- Page 1 VRF (Variable Refrigerant Flow) Installation manual V36D0**S6-5P • Thank you for purchasing this Lennox Product. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Installation Procedure Step 1 Checking and preparing accessories Step 2 Choosing the installation location Step 3 Optional: Insulating the body of the indoor unit Step 4 Installing the indoor unit Step 5 Optional: Installing the circular panel Step 6 Purging inert gas from the indoor unit Step 7 Cutting and flaring the pipes Step 8 Connecting the assembly pipes to the refrigerant pipes... -
Page 3: Safety Information
Safety Information California Proposition 65 Warning (US) Symbol Meaning Cancer and Reproductive Harm - WARNING: www.P65Warnings.ca.gov. Flammable gas IMPORTANT – This product has been designed and manufactured to meet ENERGY STAR criteria for energy efficiency when matched with appropriate coil components. Flammable materials However, proper refrigerant charge and proper air flow are critical to achieve rated capacity and efficiency. -
Page 4: General Information
Safety Information General information • The air conditioner contains a refrigerant that must be disposed of as special waste. At the end of its life cycle, the air conditioner must be disposed of in authorized WARNING centers or returned to the retailer so it can be disposed of correctly and safely. -
Page 5: Power Supply Line, Fuse Or Circuit Breaker
• Do not use the air conditioner in environments with hazardous • Verify that the air conditioner is connected to the power substances or close to equipment that releases free flames to supply following the instructions provided in the wiring avoid the occurrence of fires, explosions or injuries. -
Page 6: Precautions For Using R-32 Refrigerant
Safety Information Precautions for using R-32 refrigerant • Installation, servicing, and any type of maintenance or repair must be performed by certified personnel who are competent to carry out such activity following national General and local regulations. • This product is pre-charged with mildly flammable gas General information on Servicing classified as A2L by ASHRAE. - Page 7 Electrical repair safety measures Charging procedure • All electrical components used or replaced must be to • Follow industry standard refrigerant charging best practices. LENNOX’s specifications. • Before recharging the system shall be pressure tested • If a fault exists that could compromise safety, then no with oxygen free nitrogen gas.
-
Page 8: Installation Procedure
Installation Procedure Step 1 Checking and preparing Step 2 Choosing the installation accessories location The following accessories are supplied with the indoor unit. The type and quantity may differ, depending on the Installation location requirements specifications. • There must be no obstacles near the air inlet and outlet. Insulation pipe (3 ea) Cable-tie (6 ea) •... - Page 9 CAUTION • As a rule, the unit cannot be installed at a height of less than 8.2ft (2.5m). • If you install a cassette type indoor unit on the ceiling when the temperature is over 80.6°F (27°C) and humidity is over 80%, you must apply an extra 0.39inch (10mm) thick polyethylene insulation or a similar type of insulation to the body of the indoor unit.
- Page 10 Installation Procedure Installation conditions for indoor units and wired remote controls • Make sure to install a dedicated R-32-capable wired remote control for each indoor unit. See the installation examples below for reference. Make sure to use R-32-capable wired remote controls. The product will not operate if an R-32-capable wired remote control is not located in the vicinity or if users try to control the product using a common wired remote control.
- Page 11 Make sure to connect all indoor units to respective R-32-capable wired remote controls. At least one remote control must be installed for each indoor unit, even if multiple indoor units are installed in the same room. Group control is not possible. Outdoor unit Outdoor unit Indoor unit...
