the doors closed, press the vehicle is valid, the owner of the key F1B0024C "FIAT" button on the key or fit and can simply grasp one of the front handles to deactivate the alarm and...
  • Page 21 unlock the door and tailgate opening Driver side door emergency mechanism. opening Where the function is provided, If the electronic key does not function grasping the handle of the driver's (for example if its battery is discharged) door unlocks the driver's side door or if the conventional car battery is or all doors depending on the mode discharged, it is possible to use the...
  • Page 22 the doors were closed by pressing detected inside when it is locked, the tailgate will unlock again and the lights the button in the inner door panel flash twice. a valid electronic key is detected inside the car and, outside the car, no other electronic key is detected WARNING Before driving make sure The car will not unlock the doors...
  • Page 23 The device is activated on all doors by or even fatally, injure themselves. Also ensure that children do not inadvertently pressing the "FIAT" button on the operate the electric parking brake, the key with remote control or for vehicles brake pedal or the automatic transmission with Keyless Entry / Keyless Go lever.

  • Page 24: Seats

    Backrest angle adjustment the doors by using the metal insert in the Use lever (C) to adjust the backrest electronic key (see description on the following pages). angle, accompanying it with the movement of the torso (operate the lever until the desired position is SEATS reached, then release it).
  • Page 25 seats is immediately blocked when the Auto On Comfort car is locked from the outside. (where provided) The electric heated driver seat FRONT SEAT ELECTRIC is switched on automatically to HEATING "maximum heating" whenever the (where provided) engine is started and the outside With ignition device at MAR, press temperature is lower than 4.4°C.
  • Page 26 completely lower the rear seat head operate release devices (A) fig. 30 forward, in the event of sharp braking, with restraints; to fold both the right and left backrest possible impact with the passengers. move the seat belt to the side, sections.

  • Page 27: Head Restraints

    HEAD RESTRAINTS Upward adjustment: raise the head raise the head restraint to its restraint until it clicks into place. maximum height; FRONT press the button (A) and the device (B) fig. 31 (front head restraints) or (A) and (B) fig. 33 (rear head restraints) Adjustment on the side of the two supports, then They can be adjusted to 4 height...

  • Page 28: Steering Wheel

    STEERING WHEEL The electrochromic mirror has an performance and safety, invalidate ON/OFF button to activate/deactivate the warranty and also result in non- compliance of the car with type-approval 16) 17) the electrochromic anti-glare function. requirements. ADJUSTMENTS The steering wheel can be adjusted REAR-VIEW both in height and axially.
  • Page 29 position 2: right mirror selected; extracted, for cars equipped with to the driving position using the same mechanical key with remote control). device. When one of the front doors is opened Function activation/deactivation this operation is disabled. using the Uconnect™ system The rear-view mirrors fold automatically (where provided) when the doors are locked.

  • Page 30: External Lights

    (heated rear window) activates door The external lights, except for the Function deactivation mirror demisting/defrosting. side lights, can only be switched on To deactivate the function, turn the when the ignition device is at MAR. light switch ring to a position other than The instrument panel and the various AUTO.
  • Page 31 With fog lights on, the warning light Press the button to turn on the rear the left stalk to headlight flashing mode: on the instrument panel will switch on. fog light with side lights and fog lights the headlight off delay is activated for 30 seconds.
  • Page 32 Deactivation reset: return the lever to the central position and push it again towards the If the function is activated by using the dashboard. left steering wheel stalk, the function can be deactivated by holding the left When the speed is over 40 km/h and lever in "main beam flashing"...
  • Page 33 WARNING Check the headlight non-stable position for less than half a Contact a Fiat Dealership to have the alignment each time the weight of the second. headlights checked and adjusted.
  • Page 34 ADJUSTING THE HEADLIGHTS WHEN ABROAD For halogen dipped beam headlights only LED dipped beam headlights do not require masking. Dipped beam headlights are adjusted for driving in the country where the car was originally purchased. When travelling in countries with F1B0681 F1B0684 opposite driving direction, to avoid...

  • Page 35: Interior Lights

    INTERIOR LIGHTS automatically about 15 minutes after Versions with soft top the engine has been switched off. On versions with a soft top, there are FRONT CEILING LIGHT two ceiling lights A (A) fig. 48 located Switch (A) fig. 46 is used to switch above the rear doors, just behind the Ceiling light timing on/off the ceiling light bulbs.

  • Page 36: Windscreen Wiper/Rear Window Wiper

    The ceiling light switches on and off increases, the time between two regardless of the position of the ignition strokes decreases. In position LO or HI, the windscreen wiper moves device. continuously, i.e. without a pause between two strokes. Smart washing function Pull the stalk towards the steering wheel (unstable position) to operate the windscreen washer.
  • Page 37 AUTOMATIC WIPING the windscreen in accordance with the time of the sensor or until the device is amount of water on the screen. reset. Activation The rain sensor will be activated when The automatic wiping can be chosen Inhibition the ignition device is turned to MAR. If by the driver by selecting the rain Moving the ignition device to the STOP no rain is detected, the wiper will not...
  • Page 38 the automatic windscreen wiping with the blades in a position other wiper makes one stroke for each two mode. than rest position (at the base of the strokes of the windscreen wiper; windscreen), they will only return to rest single stroke: with the selector in the Deactivation position following a command given position, the windscreen wiper is on...
  • Page 39 If operation is not restored (even after turning the key and restarting the engine), contact a Fiat Dealership. 8) Do not operate the windscreen wiper with the blades lifted from the windscreen.

  • Page 40: Climate Control System

    CLIMATE CONTROL SYSTEM MANUAL AIR CONDITIONER/ HEATER F1B0052C...
  • Page 41 A - fan activation/adjustment knob: off). This logic guarantees optimum be activated and deactivated using the visibility at the windows. The driver can Uconnect™ system Menu. 0 = fan off always set air recirculation and climate = fan speed (7 different speeds Start&Stop control system compressor.
  • Page 42 In winter, the climate control system must be turned on at least once a month for about 10 minutes. Before summer, have the system checked at a Fiat Dealership. IMPORTANT 3) The system uses R1234yf coolant, which does not pollute the environment in the event of accidental leakage.
  • Page 43 AUTOMATIC DUAL-ZONE CLIMATE CONTROL SYSTEM F1B0051C...
  • Page 44 A - driver side temperature adjustment Air distribution selection In AUTO mode, the climate control knob; system automatically manages air Air flow to the windscreen B - internal air recirculation on/off and front side window vents to distribution (the LEDs on buttons H are off).
  • Page 45 Start&Stop position of the windscreen wiper compressor and engine coolant pump). blades) and the side windows. It is anyway possible to prioritise the The automatic dual zone climate control system manages the operation of the climate control system, The climate control system carries out deactivating the Stop&Start system by the following operations: Start&Stop system (engine off when car...

  • Page 46: Electric Windows

    heater will not activate if the battery position. The rear door windows can voltage is too low. only be closed in stages. IMPORTANT 4) The system uses R1234yf coolant, which does not pollute the environment F1B0066C in the event of accidental leakage. Under no circumstances use R134a and R12 B: right front window fluids, which are incompatible with the...

  • Page 47: Soft Top

    "in stages". To restore the system to it is advisable to put valuables in the device to prevent accidental operation of correct operation, open the window boot and lock the flap even when the the electric windows from being a hazard for those still on board.
  • Page 48 before the roof stops automatically it is advisable to cover the soft top at about 25 cm to stop it at any with a protective sheet if the car is left intermediate position. parked in the open for a long time do not keep the soft top folded for a Initial condition: from intermediate long time: this could cause folds and...
  • Page 49 once the all opened position has specific soft top products may be been reached, continue to press the used. button until the soft top makes an Leave the car in the shade after automatic run until approx. 25 cm from washing avoiding direct sunlight.

