Original operating manual
Front-mounted tank
FT-P 1502 Comfort
SmartLearning
www.amazone.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT-P 1502 Comfort and is the answer not in the manual?

Questions and answers

Summary of Contents for Amazone FT-P 1502 Comfort

  • Page 1 Original operating manual Front-mounted tank FT-P 1502 Comfort SmartLearning www.amazone.de...
  • Page 2 Please enter the identification data of the implement. The identification data can be found on the rating plate.
  • Page 3: Table Of Contents

    Permissible payload Special equipment Function of the implement 5.10 Noise development data Warning symbols 4.4.1 Positions of the warning symbols 4.4.2 Layout of the warning symbols 4.4.3 Description of the warning symbols MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 4 Checking the lower link pins and 7 Using the machine top link pins Spraying 10.4.4 Checking the hydraulic hose lines Reducing spray liquid drift 10.4.5 Cleaning the filters in the hydraulic plugs Briefly interrupting work MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 5 Loading the implement with a crane 11.2 Lashing the implement 12 Disposing of the implement 13 Appendix 13.1 Bolt tightening torques 13.2 Other applicable documents 13.3 Liquid circuit FT-P 1502 14 Directories 14.1 Glossary 14.2 Index MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 7: About This Operating Manual

    WARNING Indicates a possible threat with moderate risk for severe physical injury or death. CAUTION Indicates a threat with low risk for light or moderately severe physical injuries. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 8: Further Instructions

    Example: 1. Instruction 1 2. Instruction 2 1.2.3.2 Instructions and responses CMS-T-005678-B.1 Reactions to instructions are marked with an arrow. Example: 1. Instruction 1 Reaction to instruction 1 2. Instruction 2 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 9 CMS-T-00013932-B.1 WORKSHOP WORK Identifies maintenance work that must be performed at a workshop that is adequately equipped in terms of agricultural technology, safety and environmental technology by specialist personnel with appropriate training. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 10: Lists

    A list of other applicable documents can be found in the Appendix. 1.4 Digital operating manual CMS-T-00002024-B.1 The digital operating manual and e-learning can be downloaded from the Info Portal on the AMAZONE website. 1.5 Your opinion is important CMS-T-000059-D.1 AMAZONEN-WERKE H. Dreyer &...
  • Page 11: Safety And Responsibility

    2.1.2.1.1 Requirements for persons working with the implement CMS-T-00002310-C.1 If the implement is used improperly, people can be injured or killed: To prevent accidents due to improper use, every person who works with MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 12 Farmers are basically familiar with working with agricultural implements and can instruct agricultural helpers in how to use the implements if necessary. They can perform odd tasks and simple maintenance and repair work on agricultural implements themselves. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 13 Passengers can fall, be run over and severely injured or killed due to machine movements. Ejected objects can hit and injure passengers. Do not let anybody ride on the machine. Do not let anybody climb onto the driving machine. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 14 Non-observance of the technical limits values of the machine can result in accidents and serious personal injury or even death. Moreover, the machine can be damaged. The technical limit values can be found in the Technical Data. Comply with the technical limit values. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 15 Missing warning symbols increase the risk of serious and lethal personal injury. Clean dirty warning symbols. Immediately replace any damaged and illegible warning symbols. Put the intended warning symbols on spare parts. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 16: Knowing And Preventing Dangers

    When the drives are switched off, machine parts can continue running and cause serious personal injury or death. Before approaching the machine, wait until any machine parts that are still running have come to a stop. Only touch machine parts that are standing still. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 17 Before you work in the danger area of the implement: Secure the tractor and machine. This also applies for quick checking work. Health hazard due to radar radiation Maintain a minimum distance of 20 cm from the radar sensors. CMS-I-00010183 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 18: Safe Operation And Handling Of The Machine

    Use only suitable tractors for coupling and transporting the implement. When the implement is coupled onto the tractor, make sure that the tractor's connecting device meets the implement requirements. Couple the implement properly to the tractor. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 19 Use the warning beacon in compliance with the national regulations. Switch off the work lights. Lock the tractor control units. Follow the instructions in the section "Preparing the implement for road travel". MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 20 Do not use the control computer or control terminal during road travel If the driver is distracted, it can result in accidents and injuries or even death. Do not operate the control computer or control terminal during road travel. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 21: Safe Maintenance And Modification

