D08 Flow Control Vacuum Pump and Compressor Series User Guide About This Document Purpose This document is a description of the D08 flow control vacuum pump and compressor products in testing period, which is used to guide relevant technical personnel to initially understand the characteristics of the product.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Contents About This Document ....................1 Change History ......................2 Contents ........................3 1 Characteristics ....................... 1 1.1 Compact Size............................. 1 1.2 Multiple motor options........................1 1.3 High vacuum, Big pressure........................1 1.4 Industrial-grade reliability........................2 2 Functions .........................
Page 6
D08 Flow Control Vacuum Pump and Compressor Series User Guide 5.2 Logic Wiring Diagram(Equipped with BDC motor)................. 9 5.3 Definition of Signals(Equipped with BLDC motor)................9 5.4 Logic Wiring Diagram(Equipped with BLDC motor)...............9 6 Cautions ......................... 13 7 Dimensions ......................15 8 Appearance ......................
D08 Flow Control Vacuum Pump and Compressor Series User Guide Characteristics Compact Size The overall size of the product(equipped with a brushless motor) is about 34.5×21×32.5mm; the overall size of the product(equipped with a brushed motor) is 40 × 17 × 23.5mm; it is suitable for applications that require a very small space of air pumps.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Functions Speed Control Function For brushed motor version, The flow rate of the pump can be changed by adjusting the motor speed and changing the input voltage , For brushless motor version,The flow rate of the pump can be changed by adjusting the motor speed through PWM signal.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Technical Specifications Performance Specifications (Standard atmospheric pressure 101kpa) Max Flowrate Model Voltage Max. Max. Max. Pressure (L/min) Load Vacuum (V DC) (kPa) Current (-kPa) Peak Average (mA) Flow Flow Material Option A Pump Head:Aluminum Alloy,Diaphragm/Valves:EPDM, Motor: BDC D08L-53-0610 ≤210...
D08 Flow Control Vacuum Pump and Compressor Series User Guide Reliability Parameters Models D08L equipped with BLDC motor Versions Simplified Standard Premium Fully Loaded Lifetime 12000 (Estimated lifetime) (hrs) Unloaded Lifetime 18000 (hrs) Motor Lifetime(hrs) 20000 Full-load life test conditions: block the exhaust port of the pump, and the suction port is directly connected to the atmosphere, so that the pump can operate continuously without stopping for 24 hours under the maximum vacuum condition;...
Page 13
D08 Flow Control Vacuum Pump and Compressor Series User Guide Working Conditions Permissible ambient temperature range of the simplified version products is 0℃~ 40℃, and the permissible ambient temperature of the standard and premium Environment versions is 0℃~50℃. The permissible relative humidity of all pumps in this series is ≤90%, no condensation.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Versions Description Version Simplified Standard Version Premium Version Version Performance Lifetime ★★ ★★★ ★★★★ Noise ★ ★★ ★★★ Reliability ★ ★★ ★★★ Parameter Consistency ★ ★★ ★★★ Note: 1.The more ★, the better performance of this item. 2.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Electrical Connection The Electrical Connection section introduces how to connect this product to an external power supply and the wiring instruction of signal wires. This product is equipped with standard connection wires at the factory, and the wire definitions are distinguished by colors.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Definition of Signals(D08 Equipped with BLDC Motor) There are 5 motor wires for this product. The wiring and usage instructions are as follows. S.N. Color Function Explanation Remarks Black Negative pole of the power supply Positive pole of the DC12V (±10%)...
D08 Flow Control Vacuum Pump and Compressor Series User Guide Logic Wiring Diagram(D08 Equipped with BLDC Motor) If speed control and speed feedback are not needed, the red wire shall be connected to the positive pole of the power supply, and the black, white and orange wires connected to the negative pole of the power supply;...
Page 21
D08 Flow Control Vacuum Pump and Compressor Series User Guide When you need to use the PWM speed control function and monitor the pump operation or perform feedback control through the FG signal, you need to use an upper controller (MCU, PLC, host computer, etc.) that supports PWM signal output, FG signal input and start-stop control.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Cautions Please read the instructions in this chapter carefully and follow the instructions strictly before use. 1. This product has no waterproof, dust-proof, and explosion-proof functions and cannot be used in flammable and explosive environments! 2.
D08 Flow Control Vacuum Pump and Compressor Series User Guide Dimensions Overall Dimensions of D08L(Equipped with BLDC Motor) Unit:mm Weight:60g Installation instructions: 1. The screws on the pump cannot be removed, otherwise it will damage the pump; 2. The mounting holes are M3*5 threaded holes., Do not remove and disassemble them repeatedly, otherwise it will cause loose and unreliable installation.
Page 24
D08 Flow Control Vacuum Pump and Compressor Series User Guide Overall Dimensions of D08L(Equipped with BDC Motor) Unit:mm Weight:35g Installation instructions: 1. The screws on the pump cannot be removed, otherwise it will damage the pump; 2. M2*20 mounting holes., Do not remove and disassemble them repeatedly, otherwise it will cause loose and unreliable installation.
