- Page 1 D60 Vacuum Pump and Compressors Series User Guide Issue Date 2020-06 Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 2 Chengdu Hilin Technology Co., Ltd. Address: No.3663 Section 2 Muhua Road Shuangliu District Chengdu Sichuan China 610000 Website: http://www.hilintec.com Tel: +86-28-62567958 Copyright © Chengdu Hilin Technology Co., Ltd.
-
Page 3: About This Document
D60 Vacuum Pump and Compressors Series User Guide About This Document Purpose This document is related to the D60 vacuum pump and compressor series products,which is used to guide relevant technical personnel to initially understand the characteristics of the product. Intended Audience This document is intended for technical personnel. -
Page 4: Change History
D60 Vacuum Pump and Compressors Series User Guide Change History The change history accumulates each update of this document. The latest version of the document contains all the previous updates. Product Issue Date Issuer Modification Version 2019-07 First official release Modify ‘... -
Page 5: Table Of Contents
D60 Vacuum Pump and Compressors Series User Guide Contents About This Document....................I Change History......................II Contents........................III 1 Characteristics......................1 1.1 Working Status Indicator........................1 1.2 Brush-less DC Motors..........................1 1.3 Protections............................1 2 Special Features..................... 2 2.1 Working Status Indication and Warning....................2 3 Technical Specifications.................. -
Page 6: Characteristics
D60 Vacuum Pump and Compressors Series User Guide Characteristics Working Status Indicator The remote control type and basic type are equipped with working status indicator lights, which can visually feed back the working status of the pump. Brush-less DC Motors This model is driven by brush-less motors which have the advantages of long service life, low interference and high reliability. -
Page 7: Special Features
D60 Vacuum Pump and Compressors Series User Guide Special Features Working Status Indication and Warning The basic type and remote control type are equipped with working status indicator lights. Users can understand the working status of the equipment through the color change of the indicator lights: a. -
Page 8: Technical Specifications
D60 Vacuum Pump and Compressors Series User Guide Technical Specifications Key Specifications Maximu Flow（L/min） Load Relative Mode Voltage Weight Current Vacuum Output (V DC) （g） （A） （-kPa） Pressure Average Peak Flow （kPa） Flow D60L ≈850 ≤1.3 ≥26 ≥18 ≥50 ≥100 Note: 1. -
Page 9: Description Of Types
D60 Vacuum Pump and Compressors Series User Guide Lifetime ≥2500h ≥6000h ≥8000h Noise ★ ★★ ★★★ Reliability ★ ★★ ★★★ Parameter consistency ★ ★★ ★★★ ★ ★★ ★★★ Ambient temperature 0~40℃ 0~50℃ 0~50℃ Note: 1. The more ★, the better performance of this item. 2. -
Page 10: Life-Time Test Conditions
D60 Vacuum Pump and Compressors Series User Guide Remote Control Type √ √ Customizable Touch Control Type Top Configuration Type Note: √ in the above table means that there is a corresponding product for sale, unchecked means that there is no corresponding product. (The above table does not include customized products.) Life-time Test Conditions In a clean, non-corrosive laboratory, the pump carries a full load(the... -
Page 11: Pump Materials
D60 Vacuum Pump and Compressors Series User Guide 2) When used as a vacuum pump: the inlet can operate at full load (i.e completely blocked the inlet), but the applied load cannot exceed the maximum vacuum degree of the pump; the outlet must keep unobstructed. -
Page 12: Starting Current Curve
D60 Vacuum Pump and Compressors Series User Guide Note: 1. The maximum average flow rate of the curve will be slightly lower than the nominal value, which is due to the resistance of the test pipeline components, which leads to the attenuation of the flow; 2.The value of this curve is for reference only, not as a basis for product acceptance. -
Page 13: Product Model Description
D60 Vacuum Pump and Compressors Series User Guide Product Model Description Brief Description of Model Naming There are two types of this series of pumps: basic type and remote control type, Note: If the remarks starts with a letter, it means a special custom function. For example, letter "GJ"... -
Page 14: Electrical Connection
D60 Vacuum Pump and Compressors Series User Guide Electrical Connection Basic Type Figure 5-1 Wiring Instructions for Basic Type Instruction: The red wire of the power connector is connected to the positive pole of the DC 24V power supply, the black wire is connected to the negative pole of the power supply. - Page 15 D60 Vacuum Pump and Compressors Series User Guide Instruction: The red wire of the power connector is connected to the positive pole of the 24V DC power supply, and the black wire is connected to the negative pole of the power supply. When using the remote control function, you need to set the toggle switch to the "on"...
-
Page 16: Cautions
D60 Vacuum Pump and Compressors Series User Guide Cautions Please read the instructions in this chapter carefully and follow the instructions strictly before use. This product has no waterproof, dust-proof, and explosion-proof functions and cannot be used in flammable and explosive environment! Foreign matter must not fall into the hydraulic connectors, and there should be no solid particles in the medium, otherwise the micro pump will be damaged! - Page 17 D60 Vacuum Pump and Compressors Series User Guide If this series of pumps are not used with our matching power supply, it may cause interference to the operation of the pump. Leading the ground wire at the power connector to reliably ground will help improve the reliability of operation! Please operate strictly in accordance with the requirements of this user guide.
- Page 18 D60 Vacuum Pump and Compressors Series User Guide Dimensions Copyright © Chengdu Hilin Technology Co., Ltd.
- Page 19 D60 Vacuum Pump and Compressors Series User Guide Installation instructions: 1. The screws on the pump cannot be removed, otherwise it will damage the pump; 2. The mounting holes are self-tapping screw holes, not suitable for repeated tightening and disassembly, otherwise the installation will be loose and unreliable. Copyright ©...
-
Page 20: Appearance
D60 Vacuum Pump and Compressors Series User Guide Appearance D60-Basic Type Copyright © Chengdu Hilin Technology Co., Ltd. - Page 21 D60 Vacuum Pump and Compressors Series User Guide D60-Remote Control Type Copyright © Chengdu Hilin Technology Co., Ltd.
