- Page 1 RF SMART THERMOSTAT Wi-Fi Thermostat Super strong RF signal for sub1G Communication Heating Force heating Link WORKS WITH Amazon Alexa WORKS WITH Google Assistant English Version:1.0(11/2022) 71.04.00167...
-
Page 2: Standard Accessories
Standard accessories English RF SMART THERMOSTAT Wi-Fi Thermostat Heating Super strong RF signal for sub1G Communication Force heating Link Heating Force heating Link WORKS WITH Amazon Alexa WORKS WITH Google Assistant English Version:1.0(11/2022) 71.04.00167 Screw pack Product USB wire Manual Product overview This set is suitable for wall-hung boiler temperature control. -
Page 3: Product Overview
Product overview English 2 x 1.5 V alkaline AA batteries / Power supply USB powered (Type C interface) RF Thermostat Temp. setting range 5~95℃ Operation temperature range -5~50℃ Measurement accuracy 0.1℃ Setting temp. accuracy 0.5℃ Transmission distance ≤200m in the open air Protection level IP20 433MHz（FSK）/... -
Page 4: Display Symbols
Display symbols English RF Thermostat Time display/ Child-lock indoor humidity Frost Protection Power key 433MHz（FSK） Wake up; Event 1 Wi-Fi（Optional） Leave (am); Event 2 Weather forecast Return (am); Event 3 (Wi-Fi only) Leave (pm); Event 4 Room Temp. Return (pm); Event 5 Floor Temp. - Page 5 Display symbols English [ RF Receiver ] Red light on: heating on Red light off: heating off Yellow light on: forced heating mode is on Heating Force heating Yellow light off: forced heating mode is off Link Flashing green light: pairing Green light on: successful pairing Green light off: not paired...
- Page 6 User routine operations English RF Thermostat Function Steps Power on/off Press “power key” shortly to turn on/off the thermostat. Auto-mode Press “knob key” for 3 seconds to edit auto-mode settings. Temp. control mode Press “knob key” shortly to switch manual/auto mode. Temp.
-
Page 7: Auto-Mode Setting
Auto-mode setting English Press “knob key” for 3 seconds to edit auto-mode settings. Time Temperature Symbols Events Default Modify Default Modify 20℃ ( 68℉ ) 06:00 15℃ ( 59℉ ) 08:00 15℃ ( 59℉ ) 11:30 Workdays 15℃ ( 59℉ ) 12:30 Rotate Rotate... - Page 8 RF thermostat advanced setting (Usually for professional technicians) English Code Meaning Default value Knob key “ ” Temp. calibration -1℃ -9.9~9.9℃(-9~9℉) ±1℃ 0.5~10℃(1~10℉) Temp. Dif. Temp. upper limit 5~95℃(41~199℉) 50℃ Temp. lower limit 5~47℃(41~117℉) 5℃ ON: frost protection on OFF: frost protection off Frost protection Temperature unit ℃/℉...
- Page 9 RF receiver operating instructions English Steps Function Display state Power on/off Press“ ”shortly Power light is always on/off Pairing Under power-off, press“ ” for 3 seconds “ ”Green flashes quickly Distribution Buzzer beeps “ ”light is on network “ ”green light is on is successful Under power-off, Double click the“...
- Page 10 RF receiver operating instructions English Function Steps Display state External When the power light is flashing, “ ”Power light is flashing + “ ” probe short three times press“ ” red light is on(55℃ temperature limit) temperature limit temp When the power light is flashing, Long Save and exit External sensor temperature setting press“...
- Page 11 Installation iocation English The installation distance between the thermostat and the receiver does not exceed 200m (the distance can be judged according to the actual network coverage) Tip: There are many ways to install the RF thermostat, ①wall mounting ②desktop placement ①...
- Page 12 RF thermostat mounting steps. * Note: two power supply methods English ① 2 x 5 Alkalibatterien * Note: ① It is recommended to use brand new 1.5 V alkaline AA batteries. ② Please ensure the correct polarity when installing the battery. 1) Insert a screwdriver into the notch on the back of the thermostat, pry open the base and panel frame, and then put the battery into the battery...
- Page 13 RF thermostat installation steps English 1）Release front cover by inserting a head screw-driver into bottom crack. 2) The wiring method can be chosen by yourself. （① Exposed wiring: choose any one of the four directions, then use a flat-blade screwdriver to pry open along the dotted line;...
- Page 14 RF receiver wiring diagram English The thermostat operates in full capacity in areas with the altitude of less than 2500 above sea level. Power rating of external load should be less than or equal to 80% rated power of the thermostat in areas with altitude of 2500m to 4200m. Actuator CLOSE Boiler...
- Page 15 RF thermostat installation steps English 3) Put the wire into the terminal and tighten it with a flat- blade screwdriver. After tightening the terminal screws, cover the upper cover to complete the installation. Note: Please ensure that the wire line will not touch the spring button, otherwise it will affect the button touch function OPEN...
- Page 16 Pairing steps English ① Under power-off, press “ ” for 3 seconds, ② Under power-off, press power key + “ ” when the green light “ ” flashes, the receiver “ knob key for 3 seconds, the thermostat ” enters the pairing state.. enters the pairing state.
- Page 17 Pairing steps English ③When the receiver's buzzer beeps once, and the power light “ ” the green light “ ” are always on, the pairing is successful. RF Receiver 1 Heating Fore heating Link Keep paired Steady green state The power light on RF Receiver 2 RF Thermostat...
- Page 18 Function introduction（Wi-Fi only） English APP remote control and voice control Smart Speaker RF Thermostat 433MHz Wi-Fi Router Heating Force heating Link RF Receiver Smartphone...
- Page 19 Network configuration（Wi-Fi only） English Download Smart Life APP 16:00 LogIn Download on the iPhone store China Please enter your account Password LogIn Forgot Password Scan the QR code above or search “Smart Life” on App Store and Google Play to download the Login means that you agree with User Agreement...
- Page 20 Wi-Fi setting（Wi-Fi only） English ① In the OFF state, long press the "power button" ② Enter the “ Home ” interface of the APP, click “ ” in the upper right corner, select for 3 seconds, when the screen flashes “ ”...
- Page 21 Voice control（Wi-Fi only） English After waking up the speaker, you can say: Amazon Alexa : Alexa， Google Assistant : OK google, * Turn on the HEATER * Turn on the HEATER * Turn off the HEATER. * Turn off the HEATER. * Make the HEATER cooler in here.