-
Page 12: Indoor Unit Dimensions
Installation Procedure Indoor unit dimensions Unit : inch (mm) Category Square panel Circular panel 39.40 (1000) 14.11 (358) 41.37 (1050) 34.79 (883) Front 4.57 (116) Ceiling opening dimension [37.40 (950) - 37.80 (960)] 15.17 (385) 15.92 (404) 14.07 (357) Large 15.17 (385) 15.92 (404) 14.07 (357) Small... -
Page 13: Spacing Requirements
V36D009S6-5P V36D030S6-5P Model V36D012S6-5P V36D024S6-5P V36D036S6-5P V36D018S6-5P V36D048S6-5P 37.28 x 37.28 x 11.06 37.28 x 37.28 x 14.37 Net dimension (W x D x H) inch (mm) (947 x 947 x 281) (947 x 947 x 365) Liquid pipe connection inch (mm) 1/4 (6.35) 3/8 (9.52) -
Page 14: Step 3 Optional: Insulating The Body Of The Indoor Unit
Installation Procedure CAUTION NOTE • A: Reference for the outer circumference of the unit • Comply with the length and height limits described in the (When insulating the body of the indoor unit, use A as figure above. the reference for its outer circumference.) •... - Page 15 Perform the following steps to install inspection holes Install the suspension bolts, depending on the ceiling type. per panel type. For the recessed installation of the square panel. • Install an inspection hole in the direction of the connection parts of the refrigerant pipe and the Ceiling support drain hose.
-
Page 16: Step 5 Optional: Installing The Circular Panel
Installation Procedure Adjust the unit to the appropriate position, considering Put a pencil at the opposite side of the pivot point fixed the installation area for the front panel. in place. • Place the pattern sheet on the indoor unit. •... -
Page 17: Step 6 Purging Inert Gas From The Indoor Unit
Step 6 Purging inert gas from the To prevent any gas from leaking out, remove all burrs at the cut edge of the pipe, using a reamer. indoor unit Slide a flare nut onto the pipe and modify the flare. The indoor unit comes with nitrogen gas (inert gas) charged at the factory. -
Page 18: Step 8 Connecting The Assembly Pipes To The Refrigerant Pipes
Installation Procedure Step 8 Connecting the assembly pipes Be sure to use an insulator thick enough to cover the refrigerant tube to protect the condensate water on the to the refrigerant pipes outside of the pipe falling onto the floor and to improve the efficiency of the unit. -
Page 19: Step 10 Insulating The Refrigerant Pipes
Refer to the outdoor unit installation manual for the Finish wrapping insulating tape around the rest of the complete steps for pressure testing and vacuuming the pipes leading to the outdoor unit. system before charging with refrigerant. The pipes and electrical cables connecting the indoor unit with the outdoor unit must be fixed to the wall with suitable ducts. -
Page 20: Step 11 Installing The Drain Hose And Drainpipe
Installation Procedure Insulation type (heating/cooling) General High humidity Pipe size Pipe Remarks [86°F (30°C), 85%] [86°F (30°C), 85%] EPDM, NBR inch inch inch 1/4 to 3/8 6.35 to 9.52 Liquid pipe Heating 1/2 to 2 12.7 to 50.80 resisting 6.35 temperature 3/8 to 1 9.52 to 25.40... - Page 21 • Install an air vent to drain condensation smoothly. • Do not apply force to the piping on the unit side when connecting the drain hose. The hose should not be allowed to hang loose from its connection to the unit. Fasten the hose to Air ventilation a wall, frame or other support as close to the unit as possible.
-
Page 22: Step 12 Performing The Drainage Test
Installation Procedure Step 12 Performing the drainage test NOTE • If a common drainpipe is installed, refer to the figure Do a leak test at the connection part of the flexible hose below. and the drainpipe: Main air vent Connect a general hose to the connection part Full thread (must be installed) bolt hanger... - Page 23 Check the condensed water drainage: CAUTION Pour about 2 liters (0.54 gal) of water into the • When the float switch is not detected due to insufficient water on indoor unit drain pan as shown in the picture. the drain pan, the drain pump will not work. •...
