Support and E-Warranty Certificate
https://www.vevor.com/support
POTTERY WHEEL MACHINE
USER MANUAL
We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price",
or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not
necessarily mean to cover all categories of tools offered by us. You are kindly reminded to
verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR LSMNSP-515
Summary of Contents for VEVOR LSMNSP-515
- Page 1 Support and E-Warranty Certificate https://www.vevor.com/support POTTERY WHEEL MACHINE USER MANUAL We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price", or any other similar expressions used by us only represent an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING：Read all safety warnings, instructions, illustrations and specifications provided with this electrical equipment. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. Warning - To reduce the risk of injury, user must read instructions manual carefully. -
Page 4: Structure Diagram
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision). MODEL AND PARAMETERS Model LSMNSP-515 Maximum Payload(Clay) Voltage 100-240V～ 50/60Hz Power... - Page 5 4.Speed regulation switch 5.Forward/reverse switch 6.Power plug TOOL ACCESSORIES AND USE 1.Apron(x1): Prevent clothes from getting dirty. 2. 8-Piece Tool Set(x1)
- Page 6 A(Clay cutting line): Assist in precisely cutting clay (cutting surface is very smooth)/repairing and leveling the mouth of the work/taking away the finished product. B(Small yellow sponge): Add water or absorb water/trim the surface or mouth edge to make it smooth. C(Wooden knife):Trim the bottom for later removal/trimming.
- Page 7 E(Stainless steel scraper): Remove the excess clay on the surface to make it smooth. F(Circular large flat wire knife): Trim the surface of the vessel/ control the thickness/trim out the bottom ring foot. G(Steel needle): Scrape off excess clay from the mouth edge/remove air bubbles/punch holes.
- Page 8 3.Plastic Printing 8-piece Set(x1): Texture decoration, bonding, clay modeling, and so on(As shown below). 4.Aluminium turntable （ Φ65mm+Φ100mm): The size of the turntable depends directly on the maximum diameter we can achieve. （Loosen the bolt with a wrench and replace it）...
-
Page 9: Operating Steps
OPERATING STEPS Step1:Take out a proper amount of clay, knead it into a cone shape, fix it at the center of the rotary table, and press it (wet your hands). Step2: Plug in the power (If the water basin is not installed, install the water basin first). Step3:Choose the direction of forward (clockwise)/reverse (counterclockwise) rotation according to your needs. - Page 10 Step5:Clay molding with tools. Step6:Dry the body surface quickly with a hot air gun (1-3 minutes). Step7:Clay-mold repairs with tools. Step8:Creative painting and coloring can be carried out according to their own needs. After the work is completed,stop the machine in reverse order. Remove the molding with a scraper/clay cutting line.
- Page 11 SKILLS GUIDANCES Problem Reason Solution Fracture of clay Excessive force during The lifting process should lifting be small and even. Clay is in a spiral shape. The clay molding speed Turn the mold a few times in exceeds the machine advance.
- Page 12 clay, then start the machine to smooth the surface. Uneven thickness when Hands are not on parallel The inner and outer lifted. lines or uneven force. fingertips must move synchronously in a straight line when lifting the clay. Mold collapsed. 1.There was too much water 1.
- Page 13 TROUBLESHOOTING INSTRUCTION Problem Reason Solution Does not work. The power supply is not 1.Check whether the power connected. plug is properly inserted. 2.Check whether the leakage protector is on. Shaking of the machine The machine is not level Adjust the four feet of the with the ground.
- Page 14 Manufacturer:Hebei Lesheng Teaching Equipment Co., Ltd. ADD:East of Xingye Street, North of Hai'an Road, Haixing County, Cangzhou City, Hebei Province Importer: WAITCHX Address: 250 bis boulevard Saint-Germain 75007 Paris Made in China...
- Page 16 Support and E-Warranty Certificate https://www.vevor.com/support...