  • Page 50: Bonnet

    24) Keep children away from the soft top 19) Rinse immediately to remove soap area while it is moving. to prevent stains. Repeat the operation if needed. 25) When leaving the car, always remove the key (where provided) from the ignition 20) Follow the instructions on the device to avoid the risk of injury due to waterproofing product container for...

  • Page 51: Boot

    CLOSING lower the head restraints and fold the engaged. If you discover that the bonnet backrests is not perfectly closed while driving, stop immediately and close the bonnet in the Proceed as follows: correct manner. hold the bonnet up with one hand and with the other remove the rod (C) BOOT fig.
  • Page 52 "FIAT" button on the remote control press the button on the remote control LOAD COMPARTMENT...

  • Page 53: Interior Fittings

    INTERIOR FITTINGS the MAR position. To use it, open cap (A) fig. 72. GLOVE COMPARTMENT F1B0080C F1B0735 WARNING F1B0878 WARNING Do not connect devices 30) Be careful not to hit objects on the roof with powers higher than 180W to the SUN VISORS rack when you open the tailgate.

  • Page 54: Roof Rack/Ski Rack

    Refer to the instructions provided by the USB socket condition. the manufacturer of the purchased crossbars for installation. NOTE The USB port handles For further information, contact a Fiat data transmission from the Pen Dealership. Drive/Smartphone, etc. and slow recharging of an external device, which...

  • Page 55: Environmental Protection Systems

    RED SPECIAL IMPORTANT SERIES 23) Never exceed the maximum permitted (where provided) loads (see the "Weights" paragraph in the Some components of the "Technical specifications" chapter). car underwent antimicrobial 24) Fully comply with the regulations in treatments, as detailed below. No force concerning maximum clearance.
  • Page 56 KNOWING THE INSTRUMENT PANEL This section of the handbook provides INSTRUMENT PANEL all information that is useful for getting FEATURES........55 to know, interpreting, and using the DISPLAY ........56 instrument panel correctly. TRIP COMPUTER ......58 EOBD SYSTEM (European On Board Diagnosis) ......

  • Page 57: Instrument Panel Features

    INSTRUMENT PANEL FEATURES   F1B0640 A. Speedometer B. Fuel level digital gauge with reserve warning light C. Display D. Digital engine coolant temperature gauge with overheating warning light E. Rev counter WARNING The illumination of the instrument panel graphics may vary according to version.

  • Page 58: Display

    INSTRUMENT PANEL SHIFT) icon advises the driver to LIGHT ADJUSTMENT engage a lower gear. (brightness sensor) The indication in the display remains (versions with colour display) until a gear is shifted or the driving Versions with colour display are conditions go back to a situation where equipped with a brightness sensor gearshifting is not required to improve (fitted inside the instrument panel)
  • Page 59 OK: press this button to the instrument panel display (for further passenger's protection active: the access/select the info displays or the information see the dedicated chapter). ON comes on constantly in the submenus of an item of the Main The following information is displayed: instrument panel dashboard.

  • Page 60: Trip Computer

    TRIP COMPUTER Average fuel consumption “automatic” resetting, when the “trip distance” reaches 99999.9 km or when This value shows the approximate The "Trip computer" is used to display the “travel time” reaches 999:59 (999 average fuel consumption from the information on car operation when the hours and 59 minutes);...
  • Page 61 This check can also be carried out by the traffic police. WARNING After eliminating the anomaly, to check the system completely, a Fiat Dealership is obliged to run tests and, if necessary, road tests which may also require a long journey.

  • Page 62: Warning Lights And Messages

    Electric parking brake on The warning light switches on when the electric parking brake is engaged. Release the electric parking brake, then check that the warning light has switched off. If the warning light stays on, contact a Fiat Dealership. EBD FAILURE...
  • Page 63 If the warning light (or symbol on the display) remains on, you could not have steering assistance and the effort required to operate the steering wheel could be increased; steering is, however, possible. Contact a Fiat Dealership as soon as possible.
  • Page 64 If the warning light does not switch off, or if it stays on with the engine running, a failure was found on the ESC system. Contact a Fiat Dealership as soon as possible. yellow Hill Hold Control system failure The warning light turns on to indicate a Hill Holder Control system failure. Contact a Fiat Dealership as soon as possible.
  • Page 65 The warning light switches on when the rear fog light is turned on. yellow ELECTRIC PARKING BRAKE FAILURE The warning light switches on when electric parking brake failure is detected. Contact a Fiat Dealership as soon as possible. yellow INJECTION / EOBD SYSTEM FAILURE In normal conditions, when the ignition device is brought to MAR, the warning light switches on, but it should switch off as soon as the engine is started.
  • Page 66 Warning light What it means LANE ASSIST SYSTEM The warning light switches on as follows: Warning light continuously on (white): the system is activated, but the lane limits were not detected (the lane lines are grey). Warning light on and flashing (amber): the car has approached the lane line and is about to pass it. yellow Warning light switched on continuously (green): the system has detected the limits of both lanes.
  • Page 67 Warning light What it means FOG LIGHTS The warning light comes on when the front fog lights are turned on. green LEFT DIRECTION INDICATOR The warning light switches on when the direction indicator stalk is moved downwards or, together with the right direction indicator, when the hazard warning light button is pressed.
  • Page 68 AIRBAG FAILURE If the symbol switches on constantly, this indicates a failure in the airbag system. Contact a Fiat Dealership as soon as possible. BONNET NOT PROPERLY SHUT The symbol switches on when the engine bonnet is not properly shut.
  • Page 69 Dealership. FULL BRAKE CONTROL SYSTEM FAILURE yellow The symbols comes on in the event of a Full Brake Control system failure. Contact a Fiat Dealership as soon as possible. yellow LANE ASSIST SYSTEM FAILURE The symbol comes on in the case of permanent Lane Assist system failure. Contact a Fiat Dealership as yellow soon as possible.
  • Page 70 The symbol switches on to report a failure of the sound system. Contact a Fiat Dealership as soon as possible. yellow DUSK SENSOR FAILURE The symbol switches on in the case of failure of the dusk sensor. Contact a Fiat Dealership as soon as yellow possible. RAIN SENSOR FAILURE The symbol switches on in the case of failure of the rain sensor.
  • Page 71 IMPORTANT In the event of external temperature sensor failure, the digits that indicate the value are yellow replaced by dashes. SPEED LIMITER FAILURE The symbol switches on in the case of failure of the Speed Limiter device. Contact a Fiat Dealership as soon as possible to have the failure eliminated. yellow EXTERNAL LIGHTS FAILURE The symbol switches on to indicate a failure on the following lights: daytime running lights (DRLs);...
  • Page 72 GPF (Gasoline Particulate Filter). yellow Contact a Fiat Dealership as soon as possible. FUEL LEVEL SENSOR FAILURE The symbol switches on in the event of fuel level sensor failure. Contact a Fiat Dealership. yellow DECAYED ENGINE OIL (where provided) The symbol switches on and then disappears from the display when the display cycle is completed.
  • Page 73 30 days before servicing. It is also displayed each time the ignition device is turned to MAR. The display will be in km or miles depending on the unit of measurement set. Go to a Fiat Dealership, where the "Scheduled Servicing Plan" work will be performed and the message will be reset.
  • Page 74   Symbol What it means INTELLIGENT SPEED ASSIST SYSTEM ACTIVATION (where provided) The symbol comes on in the event of a Intelligent Speed Assist system failure. green ELECTRONIC CRUISE CONTROL The symbol comes on in the event of a Cruise Control system failure. green SPEED LIMITER The symbol comes on in the event of a Speed Limiter system failure.
  • Page 75 BLIND SPOT ASSIST continuously. The failed operation of the system might be due to the insufficient voltage from the battery or other failures on the electrical system. Contact a Fiat Dealership as soon as possible to have the electrical system checked.
  • Page 76 In this case, the warning light may not indicate problems with the restraint systems. Before continuing, contact a Fiat Dealership immediately to have the system checked. 35) If a failure is present with sharp braking, the rear wheels may lock and the vehicle may swerve.
  • Page 77 27) If the symbol switches on while driving, stop the engine immediately and contact a Fiat Dealership. 28) Driving the vehicle with this symbol on may severely damage the transmission, with resulting breakage. The oil may also overheat: contact with hot engine or with exhaust components at high temperature could cause fires.
  • Page 78 SAFETY The chapter that you are about to read ACTIVE SAFETY SYSTEMS ... 77 is very important: it describes the safety DRIVING ASSISTANCE systems with which the car is equipped SYSTEMS ........80 and provides instructions on how to OCCUPANT PROTECTION use them correctly.

