- Page 1 D70 Micro Vacuum Pump and Compressor Series User Guide Issue Date 2024-12 Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 2 D70 Micro Vacuum Pump and Compressor Series User Guide Copyright © Chengdu Hilin Technology Co., Ltd. 2020. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Chengdu Hilin Technology Co., Ltd. Trademarks and Permissions is a trademark of Chengdu Hilin Technology Co., Ltd.
-
Page 3: About This Document
D70 Micro Vacuum Pump and Compressor Series User Guide About This Document Purpose This document is related to the D70 micro vacuum pump and compressor products,which is used to guide relevant technical personnel to initially understand the characteristics of the product. Intended Audience This document is intended for technical personnel. -
Page 4: Change History
D70 Micro Vacuum Pump and Compressor Series User Guide Change History The change history accumulates each update of this document. The latest version of the document contains all the previous updates. Product Issue Date Issuer Modification Version Adjusted PS material 2024.07 content and add silencer description... -
Page 5: Table Of Contents
D70 Micro Vacuum Pump and Compressor Series User Guide Contents About This Document ....................3 Change History ......................4 Contents ........................4 1 Characteristics .....................7 1. 1 High Vacuum ............................7 1. 2 Large Flow Rate ..........................7 1. 3 Corrosion Resistant ..........................7 1. - Page 6 D70 Micro Vacuum Pump and Compressor Series User Guide 5.1 Installation and fixation of pump body ..................... 17 5.2 Push-in quick connector connection ....................17 5.3 Internal thread connector connection ....................17 5.3 Hose connection ..........................17 5.3 Outlet silencer connection ......................... 18 6 Wiring and ControlInstructions ..............
-
Page 7: Characteristics
D70 Micro Vacuum Pump and Compressor Series User Guide Characteristics High Vacuum This product can provide a maximum negative pressure environment of 11kPa.abs, that is, a relative vacuum degree of -90kPa, to meet the needs of a wide range of pressure ranges. Large Flow Rate The peak flow rate of a single pump head product is as high as 51L/min, and the average flow rate is as high as 35L/min, with an... -
Page 8: Pipe Fittings In Various Sizes
D70 Micro Vacuum Pump and Compressor Series User Guide Pipe Fittings in Various Sizes It has a modular air nozzle connector design, with an 8mm inner diameter hose connector as standard, and an optional 8mm outer diameter hard pipe quick-change connector, R1/8 internal thread connector and 8mm L-shaped rotatable connector for easy access to various types of air system. -
Page 9: Special Functions
D70 Micro Vacuum Pump and Compressor Series User Guide Special Functions Speed Control Function Products equipped with brushless motors can control and adjust the motor speed of the pump through PWM signals or voltage signals to change the flow rate. Start and Stop Function Products equipped with brushless motors can control the start and stop of the pump through PWM signals and voltage signals, which... -
Page 10: Product Model Description
D70 Micro Vacuum Pump and Compressor Series User Guide Product Model Description Brief Description of Model Naming Note: Example 1: D70VS-BL4HS2PI8 (D70 high vacuum single-head air pump, standard brushless motor 24V power supply, material combination: EPDM diaphragm, FKM valve plate, FKM seal, PPS pump head, standard version, PWM speed control, R1/8 internal thread connector) Example 2: D70VS-DC2PS1MH8 (D70 high vacuum single-head air pump, brushed DC motor 12V power supply, material combination: PTFE diaphragm, FKM valve... -
Page 11: Technical Specifications
D70 Micro Vacuum Pump and Compressor Series User Guide Technical Specifications Key Specifications Rel. Rated Load Peak Average Output Weight Model voltage(V current flow(L/m flow Pressure Vacuum( （kg) （mA) （L/min） (kPa) -kPa) BLDC motor,Diaphragm：EPDM ; Valve/Seals：FKM; Pump HS material head:PPS D70VS-BL2HS Max.50 ≤3.7... -
Page 12: Configuration Options
D70 Micro Vacuum Pump and Compressor Series User Guide 3. Unless otherwise specified, technical parameters are measured at 20°C and standard atmospheric pressure of 101kPa; 4. The average flow rate in the table is the flow value measured with a soap film flowmeter, and the peak flow rate is the value measured with a glass rotor flowmeter. -
Page 13: Reliability Parameters
D70 Micro Vacuum Pump and Compressor Series User Guide orientation ROTA: Rotate 90° clockwise based on the standard orientation of the nozzle; ROTB: Rotate 180° clockwise based on the standard orientation of the nozzle; ROTC: rotate 270° clockwise based on the standard orientation of the nozzle;... -
Page 14: Air Nozzle Options
D70 Micro Vacuum Pump and Compressor Series User Guide Motor life test conditions: Under good ventilation and heat dissipation conditions, the motor runs continuously for 24 hours without load Life test environment conditions: in a clean and corrosion-free laboratory, the ambient temperature is 5~33℃, fluctuating with the climate, the relative humidity is 50%~85%, fluctuating with the climate * Represents the design target parameters, the actual life is... - Page 15 D70 Micro Vacuum Pump and Compressor Series User Guide Options of Modular Pneumatic Connectors Connector Option feature identification PC8 push-in connector is suitable for PU and other rigid plastic air pipes P8 push-in connector with an outer diameter of 8mm. It is suitable for hose connector with an inner diameter of 7-8mm.