    Remove the ignition key and carry it with you. Wait until all parts that are still running come to a stop and until hot parts cool down. Do not stand on moving parts. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 22 Never modify safety-related components. Never drill out existing holes. Perform all maintenance work at the prescribed maintenance intervals. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 23 2.1.5.3 Operating materials CMS-T-00002324-C.1 Unsuitable operating materials Operating materials that do not meet AMAZONE requirements can cause implement damage and accidents. Only use operating material that meet the requirements in the Technical Data. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 24: Safe Working With Crop Protection Products

    CMS-T-00002325-B.1 Special equipment, accessories, and spare parts Special equipment, accessories, and spare parts that do not meet AMAZONE requirements can impede the operational safety of the implement and cause accidents. Only use original parts or parts that meet AMAZONE requirements.
  • Page 25: Safety Routines

    If you must fill the machine from open waters: Observe the country-specific regulations. Fill the machine only using AMAZONE original filling equipment or using filling equipment that meets AMAZONE requirements. Do not exceed the nominal volume of the spray liquid tank.
  • Page 26 2 hands and one foot or 2 feet and one hand on the implement. When climbing up and down, never hold onto the control elements. When climbing down, never jump off of the implement. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 27: Intended Use

    AMAZONE. Uses other than those specified under the intended use are considered as improper. The manufacturer is not liable for any damage resulting from improper use, solely the operator is responsible. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 28: Product Description

    Control panel at the front on the spray liquid tank Control panel at the bottom left Flushing water tank with filling opening and Transport device screw lid Folding platform Pressure connection for filling with stop tap Work lights MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 29: Special Equipment

    The sales documents provide information on the equipment of your implement, or consult your dealer for more detailed information. The following equipment is special equipment: Removable transport device with parking brake Filling device with non-return valve MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 30: Function Of The Implement

    The flushing water is used to clean the spray liquid tank, supply the spray gun and clean the spray agent canisters. All functions are controlled via the control terminal using switch taps and stop taps. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 31: Warning Symbols

    4.4 Warning symbols CMS-T-00011736-B.1 4.4.1 Positions of the warning symbols CMS-T-00011753-B.1 MD099 MD273 MD100 MD100 MD155 MD155 M 082 CMS-I-00007608 M 096 MD102 M 245 MD199 MD273 M 155 M 155 MD100 MD100 CMS-I-00007610 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 32: Layout Of The Warning Symbols

    A warning symbol consists of two fields: Field 1 shows the following: A pictogram depicting the danger area, CMS-I-00000416 surrounded by triangular safety symbol The order number Field 2 shows a pictogram depicting how to avoid the danger. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 33: Description Of The Warning Symbols

    Have the hydraulic system checked and repaired by a qualified specialist workshop only. Stay away from leaks in the hydraulic system. If you are injured by hydraulic oil, consult a doctor immediately. CMS-I-000216 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 34 Danger due to unintentional starting as well as unintentional and uncontrolled movements of the implement Before all tasks, secure the implement against unintentional starting as well as unintentional and uncontrolled movements. CMS-I-00002253 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 35 Never climb into the spray liquid tank. MD173 CMS-I-00007613 MD 192 Severe injuries due to incorrect handling of the pressure relief valve Have the pressure relief valve checked, adjusted, and repaired by a qualified specialist workshop only. CMS-I-00007612 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 36 Couple the front tank only onto tractors whose min 7000kg tare weight is at least 7 kg. Do not drive faster than 40 km/h with the front = 40 km/h tank. CMS-I-00007615 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 37: Front Lighting And Identification

    CMS-I-00005276 4.5 Front lighting and identification CMS-T-00011735-A.1 Warning boards Side marker lights White reflector Yellow reflector CMS-I-00007605 NOTE The lighting and identification for road travel can vary depending on the national regulations. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 38: Threaded Cartridge

    The threaded cartridge contains the following items: Documents Aids CMS-I-00002306 4.7 Rating plate on the implement CMS-T-00014674-C.1 Implement number Vehicle ID number Product Permissible technical implement weight Tare weight Model year CMS-I-00009315 Year of manufacture MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 39: Control Panel

