DF-models DF-06 PRO MINI Instructions Manual page 34

Ersatzteile | regular checks / maintenance | contrôles réguliers / entretien
controlli regolari / manutenzione | controles regulares / mantenimiento
Pravidelné kontroly / údržba | Regularne kontrole / konserwacja
8068 8061
Querlenker unten v/h Differentialgehäuse
Front and rear swing Gearbox upper and
arm assembly lower cover components
8064 8056
Querlenkerhalter (2)
Querlenkerpins (2)
Arm reinforcement
2*40.8 optical axis
plate group + Shims
8075 8083
Schrauben 2x29 (2)
Kugellager 8x12x3,5 (4)
Cross countersunk
8*12*3.5 ball bearing (4)
head machine tooth
step screw 2 * 29KM
8073 8080
M2,5x6 Schrauben (10) Senkkopfschrauben 3x5
M2.5*6*6 Machine tooth 3*5KMCross countersunk
belt intermediate screw head machine tooth screw
8084 8049
M2 Stoppmuttern (4) Reifen (2)
M2 Locknut (4) Tires (2)
8081 8024
Schrauben 2x16 (10) Servosaver
Round head self Servo arm A/B/C
return spring
tapping screws
2 * 16 (10) assembly
8079 8082
Senkkopfschrauben 2x8 Schrauben 2x10 (8)
2*8 sets of countersunk 2*10PB Cross round
self tapping screws (8) head self tapping
screw(8)
7465 8062
Hauptchassis
LiPo USB-Ladekabel
Underbody assembly
USB charging cable
8074 8052
Regler-/ Empfänger-
Gleitlager 4x8x3 (4)
Einheit Brushless
Oil bearing 4*8*3
Three in One Brushless
ESC
8051 8069
Servo
Lenkhebel/ C-Hub/
Radträger je 1x
C-shaped seat rear
axle seat steering
arm group
8077 8048
Schrauben 2x19 (10)
Body komplett
Round head self
car shell group
tapping screws
2 * 19 (10)
6462 7448
Madenschrauben M3x3
Kugellager 7x11x3 (4)
M3*3 Machine screw (6)
7*11*3 ball bearing (4)
7452 7443
Schneidschrauben Radmitnehmerpins (4)
2.6x8 (10)
1.5*9.6 optic axis (4)
Round head self
tapping screws
2.6*8PB (10)
8025 8078
Splinte (4)
Schrauben 2x7 (10)
R-pin (4)
2*7PB Cross round head
self tapping screw set
7432 8067
Radmitnehmer (4)
Spur-/ Lenkstangen
Hexagonal wheel
Tie rod group
seat assembly
