CONSET Storage Assembly Instructions And User's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Original
Storage
EN - Assembly Instruction and User Manual
(Page 2)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Storage and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CONSET Storage

Summary of Contents for CONSET Storage

  • Page 1 Original Storage EN - Assembly Instruction and User Manual (Page 2)

  • Page 2: Important Notes

    TABLE OF CONTENTS 1. Safety and warnings 2. Usage IMPORTANT NOTES! 3. Set up and installation Prior to installment, use and 4. Operation maintenance of the table frame, any 5. Maintenance and defects installer and any user of the table must study this assembly and operation 6.
  • Page 3 9. Declaration of conformity We hereby declare, under our sole responsibility that the following products: Sit and stand table product type Storage is in accordance with: Directive 2006/42/EF of The European Parliament and of the Council of 17 May 2006 on machinery...
  • Page 4 7. Parts Tabletop Motor leg Non-motor leg Gearmotor Foot Top bracket motor leg Top bracket non-motor leg Bracket for storage Lid for hole in drawer bottom Driveshaft Specil bolt M5 M5 nut M4x8 countersunk head M5x12 button head M5x10 button head...
  • Page 5 7. Parts Handle Bolt placement tool M5 wrench...
  • Page 6 8. Assembly Instruction and User Manual Step 1 - Unpacking the table Step 2 - Turn the tabletop upside down and reuse cardboard to avoid damage during assembly...
  • Page 7 Step 3 - Drive the inner tube out with driveshaft Step 4 - Mount bracket and screws...
  • Page 8 Step 5 - Drive the inner tube back with driveshaft Step 6 - Drive the inner tube out with driveshaft...
  • Page 9 Step 7 - Mount bracket and screws Step 8 - Drive the inner tube back with driveshaft...
  • Page 10 Step 9 - Mounting bracket motor on motor leg Step 10 - Mounting motor leg...
  • Page 11 Step 11 - Mounting bracket Step 12 - Mounting drive shaft...
  • Page 12 Step 13 - Mounting non-motor leg Step 14 - Fastening screws on drive shaft...
  • Page 13 Step 15 - Mounting feets Step 16 - Turn table around - be careful as the legs is not fully mounted...
  • Page 14 Step 17 - Finish mounting brackets Step 18 - Mount control panel and handle...