    KS - Spray agent canister flushing stop tap: Flush the spray agent canister on the filling opening. SF - Flushing water switch tap: Fill the spray liquid tank with flushing water or drawn water. Clean with the spray gun. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 40: Spray Liquid Pump

    4.9 Spray liquid pump CMS-T-00011756-B.1 The spray liquid pump is driven by the tractor hydraulic system. The pump speed can be read on the control terminal. The pump speed can be adjusted via the tractor. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 41: Part-Width Section Valves

    The suction filter filters the spray liquid during spraying operation. The suction filter filters the water when filling via the suction hose and when flushing. Filter area: 660 mm² Mesh size: 0.6 mm CMS-I-00007633 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 42: Self-Cleaning Pressure Filter

    CMS-I-00007634 4.14 Camera system CMS-T-00011761-B.1 4.14.1 Certified camera system CMS-T-00011762-C.1 NOTE If a DLG test report is present, it is a certified camera system. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 43: Non-Certified Camera System

    With front- mounted implements, the camera system is used for cross-traffic monitoring. 4.15 ISOBUS software CMS-T-00011764-A.1 The machine is operated with the ISOBUS software and an ISOBUS control terminal. CMS-I-00007636 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 44: Personal Protective Equipment Safety Kit

    Actual fill level in the flushing water tank CMS-I-00007702 Functions of the buttons in the main menu Go back to the start screen. Select functions in the main menu. CMS-I-00008014 Start and stop the function. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 45 Clean the pressure filter when the spray Spraying operation liquid tank is full. Suction, cleaning and diluting from flushing Fill via the suction connection. water tank. Adjust the agitator. Run the circulation cleaning. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 46: Radar Sensor

    4 | Product description Radar sensor 4.18 Radar sensor CMS-T-00001778-D.1 The radar sensor records the working speed. Depending on the equipment of the implement, different radar sensors can be installed. CMS-I-00002221 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 47: Technical Data

    AR185 bp Maximum permissible pump speed 540 1/min Operating speed 400 1/min to 540 1/min Required oil volume flow at maximum pump speed 28 l/min Delivery capacity at maximum pump speed 180 l/min MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 48: Ballast Weights

    Up the slope and down the slope 20 % up the slope 20 % down the slope 5.8 Performance characteristics of the tractor CMS-T-00011776-A.1 Engine rating Starting at 88 kW / 120 hp MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 49: Permissible Payload

    The workplace-related emission sound pressure level is lower than 70 dB(A), measured in operating condition at the ear of the tractor driver with the cab closed. The emission sound pressure level mainly depends on the vehicle used. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 50: Drivable Slope Inclination

    On left in direction of travel 15 % On right in direction of travel 15 % Up the slope and down the slope Up the slope 15 % Down the slope 15 % MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 51: Preparing The Machine

    Total weight of front-mounted implement or front ballast Permissible total weight of rear-mounted implement or rear ballast Distance between the centre of gravity of the front-mounted implement or the front ballast and the centre of the front axle MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 52 T b 0,2 T b Vmin Vmin Vmin CMS-I-00000513 2. Calculate the actual front axle load. × × - × G a b T b G c + d Vtat Vtat Vtat CMS-I-00000516 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 53 Tyre load according to according to capacity for two tractor operating calculation tractor tyres manual ≤ Minimum front ballasting ≤ Total weight ≤ ≤ Front axle load ≤ ≤ Rear axle load MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 54: Equipping The Implement With Ballast Weights

    2. Secure the top link pin with a linch pin. CMS-I-00007640 3. Install one Category 3 ball sleeve with lower link pin from the inside respectively. 4. Secure the lower link pins with linch pins. CMS-I-00007639 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 55: Coupling The Implement

    Permanent hydraulic oil circulation Hydraulic oil flow until action is Momentary executed Free hydraulic oil flow in the tractor Floating control unit Designation Function Tractor control unit Pump drive Single-acting Pressure-free return flow MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 56 2 . The hydraulic plugs lock perceptibly. 4. Route the hydraulic hose lines with sufficient freedom of movement and without chafing points. CMS-I-00001045 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 57: Coupling The Lighting For Road Travel

