CORNER TWIN/FULL BED
3460370P - TWIN CORNER BED - SILVER
SKU #
ITEM#
35103706
39SL-25HF
35203708
39SL-25R
3440370P - TWIN CORNER BED - PINK
SKU #
ITEM#
35503704
37PK-25HF
35603706
37PK-25R
3400370P - TWIN CORNER BED - CHARCOAL
SKU #
ITEM#
35903702
35CC-25HF
36003705
35CC-25R
3420370P - TWIN CORNER BED - GRAY
SKU #
ITEM#
36303701
36GR-25HF
36403703
36GR-25R
TWIN/FULL HEADBOARD & CONER SIDE PARTS LIST
Code
Description
A
Headboard
B
Corner Side
F
Leg
This product is manufactured by HOUS for
DO NOT USE SUBSTITUTE PARTS. PLEASE CONTACT YOUR RETAIL STORE OR www.roomstogo.com
Version 1-04 03 2022
LUCIE
ITEM DESCRIPTION
TWIN HDBD & CORNER SIDE
TWIN FOOTBOARD , RAILS & SLATS
ITEM DESCRIPTION
TWIN HDBD & CORNER SIDE
TWIN FOOTBOARD , RAILS & SLATS
ITEM DESCRIPTION
TWIN HDBD & CORNER SIDE
TWIN FOOTBOARD , RAILS & SLATS
ITEM DESCRIPTION
TWIN HDBD & CORNER SIDE
TWIN FOOTBOARD , RAILS & SLATS
QTY
Parts
1pc
1pc
2pcs
WITH SERVICE OR PARTS REPLACEMENT REQUEST
3470370P - FULL CORNER BED - SILVER
SKU #
ITEM#
ITEM DESCRIPTION
35303700
39SL-26HF
FULL HDBD & CORNER SIDE
35403702
39SL-26R
FULL FOOTBOARD , RAILS & SLATS
3450370P - FULL CORNER BED - PINK
SKU #
ITEM#
ITEM DESCRIPTION
35703708
37PK-26HF
FULL HDBD & CORNER SIDE
35803700
37PK-26R
FULL FOOTBOARD , RAILS & SLATS
3410370P - FULL CORNER BED - CHARCOAL
SKU #
ITEM#
ITEM DESCRIPTION
36103707
35CC-26HF
FULL HDBD & CORNER SIDE
36203709
35CC-26R
FULL FOOTBOARD , RAILS & SLATS
3430370P - FULL CORNER BED - GRAY
SKU #
ITEM#
ITEM DESCRIPTION
36503705
36GR-26HF
FULL HDBD & CORNER SIDE
36603707
36GR-26R
FULL FOOTBOARD , RAILS & SLATS
TWIN/FULL FOOTBOARD, RAILS & SLATS PARTS LIST
Code
Description
C
Footboard
D
Bed Rail
Straight
E
Slats
F
Leg
Parts
QTY
1pc
2pcs
1pc
2pcs
Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO KIDS Lucie 3460370P
Summary of Contents for ROOMS TO GO KIDS Lucie 3460370P
- Page 1 LUCIE CORNER TWIN/FULL BED 3460370P - TWIN CORNER BED - SILVER 3470370P - FULL CORNER BED - SILVER SKU # ITEM# ITEM DESCRIPTION SKU # ITEM# ITEM DESCRIPTION TWIN HDBD & CORNER SIDE 35103706 39SL-25HF 35303700 39SL-26HF FULL HDBD & CORNER SIDE 35203708 39SL-25R TWIN FOOTBOARD , RAILS &...
- Page 2 LUCIE CORNER TWIN/FULL BED TWIN HEADBOARD, CONER SIDE HARDWARE LIST Bolt 5/16"*40*2-3/8" Spring Washer 5/16" 2Pcs Flat Washer 5/16"*16mm Bolt 5/16"*17*1" Spring Washer 5/16" 12Pcs Flat Washer 5/16"*16mm 2Pcs Iron 90*70*3 Iron 118*118*36 2Pcs Allen Key 100*40*5mm Phillips Screwdriver(Not Provided) Hardware Pack Location(s): 39SL-25HF 3/3 Headboard/Corner...
- Page 3 LUCIE CORNER TWIN/FULL BED TWIN/FULL FOOTBOARD, RAILS & SLATS HARDWARE LIST Bolt 5/16"*40*2-3/8" Spring Washer 5/16" 2Pcs Flat Washer 5/16"*16mm Screw #8*1-3/8" 6Pcs Allen Key 100*40*5mm Phillips Screwdriver(Not Provided) Hardware Pack Location(s): 39SL-25R 3/3 FOOTBOARD/RAILS SKU# 35203708 39SL-26R 4/6 FOOTBOARD/RAILS SKU# 35403702 37PK-25R 3/3 FOOTBOARD/RAILS...
- Page 4 ASSEMBLY INSTRUCTION Caution:Please read all instructions carefully before starting the assembly process.These parts are cumbersome and heavy.Therefore,two people are recommended in order to prevent personal injury and insure the parts are not damaged during the assembly. STEP1: STEP2: Attach the legs(F) to headboard(A) and Loosen bolts on Headboard(A) and Footboard(C) with allen Footboard(C) as shown, tighten use bolt(1) and key(6 ), place bed rails(D) into position, Tighten bolts on...
