VEVOR LSZLK-515 User Manual

VEVOR LSZLK-515 User Manual

Pottery wheel machine
Hide thumbs

Advertisement

Quick Links

Download this manual
Support and E-Warranty Certificate
https://www.vevor.com/support
POTTERY WHEEL MACHINE
USER MANUAL
We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price",
or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not
necessarily mean to cover all categories of tools offered by us. You are kindly reminded to
verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LSZLK-515 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VEVOR LSZLK-515

Summary of Contents for VEVOR LSZLK-515

  • Page 1 Support and E-Warranty Certificate https://www.vevor.com/support POTTERY WHEEL MACHINE USER MANUAL We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price", or any other similar expressions used by us only represent an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us.
  • Page 3 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS WARNING：Read all safety warnings, instructions, illustrations and specifications provided with this electrical equipment. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. Warning - To reduce the risk of injury, user must read instructions manual carefully.

  • Page 5: Structure Diagram

    9.Periodically check whether the power cable is damaged and the connector is loose. 10.Press button(10A) on the leakage protector once a month to check whether the leakage protection can work normally! MODEL AND PARAMETERS Model LSZLK-515 Maximum Payload(Clay) 8 KG Voltage 100-240V～ 50/60Hz...
  • Page 6 1.Removable water basin 2. Density board 3.Aluminum turntable 3A:Positioning pin hole 4.Equipment body 5.Manual adjusting lever 6.Speed regulating pedal 7.Touch panel 7A:Forward/reverse switch 7B:Manual/pedal switch 7C:Slow down 7D:Acceleration 7E:Display 7F:Touch switch 8.Foot Pad 9.Power line 10.Leakage protector 10A:Test button (Press once a month. It is normal if the indicator goes off after you press it) 10B:Reset button (If the power is off, please first remove the leakage danger, and then press this key to restore the power.)
  • Page 7 2. 23-Piece Tool Set(x1) Clay-repair knife(A): For engraving. Indentation pen and pellet stick(B): For molding/clay opening. Silica gel pen(C): For erase/brush/color.
  • Page 8 3. Stainless steel clay-repair knife 8-piece Set(x1): Repair clay molds as shown below.

  • Page 9: Operating Steps

    4.Aluminium turntable（Φ280mm):The size of the turntable depends directly on the maximum diameter we can achieve. （Loosen the bolt with a wrench and replace it） 5.Density board:Used for easy drying,install three socket head screws on the aluminum plate, and then align the density plate with the screw and install it. OPERATING STEPS Step1: Take out a proper amount of clay, throw the mud ball in the center of the wheel, and press it (wet your hands).
  • Page 10 Step3: Turn on the switch and choose the direction of forward (clockwise)/reverse (counterclockwise) rotation according to your needs. Step4: Choose manual speed control/pedal speed control according to personal needs. Step5: Push the lever/pedal to adjust the speed and start clay molding with tools. Step5:Clay-mold repairs with tools.
  • Page 11 SKILLS GUIDANCES Problem Reason Solution Fracture of clay. Excessive force during The lifting process should lifting. be small and even. Clay is in a spiral shape. The clay molding speed Turn the mold a few times in exceeds the machine advance.
  • Page 12 clay, then start the machine to smooth the surface. Uneven thickness when Hands are not on parallel The inner and outer lifted. lines or uneven force. fingertips must move synchronously in a straight line when lifting the clay. Mold collapsed. 1.There was too much water 1.
  • Page 13 TROUBLESHOOTING INSTRUCTION Problem Reason Solution Does not work. The power supply is not 1.Check whether the power connected. plug is properly inserted. 2.Check whether the leakage protector is on. Shaking of the machine The machine is not level Adjust the four feet of the with the ground.
  • Page 14 CLEAN AND CARE RULES 1. After finishing the equipment operation, it is necessary to clean the clay on the surface of the turntable and wipe the water stains on the surface of the turntable (Do not rinse directly with water). 2.
  • Page 16 Support and E-Warranty Certificate https://www.vevor.com/support...