-
Page 24: Step 13 Connecting The Power And Communication Cables
Installation Procedure Step 13 Connecting the power and communication cables Bushing bracket installation When conduit is used, conduit mounting brackets must be installed as shown in the picture to attach the conduit. Indoor unit Push < 1 conduit tube > <... - Page 25 Connecting the power and communication • Before wiring work, you must turn off all power source. cables • Connect the power and communication cable among the units within maximum length to set the voltage drop under 10%. CAUTION • The auxiliary circuit breaker (ELCB, MCCB, ELB) should be considered more capacity if many indoor units are •...
- Page 26 Installation Procedure MCCB+ 1(L) 2(N) 1(L) 2(N) 1(L) 2(N) ELCB Indoor Unit 1 Indoor Unit 2 Indoor Unit 3 F3 F4 F1 F2 F1 F2 F1 F2 Wired remote control Selecting the crimping terminal lug Select the crimping terminal lug based on the norminal dimension of the power cable. Cover the connection part of the power cable and crimping terminal lug to insulate it.
- Page 27 Specifications of the terminal blocks Rated currents Model Rating current (A) Unit: inch(mm) V36D009S6-5P 0.18 Communication: M3.5 screw AC power: M4 screw V36D012S6-5P 0.18 0.43(11) 0.3(7.5) 0.35(9) V36D018S6-5P 0.18 V36D024S6-5P 0.28 V36D030S6-5P 0.42 0.51(13) V36D036S6-5P 0.57 V36D048S6-5P 0.75 Power supply MCCB (single phase) Decide the power cable specification and maximum...
- Page 28 Installation Procedure Example of Installation Total power cable length L = 328.08ft(100m), Initial pull-in current = 10[A], Running current of each units = 1[A], Total 10 indoor units were installed 9 [A] 10 [A] 1 [A] MCCB+ELB ELCB Indoor unit 1 Indoor unit 2 Indoor unit 10 0 [ft] (0m)
-
Page 29: Step 14 Optional : Led Display Indicator Specifications When Checking Wi-Fi Easy Setup And Wi-Fi Status
Step 14 Optional : LED Display indicator specifications when checking Wi-Fi Easy Setup and Wi-Fi status The wireless remote control can be used for Easy Setup, checking the internet connection status and connecting or disconnecting Wi-Fi. Easy Setup Check internet connection status Enable/Disable Wi-Fi Press the button for... -
Page 30: Led Indicator Status
Installation Procedure LED Indicator Status LED Display LED indicator for wind LED color of indicator lights direction 360 Cassette Remarks Measure Wide Spot Yellow blue blue green ● ● ● ● AP entry All LED lights are on Check device ◑... -
Page 31: Step 15 Setting The Indoor Unit Addresses And The Installation Options
Step 15 Setting the indoor unit Make sure that you are entered to the mode for setting options. addresses and the installation options You cannot set both indoor unit addresses and the installation options in a batch: set both respectively. 2 Digit Common steps for setting the addresses and 10 point ( 2SEG per point) - Page 32 Installation Procedure Take the steps presented in the following table: Steps Remote control display Set the SEG2 and SEG3 values: Set the SEG2 value by pressing the button repeatedly until the value you want to set appears on the remote control display. SEG2 Set the SEG3 value by pressing the button repeatedly until the value you want...
- Page 33 Steps Remote control display Set the SEG6 and SEG8 values: Set the SEG6 value by pressing the button repeatedly until the value you want to set appears on the remote control display. SEG6 Set the SEG8 value by pressing the button repeatedly until the value you want to set appears on the remote control display.
- Page 34 Installation Procedure Steps Remote control display Set the SEG11 and SEG12 values: Set the SEG11 value by pressing the button repeatedly until the value you want to set appears on the remote control display. SEG11 Set the SEG12 value by pressing the button repeatedly until the value you want to set appears on the remote control display.
- Page 35 Steps Remote control display 13 Set the SEG16 and SEG17 values: Set the SEG16 value by pressing the button repeatedly until the value you want to set appears on the remote control display. SEG16 Set the SEG17 value by pressing the button repeatedly until the value you want to set appears on the remote control display.
