ASSEMBLY INSTRUCTIONS
Satori Cal King Bed
NON-STORAGE BED - ITEM No.: 54003195H/ 54003195R/ 54003195F
or
STORAGE BED - ITEM No.: 54003195H/ 54003195R/ 54003195SF
(BOX 1)
Box of Headboard
COMPONENT#
54003195H
(BOX 2)
Box of Siderails, Metal Centre Rail, Slat Set
COMPONENT#
54003195R
(BOX 3) NON-STORAGE
Box of Regular Footboard
54003195F
(BOX 3) STORAGE
Box of Storage Footboard
54003195SF
DESCRIPTION
QUANTITY
Headboard
1
DESCRIPTION
QUANTITY
Siderail
2
Slat Set
14
Metal Centre Rail
2
Footboard
1
Footboard w/Storage
1
(BOX 3)
Siderails, Metal Centre Rail, Slat Set Hardware List
COMPONENT#
Z1
Z3
Z4
Z2
Z3
Z4
Z5
Z6
Z7
NOT PROVIDED
DESCRIPTION
QUANTITY
Bolt: Ø 10 x 70mm
Sping Washer: Ø 10 x 15 x 2.6mm
8
Washer: Ø 10 x 23 x 2mm
Bolt: Ø 10 x 30mm
Sping Washer: Ø 10 x 15 x 2.6mm
8
Washer: Ø 10 x 23 x 2mm
Open Wrench
1
Ø17
Screw: Ø4mm x 30mm
4
Screwdriver
1
COMPLETED BED ASSEMBLY
Page 1 of 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces Satori 54003195H
Summary of Contents for Living Spaces Satori 54003195H
- Page 1 ASSEMBLY INSTRUCTIONS Satori Cal King Bed NON-STORAGE BED - ITEM No.: 54003195H/ 54003195R/ 54003195F STORAGE BED - ITEM No.: 54003195H/ 54003195R/ 54003195SF (BOX 1) (BOX 3) Box of Headboard Siderails, Metal Centre Rail, Slat Set Hardware List COMPONENT# IMAGE DESCRIPTION QUANTITY COMPONENT# IMAGE...