  • Page 79: Active Safety Systems

    ACTIVE SAFETY ESC (Electronic Stability surface where the grip of the left and right wheels varies, or on corners. Control) SYSTEM SYSTEMS The ESC system improves the The Electronic Braking Force The car has the following active safety Distribution (EBD) system completes directional control and stability of the systems: the system allowing the brake force to...
  • Page 80 TC (Traction Control) that the car is in critical stability and slopes, activating automatically in the SYSTEM grip conditions. following cases: The system automatically operates uphill : car stationary on a road 48) 49) 50) 51) 52) in the event of slipping, loss of grip with a gradient higher than 5%, PBA (Panic Brake on wet roads (aquaplaning) and...
  • Page 81 TSC (Trailer Sway power steering to increase the safety period it is better to avoid sharp, repeated level of the whole car. Control) SYSTEM and prolonged braking. 38) If the ABS system intervenes, this The system employs a series of In critical situations (braking on indicates that the traction of the tyres on surfaces with different grip conditions),...

  • Page 82: Driving Assistance Systems

    in perfect condition and, above all, of the the load correctly to prevent the trailer 55) The capability of the PBA system prescribed type and size. must never be tested irresponsibly from swerving. and dangerously, in such a way as to 47) ESC performance features must not induce the driver to take unnecessary or compromise the safety of the driver, the...
  • Page 83 stationary and the gear lever is in the P (Park) position. The detection area of the system covers about a lane on both sides of the vehicle (around 3 metres). This area starts from the door mirror and extends for about 6 metres towards the rear part of the car.
  • Page 84 If a trailer is connected to the car, to RCP (Rear Cross Path detection) acoustic warnings when the presence avoid false indications this system must of an object is detected. system be manually deactivated using the This system helps the driver during When an acoustic warning is sent, the relative menu.
  • Page 85 The BSA system will store the allow the driver to react promptly, in operating mode running when the order to prevent or reduce the effects of a potential accident. engine was stopped. Each time the engine is started, the operating mode In situations with the risk of collision, if stored previously will be recalled and the system detects no intervention by...
  • Page 86 Engagement / disengagement Activation/deactivation in front when it is close. This setting offers the driver a lower reaction time The Full Brake Control system can be If the Full Brake Control system has compared to the "Med" and "Far" deactivated (and then reactivated) been correctly activated with the settings, in the event of a potential via the Uconnect™...
  • Page 87 Fiat Dealership as soon as possible. vehicles with small dimensions such as snow, rain, mud or other and/or not aligned in the driving lane;...
  • Page 88 Driving close to a bend When entering or leaving a wide bend, the system may detect a car that is in front of you, but that is not driving in the same lane fig. 85. In cases such as these, the system may intervene. F1B0714 F1B0708 Lane change by other vehicles...
  • Page 89 The system has been designed for This warning is displayed also when go to "Vehicle info" and then to road use only. If the car is driven off- turning the engine off and on again until "Reset tyre pressure"; press the "OK" and hold down (more road, the system must be deactivated, the RESET procedure is carried out.
  • Page 90 63) The system is an aid for the driver, warm tyres, do not reduce pressure even adversely affect its operation. Go to a Fiat who must always pay full attention while though it is higher than the prescribed Dealership for any operation of this type.

  • Page 91: Occupant Protection Systems

    All vehicle seats are equipped with seat camera on the windscreen glass. In the SYSTEMS belts with three anchor points and a event of a sensor failure, contact a Fiat Dealership. retractor. Some of the most important safety 37) When towing a trailer (with modules...
  • Page 92 F1B0101C F1B0103C F1B0382C On removal of the belt, if it jams, let it Always adjust the height of the seat IMPORTANT When returning the rear rewind for a short stretch, then pull it belts to fit the person wearing it: this seat from the tilted position to the out again without jerking.

  • Page 93: Sbr (Seat Belt Reminder) System

    NOTE To deactivate the acoustic unfastened, an acoustic warning is indication. warning permanently go to a Fiat activated together with the flashing of Dealership. The acoustic warning can warning light for approximately be reactivated at any time through 105 seconds.
  • Page 94 if the seat belt is unfastened the corresponding icon will appear as shown in (C) (red on the colour display). At speeds under 20 km/h, if a seat belt is unfastened, the respective icon ((A), (B) or (C)) will remain fixed for a total of approximately 65 seconds.

  • Page 95: Pre-Tensioners

    (pedals F1B0108C has been affected by water and/or and steering wheel must be easy to mud, contact a Fiat Dealership to have access). The maximum clearance Each seat belt must be used by only it replaced.

  • Page 96: Child Restraint Systems

    CHILD RESTRAINT WARNING SYSTEMS 78) The pretensioner may be used only CARRYING CHILDREN once. Contact a Fiat Dealership to have it SAFELY replaced after it has been deployed. 82) 83) 84) 85) 79) Removing or otherwise tampering with For optimal protection in the event pretensioner and seat belt components is strictly prohibited.
  • Page 97 in rear facing child seats for as long a rearward facing child restraint system is as possible (at least until 3–4 years fitted. Always comply with the instructions on the passenger side sun visor (see the old), since this is the most protected "Supplementary Restraint System (SRS) - position in the event of an impact.
  • Page 98 All restraint devices must bear the type-approval data, together with the control mark, on a label solidly fixed to the child restraint system which must never be removed. Lineaccessori MOPAR ® includes child restraint systems for each weight group. These devices are recommended having been specifically designed for Fiat vehicles.
  • Page 99 WARNING For correct installation on the car, some universal child restraint systems require an accessory (base) sold separately by the restraint system's producer. Therefore, the Manufacturer advises customers to check that their chosen child restraint system can be installed on their vehicle by performing a trial installation, on the dealer's premises, before purchase.
  • Page 100 INSTALLING A CHILD The child restraint system is restrained In this case, the child restraint system CARSEAT WITH by the vehicle seat belts, as shown in is used to position the child correctly SEATBELTS fig. 98 and it must restrain the child in with respect to the seat belts so that turn with its own belts.
  • Page 101 to the car seat with three anchorages in injured, even fatally. When fitting a restraint the car. system for newborns or children, strictly comply with the instructions provided by Traditional child restraint systems the Manufacturer. can be fitted alongside ISOFIX child 87) When the child restraint system is restraint systems on different seats in not used, secure it with the seat belt or...
  • Page 102 NOTE When a Universal ISOFIX child child restraint system protection restraint system is used, only ECE R44 is increased in the event of a side "ISOFIX Universal" (R44/03 or further collision; upgrades) type-approved child restraint the use of the ISOFIX system is systems can be used fig.
  • Page 103 NOTE See the table shown on the following page to check whether your car is approved for installing i-Size child restraint systems.
  • Page 104 Child restraint system installation   The following table provides guidelines on positioning child restraint systems on the car seats. Each child restraint system position complies with the UNECE standards   Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for rearward facing child restraint systems (U) Seat suitable for forward...
  • Page 105 Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for forward facing fixtures (B2/B3) NO (2) NO (2) (IUF) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal" forward facing child restraint system approved for this weight category. IUF = Position suitable for an "ISOFIX"...
  • Page 106 Child restraint system Type of child restraint system Child restraint system installation BeSafe iZi Go Modular Fiat order code: 71808564 Universal/i-Size child restraint system. It must be installed facing rearwards, using Group 0+: from birth to 13 the car seat belts only, or the dedicated...
  • Page 107 ISOFIX Britax Römer KidFix XP Group 2: from 9 to 18 kg, (for versions/markets, where anchorages of the vehicle, if present. Fiat from 95 cm to 135 cm provided) recommends installing it using the Fiat order code: 71807984 vehicle’s ISOFIX anchor points.
  • Page 108 Britax Römer KidFix XP the three-point seat belt and the ISOFIX Group 3: from 22 to 36 kg (for versions/markets, where anchorages of the vehicle, if present. Fiat from 136 cm to 150 cm provided) recommends installing it using the Fiat order code: 71807984 vehicle’s ISOFIX anchor points.

