- Page 1 349750.0 Assembly instruction Page 2 SQ 147250 - SQ147280 This instruction is a supplement to chapter 7 and 8 in the instruction, which is packed together with the legset...
- Page 2 7. PARTS D) x 1 F) x 6 J) x 4 L) x 1 G) x 4 M) x 2 E) x 10 x Variable qty B) x 1 C) x 2 G) x 4 D) x 1 F) x 4...
- Page 3 8. ASSEMBLY INSTRUCTIONS – shown assembly for right turned frame a) connect item to item b) fit screws F and tighten c) fit screws G and tighten F) x 2 G) x 2 a) connect item to item b) fit screws F and tighten c) fit screws G and tighten d) tighten the pre-mounted screws (x4) Pre-mounted screws...
- Page 4 Mounting Part : mount to the left side or the right side according to your top a) connect item to item b) fit screws and nut F, M and J c) connect item d) fit screws F and G e) connect item f) fit screws F and G J) x 2 Right side...
- Page 5 Wiring a) connect item to item b) connect item to item...
- Page 6 SKRUERNE MÅ IKKE SPÆNDES FOR HÅRDT, DO NOT OVER TIGHTEN THE SCREWS ZIEHEN SIE DIE SCHRAUBEN NICHT ZU IDET DET KAN SKADE BETJENINGEN AF SINCE THIS MAY HARM THE FUNCTION FEST AN DA DIES DIE FUNKTION BEEIN- BORDET OF THE CONTROL TRÄCHTIGEN KANN DER STEUERUNG...
