ASROCK Rack Z690D4U-2L2T/G5 Quick Installation Manual

*15G065255000AK*
P/N: 15G065255000AK V1.0
Quick Installation Guide
Z690D4U-2L2T/G5 | W680D4U-2L2T/G5 | Z690D4U/G5 |
Z690D4U-2L2T/G5/BCM | W680D4U-2L2T/G5/BCM
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1
37
1
1
F RNT_VGA 1 PWM_CFG1
F AN7
F AN6
F AN5
36
US B 3. 2 Gen1
IPMI
T: USB3_2
LA N
B: USB3_1
35
L AN1 L AN2
L AN3
X 710- AT 2
BCM57416
L AN4
PCIE 7
UID1
PCIE 6
A SPEED
ASR2600
34
PCIE 4
No t S upported:
Z 690D4U/G5
CLRCMOS1
LED_LAN3_4
1 1
33 32
3 I/O Panel
4
2
1 3
No. Description
1 VGA Port (VGA)
2 Serial Port (COM1)
3 USB 3.2 Gen1 Ports (USB3_1_2)
4 LAN RJ-45 Port (IPMI_LAN)
5 1G LAN RJ-45 Port (LAN1, shared NIC)
6 1G LAN RJ-45 Port (LAN2)
3 5
2 4
24.4cm (9.6 in)
BA T1
AT X 12V 2
AT X 12V 1
DDR5_B 2 (6 4 bit , 2 88-pin module ) DDR3_B 1 (6 4 bit , 2 40-pin module )
DDR5_B1 (6 4 bit , 2 88-pin module ) DDR3_A1 (6 4 bit , 2 40-pin module )
DDR3_B 1 (6 4 bit , 2 40-pin module ) DDR5_A 2 (6 4 bit , 2 88-pin module )
DDR3_A1 (6 4 bit , 2 40-pin module ) DDR5_A1 (6 4 bit , 2 88-pin module )
i 210
No t S upported:
Z 690D4U/G5
RoHS
NUT30_1 NUT42_1
S upe r
I/O
BMC_SMB1 IPMB1
SEC_OR1 NMI_BTN1 T 1 R PECI1
1 1
1 1
1 1
31 30 29 28 27 26
Not Supported:
Z690D4U/G5
6 8
5 7 9 10
No. Description
7 HDMI Port (2.0b)
8 Display Port (1.4a)
9 10G LAN RJ-45 Port (LAN3)
10 10G LAN RJ-45 Port (LAN4)
11 UID Switch (UID1)
www.asrockrack.com
Z690D4U-2L2T/G5
1 Install the Server Board
Insert the server board into the chassis.
Affix the screws clockwise into the
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws.
6 7
1
AT XPWR1
PSU_SMB 1
Z 690D4U/G5
Z 690D4U-2L2T/G5
W 680D4U-2L2T/G5
Z 690D4U-2L2T/G5/BCM
W 680D4U-2L2T/G5/BCM
1
O CU4
O CU3
O CU2 O CU1
Intel
Z 690/
W 680
NUT60_1 NUT80_1
Dr. Debug
USB_1_2
AUX_P ANEL1
T PM_BIOS_PH1
B IOS SA TA_SGPIO 1
RO M
1
1
25 24 23 22
4 LAN Port LED Indications
IPMI LAN Port
ACT/LINK LED
SPEED LED
LAN Port
10G LAN Port
ACT/LINK LED
SPEED LED
11
LAN Port
1G LAN Port
ACT/LINK LED
SPEED LED
LAN Port
W680D4U-2L2T/G5 Z690D4U/G5
No. Description
8
1 Front VGA Header (FRNT_VGA1)
2 PWM Configuration Header (PWM_CFG1)
2 x 288-pin DDR5 DIMM Slots
3
(DDR5_A1, DDR5_B1)
4 ATX 12V Power Connector (ATX12V1)
5 ATX 12V Power Connector (ATX12V2)
6 PSU SMBus Header (PSU_SMB1)
7 ATX Power Connector (ATXPWR1)
2 x 288-pin DDR5 DIMM Slots
8
(DDR5_A2, DDR5_B2)
9 Chassis Fan Connector (FAN4)
10 Chassis Speaker Header (SPEAKER1)
9
F AN4
11 USB 3.2 Gen1 Header (USB3_3_4)
10
12 OCuLink x4 Connector (OCU4)
BUZZER1
1
13 OCuLink x4 Connector (OCU3)
SPEAKER1
14 OCuLink x4 Connector (OCU1)
15 Chassis Fan Connector (FAN3)
16 Chassis Fan Connector (FAN2)
17 Chassis Fan Connector (FAN1)
SATA3 Connectors (SATA3_3)(Upper),
18
(SATA3_2)(Lower)
SATA3 Connectors (SATA3_1)(Upper),
19
(SATA3_0)(Lower)
USB3_3_4
20 OCuLink x4 Connector (OCU2)
11
21 System Panel Header (PANEL1)
12
22 Auxiliary Panel Header (AUX_PANEL1)
13
23 SATA SGPIO Connector (SATA_SGPIO1)
14
24 SPI TPM Header (TPM_BIOS_PH1)
15
F AN3
25 USB 2.0 Header (USB_1_2)
16
F AN2
26 CPU PECI Mode Jumper (PECI1)
17
F AN1
27 Thermal Sensor Header (TR1)
Intelligent Platform Management Bus
18
28
Header (IPMB1)
29 BMC SMBus Header (BMC_SMB1)
30 Non Maskable Interrupt Button (NMI_BTN1)
19
31 Security Override Jumper (SEC_OR1)
20
32 LAN LED Connector (LED_LAN3_4)
P ANEL1
33 Clear CMOS Pad (CLRCMOS1)
PLED PWRBT N
1
34 M.2 Socket (M2_1) (Type 2230/2242/2260/2280)
HDLED R ESET
35 Chassis Fan Connector (FAN5)
36 Chassis Fan Connector (FAN6)
21
37 Chassis Fan Connector (FAN7)
Activity / Link LED Speed LED
Status Description Status
Off No Link Off
Blinking Yellow Data Activity Yellow
On Link Green
Activity / Link LED Speed LED
Status Description Status
Off No Link Off
Blinking Green Data Activity Yellow or
Amber
On Link Green
Activity / Link LED Speed LED
Status Description Status
Off No Link Off
Blinking Orange Data Activity Yellow
On Link Green
Z690D4U-2L2T/G5/BCM W680D4U-2L2T/G5/BCM
Description
10M bps connection or
no link
100M bps connection
1Gbps connection
Description
100Mbps connection
or no link
1Gbps connection
10Gbps connection
Description
10Mbps connection or
no link
100Mbps connection
1Gbps connection