  • Page 109: Supplementary Restraint System (Srs) - Airbag

    SUPPLEMENTARY Never carry children on your lap, Main recommendations to carry even newborns. No-one can hold a children safely RESTRAINT SYSTEM Install the child restraint systems child in the case of a crash. (SRS) - AIRBAG If the car has been involved in a road on the rear seat, which is the most accident, replace the child restraint protected position in the event of an...
  • Page 110 complementary to the seat belts, which between the dashboard and the should always be worn, as specified by passenger. law in Europe and most non-European The airbags are not deployed in the countries. event of minor frontal impacts (for In a crash, those not wearing a seat which the restraining action of the seat belt are projected forwards and may belts is sufficient).
  • Page 111 F1B0630C Moving the ignition device to MAR switches on the two LEDs for about 8 seconds. If not, contact a Fiat Dealership. During the first seconds, the activation of the LEDs does not actually show the F1B0132C passenger protection status, but only checks its correct operation.
  • Page 112 Passenger's front airbag and child restraint systems: IMPORTANT F1B0129C...
  • Page 113 Fiat Dealership. Side bag If the car is scrapped, have the These comprise two bags located in airbag system deactivated at a Fiat the front seat backrests fig. 113 which Dealership. protect the pelvis, chest and shoulder area of the occupants in the event of a...
  • Page 114 108) The airbag does not replace seat subjected to vandalism or floods, have the instrument panel menu, see the belts but increases their efficiency. the airbag system checked by a Fiat description in the "Knowing the instrument Because front airbags are not deployed Dealership.
  • Page 115 STARTING AND DRIVING We have now reached the "heart" of STARTING THE ENGINE ..... 114 the car: let's see how to use the car to WHEN PARKED ......116 its full potential. ELECTRIC PARKING BRAKE We’ll look at how to drive safely in (EPB) ........

  • Page 116: Starting The Engine

    (or the symbol of the display) remains on, try with the other keys ENGINE provided with the car. Contact a Fiat Before starting the car, adjust the Dealership if the engine still does not seat, the interior rear view mirrors, the start.
  • Page 117 If the engine starts, the vehicle can be speeds above 8 km/h. used as normal, but a Fiat Dealership must 109) Do not try to start the engine pouring To switch off the engine in this be contacted as soon as possible.

  • Page 118: When Parked

    WHEN PARKED ELECTRIC PARKING WARNING Should the car battery be faulty, to unlock the electric parking BRAKE (EPB) Always remove the key from the brake the battery must be replaced. ignition device when leaving the car. The car is equipped with electric The electric parking brake can be When parking and leaving the car, parking brake (EPB) to guarantee...
  • Page 119 The stop lights also automatically indicates a fault: in this case contact a detected, the electric parking brake switch on. Fiat Dealership. will automatically engage to hold the Release the switch on the central WARNING Never use position P (Park) vehicle in safety conditions;...

  • Page 120: Dual Clutch Automatic Transmission

    when the ignition device is in the MAR The gear lever has a button (A) fig. 117 115) The electric parking brake must position. which must be pressed to move the always be engaged when leaving the car. lever to P or R. To select the "sequential"...
  • Page 121 CONTROLS ON THE please wait a few seconds before system goes back to the automatic accelerating. This precaution is mode (D), with following displaying. STEERING WHEEL particularly important with engine cold. (where provided) AUTOSTICK - Sequential AUTOMATIC DRIVING mode On some versions, the transmission MODE In the case of frequent gearshifting (e.g.
  • Page 122 STARTING THE ENGINE WARNING With the electric parking transmission - lever unlocking" in the brake released and brake pedal "In an emergency" chapter. Starting the engine is allowed only when the gear lever is in position P released, engine at idling speed STOPPING THE ENGINE and gear lever in position D, R or or N.

  • Page 123: Start&Stop System

    Stopping the engine stationary, engine at idling speed and accelerator fully released. case, contact a Fiat Dealership. With car at a standstill and brake pedal 47) If the car is on a gradient, always pressed, the engine switches off if the engage the electric parking brake BEFORE gear lever is in a position other than R.
  • Page 124 120) If the battery needs to be replaced, following activation of the MAX-DEF always contact a Fiat Dealership. Replace especially cold external temperature; function; the battery with a new one of the same battery not sufficiently charged;...

  • Page 125: Speed Limiter

    EXCEEDING THE automatically in the event of fault in the 30 km/h. system. In this case, contact a Fiat PROGRAMMED SPEED When the device is active, the car Dealership. By fully depressing the accelerator...

  • Page 126: Electronic Cruise Control

    Limiter, and the second press activates SETTING THE DESIRED activating the system after setting a limit below the effective speed of the the Cruise Control). SPEED car; Proceed as follows: when the device cannot reduce the to activate the device press button speed of the vehicle due to the gradient (A) fig.

  • Page 127: Adaptive Cruise Control (Acc)

    122) In case of a malfunction or failure of the device, contact a Fiat Dealership. RECALLING THE SPEED 123) The electronic Cruise Control can To recall the previously set speed, be dangerous if the system cannot keep press and release the RES button.
  • Page 128 It is advisable to turn the device off in behaviour is due to various conditions the following cases: outside the car (wind, inertia, type of route, etc.), and constitutes normal driving in fog, heavy rain, snow, system operation. heavy traffic and in complex driving WARNING It is dangerous to leave situations (e.g.
  • Page 129 If the accelerator is held down, the In case of system set, the conditions the equivalent in mph). Each touch of device will not be able to control the described above also cause a the button once will reduce the speed distance between the car and the cancellation or deactivation of the by 1 km/h (or the equivalent in mph).
  • Page 130 ACCELERATING WHEN SETTING THE DISTANCE The setting is 4 (maximum) the first OVERTAKING BETWEEN CARS time the device is used. After the When driving with the device active The distance between your car and distance has been modified by the driver, the new distance will be stored and following a vehicle, the device the vehicle ahead may be set to 1 bar...
  • Page 131 Speed Limiter button is pressed; system functions end, this will go back the ignition device is set to STOP. to normal and complete operation. Should the fault persist, contact a Fiat The device is cancelled (the set speed Dealership. and distance are stored): when the CANC button is pressed;...
  • Page 132 WARNING In case of narrow curves, Small vehicles Objects and vehicles moving in the performance of the device could be Some narrow vehicles (e.g. bicycles opposite or crosswise direction limited. In this case, it is advisable to and motorcycles fig. 129) travelling The device cannot detect the presence deactivate the device.

  • Page 133: Park Assist System

    Version with 8 sensors: The parking adversely affect its operation. Go to a Fiat complete safety. The driver must always Dealership for any operation of this type.
  • Page 134 deactivated by the driver, faulty or The system is automatically activated temporarily deactivated. when reverse is engaged. Deactivation The system is automatically deactivated whenever a gear other than reverse is engaged. System on activation/deactivation (versions with 8 sensors) Activation The system, when it is on, is F1B0668 automatically activated in the following conditions:...
  • Page 135 Versions with 4 sensors to contact a Fiat Dealership for the when washing the car, in rain (strong The operation of the sensors is relevant Park Assist system update wind), hail;...

