- Page 1 C09 Flow Control Vacuum Pump series User Guide Issue Date 2020-6-19 Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 2 Chengdu Hilin Technology Co., Ltd. Address: No.3663 Section 2 Muhua Road Shuangliu District Chengdu Sichuan China 610000 Website: http://www.hilintec.com Tel: +86-28-62567958 Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 3 C09 Flow Control Vacuum Pump Series User Guide About This Document Purpose This document is related to the C09 flow control micro vacuum pump products,which is used to guide relevant technical personnel to initially understand the characteristics of the product. Intended Audience This document is intended for technical personnel.
- Page 4 C09 Flow Control Vacuum Pump Series User Guide Change History The change history accumulates each update of this document. The latest version of the document contains all the previous updates. Product Issue Date Issuer Modification Version 2018-7 First official release Revise the lifetime test 2018-12 description and...
-
Page 5: Table Of Contents
C09 Flow Control Vacuum Pump Series User Guide Contents About This Document ....................1 Change History ......................2 Contents ........................3 1 Characteristics ......................1 1.1 Compact Size............................. 1 1.2 Speed Control Function........................1 1.3 Anti-loosening Connectors........................ 1 1.4 Working Status Indicator........................2 1.5 Brushless Motor.......................... - Page 6 C09 Flow Control Vacuum Pump Series User Guide 5 Electrical Connection ..................10 5.1 Brief Description of Types....................... 10 5.2 Knob Speed Control Type........................10 5.3 PWM Speed Control Type....................... 12 5.4 Frequency Speed Control Type......................14 6 Cautions ......................... 16 7 Dimensions ......................17 8 Appearance ......................
-
Page 7: About This Document
C09 Flow Control Vacuum Pump Series User Guide Characteristics Compact Size The product weighs about 90g, and the overall size is about 64x43x48mm (this size does not include shock-absorb feet). Speed Control Function There are three types of speed control functions available for this series of pumps: knob speed control, PWM speed control and frequency speed control. -
Page 8: Change History
C09 Flow Control Vacuum Pump Series User Guide Working Status Indicator Integrated speed indication function, visually understand the running status of the pump according to the flashing frequency of the indicator light. Brushless Motor This model is driven by brush-less motors which have the advantages of long service life, low interference and high reliability. -
Page 9: Contents
C09 Flow Control Vacuum Pump Series User Guide Special Features Speed Control Function The flow rate of the pump can be changed by adjusting the motor speed. There are three types of speed control functions available for this series of pumps: knob speed control type, PWM speed control type and frequency speed control type. -
Page 10: Technical Specifications
C09 Flow Control Vacuum Pump Series User Guide Technical Specifications Key Specifications （Standard atmospheric pressure 101kpa） Rated Load Average Peak Relative Weight Model Version Voltage Current Flow Flow Vacuum （g） （V DC） （mA） （L/min） （L/min） （-kpa） Premium ≤200 ≥2.0 ≥2.0 ≥37 Version Standard... -
Page 11: Description Of Versions
C09 Flow Control Vacuum Pump Series User Guide Description of Versions Simplified Version Standard Version Premium Version Version Performance Life time ≥2000h ≥4500h ≥5500h Motor ★ ★★ ★★★★ Reliability ★ ★★ ★★★★ Anti-electromagnetic Interference ★ ★★ ★★★★ Diaphragm Performance ★ ★★... -
Page 12: Working Conditions
C09 Flow Control Vacuum Pump Series User Guide of the pump must be unobstructed, and there must be no components in the outlet hose that hinder the discharge of gas! Working Conditions 1. Environment: Permissible ambient temperature range of the pump is 0 ℃... -
Page 13: Parameter Curve
C09 Flow Control Vacuum Pump Series User Guide Parameter Curve Vacuum degree-flow curve, there are individual differences between different micro pumps, this curve is a statistical value, only used as a technical reference for users to confirm the working point. The "flow"... -
Page 14: Starting Current
C09 Flow Control Vacuum Pump Series User Guide Starting Current The starting current curve is measured under the working condition that the inlet and outlet are directly connected to the atmosphere, and there are certain individual differences between different micro pumps. -
Page 15: Product Model Description
C09 Flow Control Vacuum Pump Series User Guide Product Model Description Brief Description of Model Naming This series of pumps are divided into three types according to the selected speed control mode: knob speed control type, PWM speed control type and frequency speed control type. Copyright ©... -
Page 16: Electrical Connection
C09 Flow Control Vacuum Pump Series User Guide Electrical Connection Brief Description of Types 1. Knob speed control type: A digital rotary encoder is used for input control to realize digital control of start and stop, acceleration and deceleration of the pump. Adjust the knob clockwise or counterclockwise to control the speed increase or decrease, and press the button to control the start and stop of the micro pump. - Page 17 C09 Flow Control Vacuum Pump Series User Guide Note: The wire color in the above figure may be different from the actual wire color,please connect according to the above figure. The red wire of the power connector is connected to the positive pole of the DC power supply, the black wire is connected to the negative pole of the power supply, and the speed regulation connector is connected to the knob circuit board through a wire...
-
Page 18: Pwm Speed Control Type
C09 Flow Control Vacuum Pump Series User Guide (2) Screw installation: Use two M3 screws to pass through the screw holes and washers of the speed control knob switch, and then fix them to the mounting plate. Figure 5-3 Screw Installation Note: In order to avoid welding protrusions on the back of the speed control knob switch to affect the installation, we have attached two Φ3*Φ7*3 insulating washers in the installation accessories. - Page 19 C09 Flow Control Vacuum Pump Series User Guide Note: The wire color in the above figure may be different from the actual wire color,please connect according to the above figure. The red wire of the power connector is connected to the positive pole of the DC power supply, and the black wire is connected to the negative pole of the power supply.
-
Page 20: Frequency Speed Control Type
C09 Flow Control Vacuum Pump Series User Guide Frequency Speed Control Type Figure 5-5 Wiring Diagram of Frequency Speed Control Note: The wire color in the above figure may be different from the actual wire color,please connect according to the above figure. The red wire of the power connector is connected to the positive pole of the DC power supply, and the black wire is connected to the negative pole of the power supply. - Page 21 C09 Flow Control Vacuum Pump Series User Guide Connector Input Definition Input Signal Description Not connected Frequency speed control signal a. Control speed through frequency, Frequency speed range: when 1.5kHz<frequency rate<5.6kHz, 1.5kHz~5.6kHz rpm=input frequency; 0V≤low level≤0.8V b. When the frequency is >5.6kHz, 3.3V≤high level≤5V the micro pump runs at the highest speed;...
-
Page 22: Cautions
C09 Flow Control Vacuum Pump Series User Guide Cautions Please read the instructions in this chapter carefully and follow the instructions strictly before use. 1. The outlet must be unobstructed, otherwise the micro pump will be damaged! 2. The inlet can carry a large load, but only short-term blockage is allowed, and long-term blockage can easily damage the pump. -
Page 23: Dimensions
C09 Flow Control Vacuum Pump Series User Guide Dimensions Installation instructions: 1. The screws on the pump cannot be removed, otherwise it will damage the pump; 2. The mounting holes are self-tapping screw holes, not suitable for repeated tightening and disassembly, otherwise the installation will be loose and unreliable. -
Page 24: Appearance
C09 Flow Control Vacuum Pump Series User Guide Appearance Copyright © Chengdu Hilin Technology Co., Ltd.