-
Page 16: Installation Instructions
D70 Micro Vacuum Pump and Compressor Series User Guide Installation Instructions Copyright © Chengdu Hilin Technology Co., Ltd. - Page 17 D70 Micro Vacuum Pump and Compressor Series User Guide Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 18 D70 Micro Vacuum Pump and Compressor Series User Guide installation and fixation of pump body This product can be optionally equipped with a cylindrical shock-absorbing foot kit when ordering. The shock-absorbing feet can isolate the vibration of the micropump from being transmitted to the equipment during operation and further reduce noise.
- Page 19 D70 Micro Vacuum Pump and Compressor Series User Guide Pipe connection of internal thread connector When choosing a pump head with an internal thread, customers should use the air nozzle connector according to their own conditions. The internal thread is the national standard 1/8 cylindrical internal thread (Rp1/8).
-
Page 20: Electrical Connection
D70 Micro Vacuum Pump and Compressor Series User Guide Electrical Connection The wiring instructions are instructions for connecting the external power supply and signal cables of this product. This product is shipped with standard connection cables, and the cable definitions are distinguished by color. - Page 21 D70 Micro Vacuum Pump and Compressor Series User Guide D70 with Brushed Motor Interface Definition Function S.N. Wire Input Signal Definition Description For 12V/24V motors, the voltage must not exceed the DC10.8~13.2V Positive pole maximum voltage range, DC21.6~26.4V otherwise the motor will be burned out.
- Page 22 D70 Micro Vacuum Pump and Compressor Series User Guide Wiring of D70 with BL type DC brushless motor The product model with the words BL2/BL4 means that the product is equipped with a brushless DC motor with a rated voltage of 12V/24V DC.
- Page 23 D70 Micro Vacuum Pump and Compressor Series User Guide When you need to use the voltage signal speed regulation function, you can divide the voltage through a potentiometer. Connect the potentiometer Vcc to the green 5VOUT port to input 5V DC voltage. Connect the voltage divider output of the potentiometer to the blue PWM input cable, and connect the potentiometer ground to The black thin wire SGND is connected to the control signal ground, and...
- Page 24 D70 Micro Vacuum Pump and Compressor Series User Guide cable, and the PWM signal source ground is connected to the black thin line SGND control signal ground. The yellow FG feedback signal output cable is then connected to the FG signal input end of the upper controller;...
- Page 25 D70 Micro Vacuum Pump and Compressor Series User Guide Power supply signal, 5V signal power driving capacity 100mA, Green 5VOUT Output 5V voltage supply used to power the speed regulator Analog voltage speed regulation: 4.8V~5V motor stops, 0V~0.2V motor reaches maximum speed. PWM speed regulation: The speed recommended input...
- Page 26 D70 Micro Vacuum Pump and Compressor Series User Guide Cautions Please read the instructions in this chapter carefully and follow the instructions strictly before use. 1. Only technicians with corresponding skills training can install, use, test and maintain the pump! 2.
- Page 27 D70 Micro Vacuum Pump and Compressor Series User Guide threat to personal harm and return them to the factory for maintenance services for the reasons of employee personal safety protection and social safety. If any For related product maintenance needs, please sign the harmless declaration form and contact our company in advance! 10.
- Page 28 D70 Micro Vacuum Pump and Compressor Series User Guide Customer Repair Declaration of Harmlessness In order to protect the personal and environmental safety of our employees, logistics company personnel and related personnel in the whole society, please check the toxic, harmful, corrosive, biohazardous and radioactive materials before sending the repaired and returned products back to Hailin Technology.
- Page 29 D70 Micro Vacuum Pump and Compressor Series User Guide Appearance D70 single head equipped with BL brushless motor Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 30 D70 Micro Vacuum Pump and Compressor Series User Guide D70 single head equipped with DC brush motor Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 31 D70 Micro Vacuum Pump and Compressor Series User Guide D70 corrosion-resistant pump head equipped with BL brushless motor Copyright © Chengdu Hilin Technology Co., Ltd.
