Ecco ED3060 Installation And Operation Instruction Manual

!
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property damage,
serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the
safety information contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential
to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current
arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output perfor-
mance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate
the system without losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the effectiveness of the air bag or become a projectile that could cause serious personal injury or
death. Refer to the vehicle owner's manual for the air bag deployment area. It is the responsibility of the user/operator to deter-
mine a suitable mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential
head impact.
6. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the ve
hicle operator should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or com-
partment doors), people, vehicles, or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal. Never take
the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an intersection, driving
against traffic, responding at a high rate of speed, walking on or around traffic lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding warning signal devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specifications:
Size: 6.45" L x 2" W x 1.3" H
Weight: 0.6 lb. (0.27 kg)
Input Voltage: 12-24 VDC
Max Power @ 12.8 V: 17.9 W
Max Current @ 12.8 V: 1.4 A
DOT Type: I, S, T, R
Installation and Operation Instructions
ED3060 LED Stop-Turn-Tail-Reverse
Installation & Mounting:
Mounting with supplied rubber grommet:
1. Cut out supplied template (page 3). Mark hole to be cut using
template. Ensure that the hole measures approximately 6.75"
length x 2.50" width. Cut out mounting hole.
2. Insert the rubber grommet into the hole until flange is against
mounting surface.
3. Route wires through grommet and press light into the grommet
until light is flush with grommet surface.
Mounting with option plastic bezel:
1. Use plastic bezel to trace hole to be cut. Ensure that the hole
measures approximately 6.75" length x 2.50" width. Cut out
mounting hole.
2. Place the flange to the hole and mark the screw hole locations.
3. Pre-drill holes with 3/16" drill bit (or recommended drill for
selected hardware).
4. Install flange using #12 hardware appropriate for material to be
mounted to.
5. Feed wires through flange and insert light into flange while
aligning key in light to feature in flange. Light will snap into
place.
Page 1 of 3
