Technical Support and E-Warranty Certificate www.vevor.com/support
POTTERY WHEEL MACHINE
MODEL:GCJX-030
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Related Manuals for VEVOR GCJX-030
Summary of Contents for VEVOR GCJX-030
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support POTTERY WHEEL MACHINE MODEL:GCJX-030 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING：Read all safety warnings, instructions, illustrations and specifications provided with this electrical equipment. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. Warning - To reduce the risk of injury, user must read instructions manual carefully. - Page 4 6.Before use, make sure that the switch and pedal are in the stop position before inserting the power. 7.When repairing or replacing parts, the switch must be cut off and the power supply must be unplugged. 8. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 5 · Connect the product to an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for assistance. MODEL AND PARAMETERS Model GCJX-030 Maximum Payload(Clay) Input AC 100-240V～ 50/60Hz Power...
-
Page 6: Structure Diagram
STRUCTURE DIAGRAM 1.Aluminum turntable 2.Equipment body 3.Speed regulation switch 4.Forward/reverse switch 5.Power plug TOOL ACCESSORIES AND USE 1. 8-Piece Tool Set(x1) - Page 7 A(Clay cutting line): Assist in precisely cutting clay (cutting surface is very smooth)/repairing and leveling the mouth of the work/taking away the finished product. B(Small yellow sponge): Add water or absorb water/trim the surface or mouth edge to make it smooth. C(Wooden knife):Trim the bottom for later removal/trimming.
- Page 8 E(Stainless steel scraper): Remove the excess clay on the surface to make it smooth. F(Circular large flat wire knife): Trim the surface of the vessel/ control the thickness/trim out the bottom ring foot. G(Steel needle): Scrape off excess clay from the mouth edge/remove air bubbles/punch holes.
-
Page 9: Operating Steps
2. Plastic Printing 8-piece Set(x1): Texture decoration, bonding, clay modeling, and so on(As shown below). 3. Aluminium turntable （Φ45mm+Φ65mm+Φ100mm): The size of the turntable depends directly on the maximum diameter we can achieve. （Loosen the bolt with a wrench and replace it） NOTE: After the work, please clean the sludge on the turntable and basin in time, wipe it with a dry towel to avoid oxidation on the surface of the turntable ! - Page 10 Step2: Plug in the power. Step3:Choose the direction of forward (clockwise)/reverse (counterclockwise) rotation according to your needs. Step4:Turn the knob to adjust the proper speed. (Clockwise acceleration, reverse deceleration) Step5:Clay molding with tools. Step6:Dry the body surface quickly with a hot air gun (1-3 minutes).
- Page 11 Step7:Clay-mold repairs with tools. Step8:Creative painting and coloring can be carried out according to their own needs. After the work is completed,stop the machine in reverse order. Remove the molding with a scraper/clay cutting line. Place in a cool place for a period of time before firing. SKILLS GUIDANCES Problem Reason...
- Page 12 Clay is in a spiral The clay molding speed exceeds Turn the mold a few times in shape. the machine speed. advance. Clay unevenly Abnormal posture of clay Sit firmly and keep your back, stressed presses molding. neck, shoulders, upper arms, forearms, wrists and palms still.
- Page 13 Mold collapsed. 1.There was too much water and 1. Use as little water as possible the clay was too soft to hold. when drawing. 2.Opening rapidly expands, 2. Keep your hands moving from deformation and collapse. the bottom to the top. 3.The wall is thick on the top and 3.
- Page 14 Water basin is leaking. 1.The water exceeds the 1.Check whether the waterproofing edge of the storage of mud water basin. exceeds the waterproof 2.The water basin is not edge. installed properly. 2.Check that water basin is properly installed. The turntable jumps too The fastener is loose.
- Page 16 Technical Support and E-Warranty Certificate www.vevor.com/support...