  • Page 136: Lane Assist System (Lane Crossing Warning)

    (A) torque to the steering wheel (vibration), area of the sensors carried out by a Fiat fig. 134, located on the left stalk. thus advising the driver that he must Dealership.

  • Page 137: Traffic Sign Recognition

    In the event of a failure of speed limit indications the camera, contact a Fiat Dealership. hand on the steering wheel; no overtaking 65) Do not cover the operating range of car speed ranges between 60 km/h the camera with stickers or other objects.
  • Page 138 WARNING The system is designed to the additional snow signal will appear read roads signs complying with the if the external temperature is equal to specifications of the Vienna convention or lower than 3°C and the windscreen and ENCAP 2018 requirements. wipers are working the additional rain signal will appear if USE OF THE TRAFFIC...

  • Page 139: Intelligent Speed Assist

    SYSTEM ACTIVATION Traffic Sign Recognition system can 71) Do not tamper or perform any be programmed with these systems To activate the system, press the RES operations in the area of the windscreen glass directly surrounding the sensor. active. (A) fig. 138 button on the steering 72) Clean the windscreen glass from If the speed is higher than the current wheel, to store the speed limit equal to...

  • Page 140: Daa (Driver Attention Assist) System

    DAA (Driver when the Traffic Sign Recognition system cannot display any speed limit. Attention Assist) EXCEEDING THE SYSTEM PROGRAMMED SPEED (where provided) By fully depressing the accelerator This is an auxiliary driving assistance pedal, the programmed speed can be system that detects when the driver is exceeded even with the system active tired.

  • Page 141: Rear View Camera

      If the driver ignores the warning Every time reverse is engaged, the provided by the system and does display fig. 141 shows the area around Distance from the Area not stop, the message will remain on the car, as seen by the rear camera. rear part of the car the instrument panel display until the Red (A)

  • Page 142: Towing Trailers

    in the registration document) account For any version the towing device used cleaning it. Avoid using dry, rough or hard should be taken of the fully laden trailer, must be right for the towable weight of cloths. The camera must be washed using clean water, with the addition of vehicle including accessories and luggage.

  • Page 143: Refuelling The Car

    REFUELLING THE 137) 138) 139) Only use unleaded petrol with an octane number (R.O.N.) not lower than 95 (EN228 specification). WARNING Never introduce leaded petrol to the tank, even in small F1B0719 F1B0725 amounts in an emergency, as this would damage the catalytic converter Fuel - Vehicle Flap A is provided with a dust boot (B) compatibility...

  • Page 144: Driving Tips

    DRIVING TIPS 5.0% (V/V) ethanol compliant with Electric devices EN228 Use electrical devices only for the SAVING FUEL amount of time needed. The heated E10: Unleaded petrol containing up to Below are some suggestions which rear window, windscreen wipers and 3.7% (m/m) oxygen and with maximum may help you save fuel and thus lower heater fan require a considerable...
  • Page 145 For these to leave children in a parked car consumption and emissions. operations, contact a Fiat Dealership. when the temperature outside is very Acceleration high. The heat inside the passenger...
  • Page 146 Warranty Booklet. ENGINE OVERHEATING ..... 166 It is also possible to call the national or international universal freephone DUAL CLUTCH AUTOMATIC number to search for the nearest Fiat TRANSMISSION LEVER RELEASE ......... 166 Dealership. DUAL CLUTCH AUTOMATIC TRANSMISSION - IGNITION KEY EMERGENCY EXTRACTION ......

  • Page 147: Hazard Warning Lights

    HAZARD WARNING BULB extending progressively towards the edges. LIGHTS REPLACEMENT CONTROL 140) 141) 142) 143) Press button fig. 145 to switch the lights on/off. GENERAL When the hazard warning lights are on, INSTRUCTIONS the warning lights flash. Before changing a bulb, check the contacts for oxidation replace blown bulbs with others of the same type and power...
  • Page 148 BULB TYPES   The car is equipped with the following bulbs Glass bulbs (type A): they are press-fitted. Pull to extract. Bayonet-type bulbs (type B): to remove them from their holder, press the bulb and turn it anticlockwise, then extract it. Tubular bulbs (type C): release them from their contacts to remove.
  • Page 149   Figure Light bulbs Type Power reference Front side lights/Daytime running lights (DRL) (halogen) W21W – – Front side lights/Daytime running lights (DRL) (LED) (where provided) – – Rear side/brake light Main beam/dipped beam headlights (halogen) 60/55W – – Main beam/dipped beam headlights (LED) Front direction indicators WY21W Rear direction indicators...
  • Page 150 Figure Light bulbs Type Power reference Boot lights...
  • Page 151 REPLACING AN To replace them, contact a Fiat EXTERNAL BULB Dealership. Main beam/dipped beam Side lights/daytime running lights headlights (halogen) (DRL) (halogen) To replace the bulb, proceed as To replace the bulbs, proceed as follows: follows: working from inside the engine...
  • Page 152 WARNING The procedure is described assembly anticlockwise and then by way of example only. It is advisable remove it sliding it outwards to contact a Fiat Dealership for bulb replace the bayonet-fitted bulb (A) replacement. fig. 149 finally, refit the inspection flap (B) fig.
  • Page 153 Tail lights replaced: anticlockwise for extraction, The tail lights are LED-type. For clockwise for fitting replacing these bulbs, contact a Fiat reposition the bulb holder assembly Dealership. F1B0723 (D) correctly in the headlight body; Brake lights proceed until you hear the tabs click The brake lights are LED-type.
  • Page 154 LED lights remove the lenses (A) fig. 155 working (where provided) in the point For replacing these bulbs, contact a Fiat Dealership. F1B0156C REPLACING AN INTERNAL BULB Front ceiling light To replace the bulbs, proceed as follows: remove the ceiling light (A) fig.
  • Page 155 To replace the bulbs, proceed as lower the support handle and, in the Boot lights follows: direction indicated by the arrow remove To replace the bulb, proceed as ceiling light unit (A) fig. 162 operate in the points indicated by follows: the arrows and remove ceiling light (A) open the boot and extract the ceiling...

  • Page 156: Fuses

    144) Replacement of a fuse. All the jack cannot be repaired and in not interfere with traffic and lets you safely work may be performed only by a Fiat replace them (see the description in the the event of a fault it must be replaced Dealership or a qualified repair workshop.
  • Page 157 stop the car in a position that is not dangerous for oncoming traffic where you can change the wheel safely. The ground must be flat and sufficiently compact; stop the engine, engage the hazard warning lights and the electric parking brake;...
  • Page 158 remove the centring pin and screw the car, next to the symbol on the on the other stud bolts by hand; side member itself; using the wrench (A), screw down all the stud bolts; turn the wrench (A) (anticlockwise) on the hexagonal part of the jack to lower the car, then extract the jack;...
  • Page 159 Fiat Dealership. Never go under the 151) The vehicle's driving characteristics to simplify fitting of the wheel, screw raised vehicle: use it only in the positions...

