MAS90: 5043-43240
SUMMIT BED FRAME HARDWARE
QTY:
8
100MM DECORATIVE HEAD LAG BOLTS
1
4MM ALLEN WRENCH
10
6 X 1 1/4" PHIL FLAT PARTICLE BOARD SCREW
4MM POWER DRILL DRIVER
1
ASSEMBLY: 1 PERSON AND 30 MINUTES
TOOLS:
1)
4 mm Allen Wrench (INCLUDED)
2)
4 mm Allen Drill Bit
(Be sure to FULLY SEAT bit into bolt head before turning)
3)
Phillips Head Screwdriver
*We recommend using a power driver with the drill bit if available*
BE SURE THAT LAG BOLTS ARE STARTED INTO THE HOLES ON THE FRAME RAILS DURING ASSEMBLY.
DO NOT FULLY TIGHTEN UNTIL ASSEMBLY IS LOOSELY COMPLETE.
DESCRIPTION:
7030-00453 KIT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces 5043-43240
Summary of Contents for Living Spaces 5043-43240
- Page 1 7030-00453 KIT MAS90: 5043-43240 SUMMIT BED FRAME HARDWARE QTY: DESCRIPTION: 100MM DECORATIVE HEAD LAG BOLTS 4MM ALLEN WRENCH 6 X 1 1/4" PHIL FLAT PARTICLE BOARD SCREW 4MM POWER DRILL DRIVER ASSEMBLY: 1 PERSON AND 30 MINUTES TOOLS: 4 mm Allen Wrench (INCLUDED)
- Page 2 3) Install pulls on drawer fronts and knob on footboard door with supplied machine screws, and slide 4Drw Underdresser into position below mattress rail on your choice of side of bed. 4) Add the proper thickness innerspring bunk mattress. See Living Spaces for details.
