- Page 1 USER MANUAL ENGLISH V1.0 MP-300SBU Professional Multimedia Player Product code: D1243...
- Page 2 MP-300SBU Professional Multimedia Player Preface Thank you for purchasing this DAP product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
MP-300SBU Professional Multimedia Player Table of contents 1. Introduction ............................ -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: Figure 1 • • DAP MP-300SBU Professional Multimedia Player • • Schuko to IEC power cable (1,5 m) • •... -
Page 5: Symbols And Signal Words
MP-300SBU Professional Multimedia Player 1.4. Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in death or DANGER serious injury. -
Page 6: Safety
MP-300SBU Professional Multimedia Player Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. 2.1. -
Page 7: Requirements For The User
MP-300SBU Professional Multimedia Player • • Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the required power consumption of the device. Attention General safety • • Do not block the ventilation openings. Without proper heat dissipation and air circulation, the internal components may overheat. -
Page 8: Description Of The Device
Description of the Device The DAP MP-300SBU Professional Multimedia Player is a USB, SD card and BT 5.3 audio player and is designed for installation into a 19” rack. The device features pitch, tempo and playback controls. It has an RCA line output and a set of balanced XLR outputs. -
Page 9: Lcd Display
MP-300SBU Professional Multimedia Player 3.3. LCD Display Figure 4 16) Track number 17) Folder number 18) Time display 19) Pitch mode indicator 20) A/B indicator 21) Pitch setting indicator 22) Loop mode indicator 23) Auto cue indicator 24) Tempo lock indicator... -
Page 10: Product Specifications
MP-300SBU Professional Multimedia Player 3.4. Product Specifications Model: MP-300SBU Professional Multimedia Player Outputs: Main outputs 1 Main output connector 3-pin XLR / RCA Playback: Supported audio files FLAC / MP3 / WAV Supported format exFAT / FAT16 / FAT32 Maximum storage size 256 GB ... -
Page 11: Dimensions
MP-300SBU Professional Multimedia Player Product properties: LED indicators Power Thermal specifications: Maximum ambient temperature 50 °C Minimum ambient temperature -20 °C Included items: Included cables IEC cable 3.5. Dimensions Figure 5 Product code: D1243... -
Page 12: Installation And Setup
MP-300SBU Professional Multimedia Player Installation and Setup 4.1. Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. 4.2. Safety Instructions for Installation Attention Make sure that there is enough space for ventilation around the device. -
Page 13: Start-Up
05) Adjust the volume with the master level control knob (03). 06) Adjust the control options. Note: Press the master level control knob (03) to make it flush with the front of the MP-300SBU Professional Multimedia Player. Product code: D1243... -
Page 14: Operation
01) Switch on the device. 02) Start BT on your mobile device. 03) On your mobile device scan for the available BT devices. The ID of the MP-300SBU Professional Multimedia Player is "MP-300SBU". 04) Pair your mobile device with the MP-300SBU Professional Multimedia Player. -
Page 15: Usb Drive
02) Place a USB drive into the USB-A connector in (11). 03) Press the source input button (04) for USB. 5.3. Control Options The MP-300SBU Professional Multimedia Player has the following control options: A. Display button (see 5.3.1. Display Options) B. -
Page 16: Play Mode
MP-300SBU Professional Multimedia Player 5.3.2. Play Mode 01) Press the play mode button (B) to enter the play mode menu. 02) Turn the folder/track control knob (09) to select one of the following 5 settings: • • SINGLE: Play a single track •... -
Page 17: Playback Functions
MP-300SBU Professional Multimedia Player 5.3.8. Playback Functions The MP-300SBU Professional Multimedia Player has the following options for track playback: • • Stop button: Press this button to stop a track and go back to the beginning • • Cue button: Press this button to activate the cue function (see 5.3.8.2. -
Page 18: Troubleshooting
MP-300SBU Professional Multimedia Player Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 19: Corrective Maintenance
Approval Hereby, Highlite International declares that the device MP-300SBU Professional Multimedia Player, product code D1243, is in compliance with Directive 2014/53/EU (RED – Radio Equipment Directive). The full text of the EU declaration of conformity is available on the respective product page on the website of Highlite International (www.highlite.com). - Page 20 DAP is a brand of Highlite International B.V.