  • Page 160: Fix&Go Kit

    FIX&GO KIT use only! 80 km/h max!" Replace with standard wheel as soon as possible. DESCRIPTION Never remove or cover the sticker on the (where provided) space-saver wheel. Never apply a wheel cap on a space-saver wheel. The vehicle's 155) 156) 157) 158) 159) 160) 161) 162) driving characteristics will be modified with the space-saver wheel fitted.
  • Page 161 The TireKit comprises: Tyre repair (OPT1 kit) Proceed as follows: (1) fig. 174: pressure gauge (2): instruction label insert the sealant cartridge (1) (3): ON-OFF switch into the corresponding compressor compartment (2)and press it down hard fig. 172. Remove the speed limit sticker (3) and apply it in a clearly visible position fig.
  • Page 162 1.8 bar / 26 psi, restore the pressure compressor, disconnect the sealant and drive safely to a Fiat Dealership tube (4) from the tyre valve and remove as soon as possible. If, however, the the cartridge (1) from the compressor pressure is lower than 1.8 bar / 26 psi,...
  • Page 163 If the pressure gauge fig. 186 indicates activate the compressor setting the a pressure lower than 2.0 bar / not resume driving, but contact a Fiat ON-OFF button, fig. 185, to the on 29 psi 10 minutes after starting Dealership.
  • Page 164 If the pressure shown is higher than REPLACEMENT F0S0788 2.0 bar / 29 psi, restore the pressure (OPT1 kit) and drive safely to a Fiat Dealership Proceed as follows: as soon as possible. If, however, the WARNING only use original Fix&Go cartridges, pressure is lower than 2.0 bar / 29 psi,...

  • Page 165: Run Flat Tyres

    For repair, contact a Fiat Dealership as product. Remember to carefully read the IMPORTANT soon as possible.

  • Page 166: Jump Starting

    JUMP STARTING directly! If the auxiliary battery is installed on another car, check that there is no accidental contact of metal If the battery is flat, a jump starting parts between the two cars, since an can be performed using the battery earth connection may result, with the and the cables of another car, or using risk of serious injury to any people who...

  • Page 167: Fuel Cut-Off System

    172) Do not get too close to the radiator Fiat Dealership. turning on the lights inside the car; cooling fan: the electric fan may start; If it is often necessary to perform a deactivation of climate control danger of injury.

  • Page 168: Engine Overheating

    RESET temperature decreases. If temperature stop the engine; 175) does not decrease, contact a Fiat engage the electric parking brake; To restore correct operation of the Dealership as soon as possible. working carefully in the point vehicle, carry out the following...

  • Page 169: Dual Clutch Automatic Transmission - Ignition Key Emergency Extraction

    DUAL CLUTCH AUTOMATIC TRANSMISSION - IGNITION KEY EMERGENCY EXTRACTION The ignition key (for versions with F1B0759 F1B0022C key without remote control) can be removed only if the gear lever is in depress the brake pedal and keep it position P (Park). fully depressed;...
  • Page 170 (C) fig. 195, make sure it locks correctly and fully tighten the fixing screws (B). IMPORTANT 80) It is advisable to contact a Fiat Dealership to have the refitting procedure carried out. If you would like to proceed autonomously, special attention must...

  • Page 171: Towing A Broken-Down Car

    TOWING A BROKEN-DOWN CAR The procedures for towing a broken-down car with a tow truck are described below. It is recommended to tow the car with all four wheels lifted from the ground on the platform of a roadside assistance car.  ...

  • Page 172: Towing The Car

    WARNING A suitable towing or lifting WARNING Avoid lifting the front (or equipment is necessary for towing, in rear) wheels only. Lifting the front (or order to avoid damage to the car. rear) wheels only while towing might damage the transmission or the transfer unit.
  • Page 173 177) The brake servo and the electromechanical power steering will not work while the vehicle is being towed. You will therefore need to apply more force on the brake pedal and steering wheel. Do not use flexible ropes when towing, and avoid jerky movements.
  • Page 174 SERVICING AND MAINTENANCE Proper maintenance allows car SCHEDULED SERVICING ... 173 performance to be maintained over ENGINE COMPARTMENT ... 178 time, operating costs to be contained, RECHARGING THE BATTERY ..183 and safety system performance to be SERVICING PROCEDURES ..184 safeguarded.

  • Page 175: Scheduled Servicing

    PERIODIC CHECKS under the best conditions. Service Schedule: Every 1,000 km or before long trips For this reason, Fiat has planned a check front disc brake pad condition check and, if necessary, top up: series of checks and services at fixed and wear;...
  • Page 176 SERVICE SCHEDULE WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Attention: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations!  ...
  • Page 177 Thousands of kilometres Months Visually inspect condition of: exterior bodywork, underbody protection, pipes and hoses (exhaust, fuel system, brakes), rubber elements (gaiters, sleeves, bushes, etc.) Check the position/wear of the windscreen wiper and rear window wiper blades (where provided) Check operation of the windscreen wiper/washer system and adjust nozzles, if necessary...
  • Page 178 Thousands of kilometres Months Visually inspect the condition of the toothed timing drive belt Check oil level of electro- hydraulic actuator and top up, if necessary (versions with dual-clutch automatic transmission) Replace engine oil and oil filter Spark plug replacement(5) Replace accessory drive belt/s Replace toothed timing drive belt...
  • Page 179 "Technical specifications" chapter); strictly comply with the spark plugs replacement intervals in the Service Schedule. It is advisable to contact a FIAT Dealership for plug replacement. (6) The brake fluid replacement has to be done every two years, irrespective of the mileage.

  • Page 180: Engine Compartment

    ENGINE COMPARTMENT CHECKING LEVELS 179) 180) 1.4 Turbo Multi Air versions (for versions/markets, where provided) F1B0171C A. Engine oil dipstick B. Engine oil cap/filler C. Engine coolant D. Windscreen/rear window washer fluid E. Brake fluid F. Battery...
  • Page 181 When the car is new, the engine needs distilled water. Specifications" chapter. to be run in; therefore the engine oil A periodic check carried out at a Fiat consumption can only be considered Dealership is, however, necessary to WARNING Carefully clean the cap stabilised after the first 5000 - check efficiency.
  • Page 182 Fiat Dealership for replacement. reconnecting the electrical supply to will evaluate the overall electrical Follow the battery Manufacturer’s the battery, make sure that the ignition consumption. instructions for maintenance. device is in the STOP position and the driver side door is closed.
  • Page 183 189) Always wear appropriate goggles to protect your eyes when working on or near the conventional battery. 190) If the battery needs to be replaced, always contact a Fiat Dealership. Replace the battery with a new one of the same type (EFB - Enhanced Flooded Battery) and specifications.
  • Page 184 6) The used engine oil and the filter that has been replaced contain substances that are harmful to the environment. To change the oil and filters, we advise you to contact a Fiat Dealership. 7) Used transmission fluid contains substances that are harmful to the environment. It is advisable to contact a Fiat Dealership to have the fluid changed.

  • Page 185: Recharging The Battery

    Do not use a To carry out this operation contact a "quick-type" battery charger to provide Fiat Dealership. the starting voltage. WARNING After setting the ignition VERSIONS WITHOUT device to STOP and having closed START&STOP SYSTEM...

  • Page 186: Servicing Procedures

    Fiat Dealership at the beginning of intervention or replacements over the using a sponge or a soft cloth and a the summer.
  • Page 187 suitable deicing product to release it if window wiper" in the "Knowing your WARNING Do not operate the required. car" chapter). windscreen wiper with the blades lifted from the windscreen. Do not use the windscreen/rear To lower the blades, move the ignition window wiper to remove frost or ice.
  • Page 188 Fiat Dealership. BRAKING SYSTEM washer nozzles. The guarantee the efficiency of the EXHAUST SYSTEM...
  • Page 189 DUAL CLUTCH REPLACING THE 88) It is recommended to have the car AUTOMATIC BATTERY serviced by a Fiat Dealership. When TRANSMISSION carrying out normal periodic operations If necessary, replace the battery and small servicing interventions personally with another battery with the same...

  • Page 190: Lifting The Vehicle

    If the vehicle needs to be jacked up, go pressure, see the "Wheels" paragraph approved and suitable for the specific to a Fiat Dealership, which is equipped in the "Technical specifications" air conditioning system fitted on the with shop jacks and jack arms.
  • Page 191 Tyres with unidirectional tread can identify the cause and correct it as Important notes be recognised by arrows on the side soon as possible, by contacting a Fiat The use of snow chains should be in which indicate the direction of rotation. Dealership.