    6.4.5 Removing the transport device CMS-T-00011781-A.1 1. Slightly raise the implement. 2. Hold the transport roller and pull out the linch pin. 3. Remove the transport roller downwards. 4. Remove all 4 transport rollers. CMS-I-00007641 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 58: Coupling The Spray Liquid Hose Lines

    6.4.7 Connect the electronic lines CMS-T-00011783-B.1 Connect the electronic cables. CMS-I-00007642 6.5 Preparing the implement for operation CMS-T-00011925-C.1 6.5.1 Filling the hand wash tank CMS-T-00011787-A.1 Fill the hand wash tank via the filling opening. CMS-I-00007646 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 59: Filling The Flushing Water Tank

    6.5.3 Calculating the target rate for band spraying CMS-T-00012585-B.1 Calculate the desired target rate for band spraying SB from the target rate for full-area spraying SF. SB = SF SB = _________ l/ha CMS-I-00008043 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 60: Filling The Spray Liquid Tank Via The Suction Hose

    6. Enter the target fill level on the TwinTerminal and confirm. Filling of the spray liquid tank stops automatically as soon as the target fill level has been reached. 7. Add the crop protection product while filling. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 61: Filling The Spray Liquid Tank Through The Pressure Connection

    [kg/l] for the individual liquids into account while filling the field sprayer. Specific weights of different liquids Liquid Water Urea NP solution Density 1 kg/l 1.11 kg/l 1.28 kg/l 1.38 kg/l MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 62: Adding Crop Protection Product And Cleaning Spray Agent Canisters

    6. Select for switch tap "SF". 7. Clean the flushing area with the spray gun. 8. Select Position 0 for switch tap "SF". 9. Close the cover of the spray liquid tank. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 63: Replacing Spraying Nozzles

    7. Screw the bayonet cap onto the nozzle body. 6.6 Preparing the machine for road travel CMS-T-00011922-B.1 6.6.1 Switching on the agitator CMS-T-00011924-B.1 To prevent the spray liquid from segregating, the agitator must be switched on during road travel. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 64: Checking The Camera System

    The camera system is an aid. The camera system does not replace the banksman Rely on the banksman when driving into intersections or junctions. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 65 6 | Preparing the machine Preparing the machine for road travel Monitoring cross-traffic using a certified camera system Use a banksman when driving into intersections or junctions. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 66: Using The Machine

    5. Select on the TwinTerminal and confirm. CMS-I-00007657 6. Select on the TwinTerminal, set the agitator capacity and confirm. Switch on spraying operation in the Work menu on the control terminal. CMS-I-00008033 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 67: Reducing Spray Liquid Drift

    1. On the control terminal, select the Cleaning menu. CMS-I-00007717 2. In the Cleaning menu, select "Flush boom". Flush the boom. Stop flushing. CMS-I-00008032 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 68 15. Clean the pressure filter with water. CMS-I-00007732 To ensure that the opening of the filter mount is flush with the connection fitting: Insert the pressure filter properly. 17. Screw the pressure filter back in. CMS-I-00007651 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 69: Emptying Excess Spray Liquid Via The Spray Liquid Pump

    The hose is contaminated. 10. Clean the implement. 7.5 Diluting spray liquid with flushing water CMS-T-00011909-A.1 Reasons for diluting the spray liquid: Eliminate residual quantities. Increase the spray liquid supply for treating a residual area. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 70: Spraying Out The Diluted Residual Quantity

    2. Read the technical residue in the spray line from the technical data. 3. Calculate the distance travelled. 10.000 Designa Unit Description tion Required travelled distance l/ha Application rate Working width Undilutable residual CMS-I-00007752 quantity 4. Switch off the agitator. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 71: Cleaning The Field Sprayer On The Field

    3. In the Cleaning menu, select "Intensive cleaning" or "Quick cleaning". NOTE The intensive cleaning procedure takes approx. 15 minutes. During intensive cleaning, cleaning water is CMS-I-00007717 sprayed onto the field automatically three times. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 72 8. Place a collection bucket under the drain valve. 9. Open stop tap "DF". 10. Open stop tap "RM". The final residual quantity is drained. 11. Close the stop taps again. CMS-I-00009593 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 73: Cleaning The Field Sprayer With Cleaning Additives