  • Page 192: Car Inactivity

    clean and protect the shiny metal 199) Travelling with partially or completely parts using special compounds deflated tyres can cause safety problems and irremediably damage the tyre. available commercially; sprinkle talcum powder on the windscreen and rear window wiper IMPORTANT rubber blades and lift them off the glass;...

  • Page 193: Bodywork

    one minute before disconnecting the maintained intact, requires special care: Bird droppings must be washed off electrical supply from the battery. When see the instructions in the warning at immediately and thoroughly as the acid reconnecting the electrical supply to the end of this paragraph they contain is particularly aggressive.
  • Page 194 at the electronic control units or at the windscreen washer fluid for cleaning IMPORTANT windscreen/rear window wiper motors. the front windscreen and rear window; dilute it min. 50% with water. Only use Have this operation performed at a 97) Abrasive products and/or polishes pure screen washer fluid when strictly specialised workshop.

  • Page 195: Interior

    INTERIOR PLASTIC AND COATED area, applying a uniform light pressure PARTS (do not rub hard). 200) 201) 202) Rinse and wring out the microfibre 100) Periodically check the cleanliness of the cloth, and pass over the area treated in Clean interior plastic parts with a damp interior, beneath the mats, which could the previous point again.
  • Page 196 IMPORTANT 100) Never use alcohol, petrols and derivatives to clean the dashboard and instrument panel lens. 101) Do not use "hard" synthetic brushes as they could damage the fabric beyond repair. Clean the steering-wheel completely to prevent differences in appearance between treated and untreated zones.
  • Page 197 TECHNICAL SPECIFICATIONS Everything you may find useful for IDENTIFICATION DATA ....196 understanding how your car is made ENGINE ........197 and works is contained in this chapter INTAKE SYSTEM ....... 198 and illustrated with data, tables and TRANSMISSION ......199 graphics.

  • Page 198: Identification Data

    IDENTIFICATION DATA VEHICLE IDENTIFICATION NUMBER (VIN) PLATE It is located on the driver side door pillar. It can be read with the door open and bears the following data fig. 209: A Name of Manufacturer F1B0330C F1B0058C B Car type-approval number C Car identification number CHASSIS MARKING The marking includes:...

  • Page 199: Engine

    ENGINE   Versions 1.4 Turbo MultiAir 140 HP Type code 55263624 Cycle Otto Number and position of cylinders 4 in line Piston bore and stroke (mm) 72 x 84 Total displacement (cm³) 1368 10.0 ± 0.2: 1 Compression ratio Maximum power (CEE) (kW) Maximum power (CEE) (HP) Corresponding engine speed (rpm) 5000...

  • Page 200: Intake System

    INTAKE SYSTEM 203)   Versions Intake system Phased sequential electronic injection with knock control and variable 1.4 Turbo MultiAir intake valve actuation WARNING 203) Modifications or repairs to the fuel supply system that are not carried out properly or do not take the system’s technical specifications into account can cause malfunctions leading to the risk of fire.

  • Page 201: Transmission

    TRANSMISSION Versions with dual clutch automatic transmission Versions Transmission Traction Six forward gears plus reverse with synchronisers 1.4 Turbo MultiAir 140 HP Front for forward gears and reverse...

  • Page 202: Wheels

    WHEELS Load index (capacity) RIMS AND WHEELS 62 = 265 kg 78 = 425 kg Alloy or pressed steel rims. Tubeless 63 = 272 kg 79 = 437 kg radial carcass tires. All approved tires are listed in the 64 = 280 kg 80 = 450 kg Registration Certificate.
  • Page 203 H2 shape and number of "humps" (circumference measurement which keeps the bead of tubeless tyres in position on the rim). ET40: wheel compensation (distance between the disc/rim supporting plane and the wheel rim centre line). SNOW TYRES 204) Use snow tyres of the same size as the F1B0054C standard tyres provided with the car.
  • Page 204 RIMS AND TYRES PROVIDED 206)   Rims Tyres provided Aftermarket winter tyres 6.5J x 16 H2 ET40 215 / 60 R16 95H 215 / 60 R16 95Q (M+S) 7J x 17 H2 ET40 215 / 55 R17 94V (*) 215 / 55 R17 94Q (M+S) 225 / 45 R18 91V (**) 7J x 18 H2 ET40 225 / 45 R18 91Q (M+S)
  • Page 205 COLD TYRE INFLATION PRESSURE (bar) When the tyres are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck the correct value when the tyre is cold. With snow tires, add +0.2 bar to the pressure value prescribed for standard tires. If it is necessary to raise the vehicle, refer to the "Raising the vehicle"...

  • Page 206: Dimensions

    DIMENSIONS Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen. Small variations with respect to the reported values are possible depending on the dimensions of the rims. F1B0902  ...

  • Page 207: Weights And Loads

    WEIGHTS AND between values (E) e (D) shown on the plate. LOADS E.g.: E=3080 kg - D= 1875 kg Braked trailer=1205 kg 102) To identify the weights and loads for your car, refer to the plate shown in WARNING Do not exceed the fig.
  • Page 208 TOWABLE WEIGHTS (kg)   Versions 1.4 Turbo MultiAir 1875 1200 140 HP A = TOWABLE WEIGHT B = UNBRAKED TRAILER C = LOAD ON TOW HOOK D = LOAD ON THE ROOF (versions with roof rack bars)

  • Page 209: Refuelling

    REFUELLING     1.4 Turbo MultiAir Prescribed fuels and original lubricants Fuel tank (liters): Unleaded petrol with at least 95 R.O.N. (EN228 specifications) Including a reserve of (litres): 5 - 7 50% mixture of distilled water and Engine cooling system (litres): PARAFLU UP (*) Engine sump (litres): SELENIA DIGITEK P.E.

  • Page 210: Fluids And Lubricants

    FLUIDS AND LUBRICANTS Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Service Schedule. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is crucial for engine operation and duration.
  • Page 211 Original liquids and Features Specification Applications lubricants Low friction coefficient TUTELA STAR 700 Lubricants and greases for grease for constant Differential side constant Contractual Technical 9.55580-GRAS II drive transmission velocity joints. N.L.G.I. velocity joints Reference N° F701.C07 consistency 0-1. Synthetic fluid for brake and clutch systems.

  • Page 212: Performance

    PERFORMANCE Top speed reachable after the initial period of usage of the car.   Versions km/h 1.4 Turbo Multi Air 140 HP (*) (*) Versions with dual-clutch automatic transmission...

  • Page 213: Fuel Consumption - Co 2 Emissions

    FUEL CONSUMPTION - CO 2 EMISSIONS The fuel consumption and CO 2 emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the car is registered. The type of route, traffic conditions, weather conditions, driving style, general condition of the car, version/equipment/accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.

  • Page 214: Prescriptions For Handling The Car At The End Of Its Life

    PRESCRIPTIONS FOR HANDLING THE CAR AT THE END OF ITS LIFE (where provided) The Manufacturer has been committed for many years to safeguarding the Environment through the constant improvement of its production processes and manufacturing products that are increasingly "eco-compatible". To grant customers the best possible service in terms of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life, the Manufacturer is offering its customers the chance to hand over their car at the end of its life without incurring any additional costs.
  • Page 215 MULTIMEDIA TIPS, CONTROLS AND GENERAL INFO ......214 This chapter describes the main functions of the Radio or Uconnect™ Uconnect™ 7" HD / Uconnect™ 7” HD or Uconnect™ 7” HD Nav 7" HD Nav ......... 216 infotainment systems that can be fitted MOPAR®...

  • Page 216: Tips, Controls And General Info

    TIPS, CONTROLS soft, dry anti-static cloth to clean and If the check has a positive outcome, do not press; the system will start to operate, AND GENERAL INFO never use alcohol, petrols and whereas if the comparison codes are ROAD SAFETY derivatives to clean the display lens not the same or if the electronic control Learn how to use the varied system...
  • Page 217 Immediately stop using the system in the event of a fault. Otherwise the system might be damaged. Contact a Fiat Dealership as soon as possible to have the system repaired. WARNING 207) Follow the safety rules here below:...

  • Page 218: Uconnect™ 7" Hd / Uconnect™ 7" Hd Nav

    Uconnect™ 7" HD / Uconnect™ 7" HD Nav (where provided) CONTROLS ON FRONT PANEL F1B0769...
  • Page 219 FRONT CONTROL PANEL SUMMARY TABLE   Button Functions Mode Volume activation/deactivation (Mute/Pause) Short button press On/off Short button press Volume adjustment Left/right rotation of knob Display on/off Short button press Scrolling the list or tuning to a radio station. Change radio station (Radio mode) Scroll the contents Left/right rotation of knob of the sources (Media mode) Media source track change...
  • Page 220 FRONT CONTROL PANEL SUMMARY TABLE   Button Functions Mode Volume activation/deactivation (Mute/Pause) Short button press On/off Short button press Volume adjustment Left/right rotation of knob Display on/off Short button press Scrolling the list or tuning to a radio station. Change radio station (Radio mode) Scroll the contents Left/right rotation of knob of the sources (Media mode) Media source track change...
  • Page 221 SUMMARY TABLE OF DISPLAY BUTTONS   Button Functions Mode Access to the Radio mode Press graphic button Radio Media Source selection: USB, Bluetooth® Press graphic button Phone Access to the Phone mode Press graphic button Access to the system functions (Audio, Media, Uconnect™...
  • Page 222 CONTROLS ON THE STEERING WHEEL The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 223 STEERING WHEEL CONTROLS SUMMARY TABLE   Button Interaction Acceptance of incoming call Answering the second incoming call and putting the active call on hold Display on the instrument panel of the list of the last 10 calls and favourite phone numbers (only with call browsing active) Activation of voice recognition Interruption of the voice message in order to give a new voice command...
  • Page 224 CONTROLS BEHIND THE STEERING WHEEL   Buttons Interaction Button A (left side, behind the steering wheel) Brief button press : search for next radio station or selection of USB next track. Upper button Long button press : scan of higher frequencies until released/fast forward of USB track. With each press it scrolls through sources AM, FM, DAB (where provided), USB.
  • Page 225 SWITCHING THE SYSTEM provided) graphic buttons to select the "Loudness" (for versions/markets, ON/OFF desired frequency band are displayed where provided) "AutoPlay" The system is switched on/off by (the graphic button corresponding to "Auto-On Radio" the selected band is highlighted). pressing the button/knob On the right: display of the following Turn the button/knob clockwise MEDIA MODE...
  • Page 226 "Info": additional information about NOTE This button might be disabled for subsequently). If "No" is selected, the the track playing some Apple® devices. priority is determined according to the “Tracks”: list of available tracks order of connection. The last device Bluetooth®...
  • Page 227 is not guaranteed as it depends on the pair up to 10 phones/audio devices device type/brand. to make access and connection easier and quicker; USB charge port transfer calls from the system to (where provided) the mobile phone and vice versa and Some versions have a USB charging deactivate the microphone audio for port on the central console fig.
  • Page 228 when prompted by the mobile selecting "Phonebook" reading function available, the text phone, use its keypad to enter the PIN selecting "Recent" message notification option on the selecting "Dial" phone must be enabled; this option is code shown on the system display or selecting "Redial"...
  • Page 229 Apple CarPlay AND answer a received message or as a messages received on the instrument new message: panel display. To use this function, Android Auto the mobile phone must support (where provided) the text exchange function through NOTE The date and time shown on Bluetooth®.
  • Page 230 If the smartphone is connected To use Apple CarPlay, the smartphone navigation or navigation using the correctly to the car via one of the two must be connected to the car with a smartphone. USB ports located on the central USB cable.
  • Page 231 Exiting from the Android Auto and Key off options Select the "Parking" button to search Audio for car parks. Apple CarPlay Apps Phone/Bluetooth® Select the "Weather" or "Report You can still access the contents of the Radio Setup Speed Camera" button to receive Uconnect™...
  • Page 232 Call The navigation system can also be sounds. Tip: you can deactivate the Dial updated at the Fiat Dealership. warning sounds by selecting “Settings”, Redial NOTE The dealer may charge for then “Sounds & Alerts”.

  • Page 233: Mopar® Connect

    Tune to the DAB “frequency” (where Go through a saved location durations. Go to the personal page provided) Recent Destinations on the official Fiat website for more Tune to "radio name" FM Stop at a recent destination information about your vehicle. Increase zoom...

  • Page 234: Official Type Approvals

    Download the Uconnect™ LIVE PRIVACY MODE activation the www.driveuconnect.eu portal, app for smartphones or access the contact the Fiat Dealership or contact procedure Customer Care. www.driveuconnect.eu portal to use Proceed as follows: the connected services. You can find take note of the total odometer...
  • Page 235 BORN TO BE TOGETHER...
  • Page 236 Oil change? The experts reccomend Selenia The engine of your car is factory filled with Selenia. This is an engine oil range which satisfies the most advanced international specifications. Its superior characteristics allow Selenia to guarantee the highest performance and protection of your engine. The Selenia range includes a number of technologically advanced products: Selenia ECO2 Selenia DIGITEK PURE ENERGY...
  • Page 239 FLEXCARE - SUBSCRIBE TO PEACE OF MIND A collection of extended warranty and service plans (where and which provided) to match the way you drive PROTECTION PREDICTABILITY FLEXIBILITY EXPERTISE Protect yourself Anticipate the costs, Tailor your FlexCare Benefi t from Brand Parts from the with no surprises.
  • Page 240 NOTES...
  • Page 243 CONTENTS Brakes Dual clutch automatic transmission ... . . 118 brake fluid level ... 178 BS (system) ....77 Dual clutch automatic transmission BSA (Blind Spot Assist) system .
  • Page 244 Light switch ....28 Fiat Code (system) ... . 16 Fix&Go kit ....158 dentification data ain beam headlights .
  • Page 245 Rear ceiling light (changing a Run Flat Tyres ....163 Soft top ....45 bulb) .
  • Page 246 Settings ....216 arning lights and messages ..60 Weights and loads ... 205 Wheels and tyres .
  • Page 247 FCA Italy S.p.A. - MOPAR - Technical Service Operation Via Adige 7, 10040 Rivalta di Torino (TO) - Italy Print no. 603.85.779 - 08/2023 - 3 Edition...
  • Page 250 connect™ 7" HD - Uconnect™ 7" HD Nav...
  • Page 252 FLEXCARE - SUBSCRIBE TO PEACE OF MIND A collection of extended warranty and service plans (where and which provided) to match the way you drive PROTECTION PREDICTABILITY FLEXIBILITY EXPERTISE Protect yourself Anticipate the costs, Tailor your FlexCare Benefi t from Brand Parts from the with no surprises.
  • Page 255 Oil change? The experts reccomend Selenia The engine of your car is factory filled with Selenia. This is an engine oil range which satisfies the most advanced international specifications. Its superior characteristics allow Selenia to guarantee the highest performance and protection of your engine. The Selenia range includes a number of technologically advanced products: Selenia ECO2 Selenia DIGITEK PURE ENERGY...
  • Page 256 BORN TO BE TOGETHER...
  • Page 284 215 / 60 R16 95Q (M+S) 215 / 55 R17 94Q (M+S) 225 / 45 R18 91Q (M+S)
  • Page 436 AUTO AUTO AUTO...

Table of Contents

Save PDF