    If there is doubt regarding the cleanliness of the liquid circuit, the machine can be cleaned with cleaning additives. To do so, the following cleaning additives can be used. Product Manufacturer Agro-Quick Adama JET CLEAR Sudau agro Proagro Spritzenreiniger proagro SE MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 74: Using The Camera System

    Also use the exterior mirror for the largest possible coverage of the field of vision. NOTE Equipment with a non-certified camera system does not replace the marshalling person in road traffic. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 75 Via the display mode, it is possible to display one camera or both cameras. To switch off the camera system: Switch off the screen with the "POWER" button. 5. For other settings, observe the operating manual for the camera system. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 76: Eliminating Faults

    81. actual forward speed. Hydraulic functions run slower. Filters in the hydraulic plug are Clean or exchange the filter in soiled. the hydraulic plug. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 77 1. Remove the spring element 3 . 2. Take out the diaphragm 2 . 3. Clean the diaphragm seat. 4. Check the diaphragm for cracks. 5. Reinstall the diaphragm and spring element. CMS-I-00008061 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 78: Parking The Machine

    2. Release the top link 1 . 3. Uncouple the top link 1 from the implement. 4. Release the lower links 2 . 5. Uncouple the lower links 2 from the implement from the tractor seat. CMS-I-00001249 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 79: Driving The Tractor Away From The Implement

    CMS-I-00004045 9.4 Uncoupling the lighting for road travel CMS-T-00001402-I.1 1. Unplug the connector 1 for the lighting. CMS-I-00001048 2. Hook in the plugs 1 in the hose cabinet. CMS-I-00001248 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 80: Disconnecting The Hydraulic Hose Lines

    4. Put the dust caps on the hydraulic sockets. CMS-I-00001065 5. Hang the hydraulic hose lines 1 in the hose cabinet. CMS-I-00001250 9.6 Uncoupling the spray liquid hose lines CMS-T-00011839-B.1 Uncouple the hose lines for the liquid circuit. CMS-I-00007643 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 81: Disconnecting The Electronic Lines

    9 | Parking the machine Disconnecting the electronic lines 9.7 Disconnecting the electronic lines CMS-T-00011840-B.1 Disconnect the electronic cables. CMS-I-00007642 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 82: Repairing The Implement

    CMS-I-00007668 Select flushing water on the TwinTerminal and confirm. 7. Select for pressure valve chest "DA". 8. Select for switch tap "SF". Antifreeze was pumped into the spray liquid tank. CMS-I-00007667 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 83 20. Reuse the mixture of antifreeze and spray liquid Dispose of it correctly. To drain the pressure sensor: Remove the hose from the pressure sensor. 22. Empty the hand wash tank. CMS-I-00007669 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 84: Having The Field Sprayer Inspected

    10.2 Checking the spray liquid pump CMS-T-00015230-B.1 WORKSHOP WORK 1. Loosen the union nut. 2. Fasten the slide-on fitting with order number ZF1433. 3. Put on the hose connection. 4. Run the spray liquid pump. CMS-I-00007672 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 85 10.2 Checking the pressure gauge CMS-T-00015232-A.1 WORKSHOP WORK Testing kit for the pressure gauge: Slip-on cap, order number: 913954 and plug, order number: ZF195 Blind hose, order number: 116059 Pressure gauge connection, order number: 7107000 CMS-I-00007673 MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 86: Eliminating Limescale In The System

    6. Interrupt the pump drive. 7. Allow the mixture to rest for 5 minutes. 8. Dilute the mixture with flushing water until the colour changes to yellow. The diluted mixture is harmless. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 87: Maintaining The Implement

    To do so, at least one nozzle must be used both on the left and right boom section, and also in the middle of the sprayer boom. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 88 Stop the spraying procedure on the ISOBUS control terminal. 9. In the Setting menu on the ISOBUS control terminal, set the simulated speed to 0 km/h. 10. Convert the average individual nozzle output to one minute. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 89 If the values determined for the application rate do not match the set values: Calibrate the flow meter, see ISOBUS software operating manual, section "Calibrating the flow meter". Check all nozzles for wear and blockage. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 90: Checking The Hydraulic Hose Lines

    3. Retighten loose bolted connections. Hydraulic hose lines must not be more than 6 years old. 4. Check the manufacturing date 1 . CMS-I-00000532 WORKSHOP WORK 5. Replace worn, damaged or aged hydraulic hose lines. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 91 2. Read the oil level on the mark when the implement is aligned horizontally. CMS-I-00007694 If the oil level is below the mark: Take of the cover and refill oil. 4. Put the cover back on. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 92 While doing so, slowly fill multi-purpose oil 15W40 up to the mark. 6. Mount the cover of the sight glass. 7. Install the spray liquid pump. 8. Check the oil level after one hour of operation. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 93: Adjusting The Air Pressure In The Hydraulic Accumulator

    Check and correct the air pressure on the air valve 2 . CMS-I-00007696 10.4.9 Checking the ballast weights CMS-T-00011848-A.1 INTERVAL Every 50 operating hours Weekly Check the fastening material for the ballast weights. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 94: Checking The Tightening Torque For The Radar Sensor Bolts

    Always maintain a minimum distance of 30 cm between the high-pressure nozzle and the implement. Do not exceed a water pressure of 120 bar. Clean the implement with a high-pressure cleaner or a hot water high-pressure cleaner. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 95: Storing The Implement

    1. Clean the machine. 2. Protect unpainted components from corrosion using a suitable corrosion inhibitor. 3. Grease all lubrication points. Remove excess grease. 4. Park the implement in a sheltered place. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 96: Loading The Implement

    Only attach the slings for lifting at the marked lashing points. 1. Attach the slings for lifting on the intended lashing points. 2. Slowly lift the implement. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 97: Lashing The Implement

    1. Put the implement on the transport vehicle. 2. Attach the lashing straps at the marked points. 3. Lash down the implement in compliance with the national regulations for load securing. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 98: Disposing Of The Implement

    2. Return batteries to the distributor Dispose of batteries at a collection point. 3. Put recyclable materials in the recycling. 4. Treat operating materials like hazardous waste. WORKSHOP WORK 5. Dispose of the coolant. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 99: Appendix

    380 Nm 290 Nm 405 Nm 485 Nm 27 mm M18x1.5 325 Nm 460 Nm 550 Nm 410 Nm 580 Nm 690 Nm 30 mm M20x1.5 460 Nm 640 Nm 770 Nm MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 100: Other Applicable Documents

    174 Nm 8.4 Nm 242 Nm 20.4 Nm 342 Nm 40.7 Nm 470 Nm 70.5 Nm 589 Nm 13.2 Other applicable documents CMS-T-00012659-A.1 Tractor operating manual Operating manual for the AMAZONE rear implement MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 101: Liquid Circuit Ft-P 1502

    Valve for internal cleaning of spray Internal cleaning valve for spray KWA106 VWA106 liquid pump liquid tank KWA111 Spray gun / jet nozzle tap VWA110 Canister cleaning WWA111 Spray gun XWA060 Suction connection XWA072 Draining connection MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 102: Directories

    Tractor In this operating manual, the designation tractor is always used, even for other agricultural tractor units. Implements are mounted on the tractor or towed by the tractor. MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 103: Index

    Air pressure in the hydraulic accumulator Application rate Flow meter Oil quantity, oil condition Faults Output of the spray liquid pump elimination Pressure gauge the field sprayer by an inspection workshop Tightening torque for radar sensor bolts MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 104 Adjusting the air pressure Hydraulic hose lines checking Checking the condition reading the level connecting uncoupling Overwintering Hydraulic system connecting Part-width section valves Description Inflation pressure Payload adjustment calculation Intended use Platform Intensive cleaning Position MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 105 Residual quantities Spray liquid pump Transport speed Safety kit Test badge Description Machine inspection Special equipment Threaded cartridge Description Spray agent adding Three-point mounting frame adjusting Spray agent canister coupling cleaning disconnecting MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 106 Calculating the required tractor characteristics 45 Transport device Description installing removing Transport Lashing the implement Lifting the implement TwinTerminal Description Tyre load capacity calculation unloading Warning symbols Description Layout Positions Workshop work MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
  • Page 108 AMAZONEN-WERKE H. DREYER SE & Co. KG Postfach 51 49202 Hasbergen-Gaste Germany +49 (0) 5405 501-0 amazone@amazone.de www.amazone.de MG7610-EN-GB | F.1 | 26.02.2025 | © AMAZONE...