- Page 36 Installation Procedure Steps Remote control display 17 Set the SEG21 and SEG22 values: Set the SEG21 value by pressing the button repeatedly until the value you want to set appears on the remote control display. SEG21 Set the SEG22 value by pressing the button repeatedly until the value you want to set appears on the remote control display.
-
Page 37: Setting The Indoor Unit Addresses
Setting the indoor unit addresses (MAIN/ Check whether the option values you have set are RMC/MCU) correct by pressing the button repeatedly. [SEG2, SEG3] [SEG4, SEG5] [SEG6, SEG8] [SEG9, SEG10] [SEG11, SEG12] Make sure that the power is supplied to the indoor unit. •... -
Page 38: Setting The Installation Options In A Batch
Installation Procedure Setting the installation options in a batch Option No. for an indoor unit address: 0AXXXX-1XXXXX-2XXXXX-3XXXXX Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 100-digit of an indoor 10-digit of an indoor The single digit of an Function Page Mode Setting main address unit address unit address... - Page 39 Setting the indoor unit installation CAUTION option (suitable for the condition of each installation location) • If you enter A to F to the SEG5 or SEG6, the indoor unit main address is not changed. • If you enter 0 to the SEG3, the indoor unit maintains the Make sure that the power is supplied to the indoor unit.
- Page 40 Installation Procedure Installation options for the 02 series SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 Use of external temperature Compensation sensor / Minimizing fan operation Use of central control of the fan RPM when thermostat is off SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 Settings for load operation during...
- Page 41 Installation options for the 02 series (detailed) Option No. for an indoor unit address: 02XXXX-1XXXXX-2XXXXX-3XXXXX Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 Use of external temperature sensor / Compensation of the Function Page Mode Minimizing fan operation when thermostat Use of central control fan RPM is off Details...
- Page 42 Installation Procedure Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 Settings for load operation during heater control Use of hot water EEV step when Function Page Use of drain pump Fan control during defrost mode / Heater control during heater heating stops defrost mode Detail Indication Details Indication Details Indication...
- Page 43 Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 Setting the output of external Buzzer control / whether to use humidity Use of external Maximum filter Function Page control / External heater On or S-Plasma ion sensor / whether to use APP UX DSP (Dual Set control usage time Off signal...
- Page 44 Installation Procedure Option SEG19 SEG20 SEG21 SEG22 Individual control Heating setting compensation offset / Removing condensated water in EEV step of stopped unit during the Function Page with remote control the Heat mode oil return or the defrost mode Details Indication Details Indication Details Indication Indication Details...
- Page 45 (*4) Default setting value: 9 ℉ (5 ℃) (*5) If the air conditioner operates in the Heat mode immediately after finishing the cooling operation, the condensated water in the drain pan becomes water steam by the heat of the indoor unit heat exchanger. Since the water steam might be condensed on the indoor unit, which may fall into a living space, use this function to remove the water steam out of the indoor unit by operating the fan (for maximum 20 minutes) although the indoor unit is turned off after the Cool mode is turned to the Heat mode.
- Page 46 Installation Procedure Installation options for the 05 series (detailed) Option No. : 05XXXX-1XXXXX-2XXXXX-3XXXXX Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 (When setting (When setting SEG3) SEG3) Use of the HR-specific (When setting SEG3) auto changeover Offset for Reference for Function Page Mode Offset for the heating...
- Page 47 Option SEG13 SEG14 SEG15 SEG16 SEG17 Function Dual fuel (heater lock) setting Dual fuel (HP lock) setting Indication Detail Indication Detail Disuse Disuse 64.9 ℉ (18.3 ℃) 45.0 ℉ (7.2 ℃) 60.1 ℉ (15.6 ℃) 39.9 ℉ (4.4 ℃) 55.0 ℉ (12.8 ℃) 35.1 ℉...
- Page 48 Installation Procedure Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24 Whether to use UV LED / whether to use BLE Onboarding / Forcing FAN Operation for Heating Function whether to allow fan speed control during auto mode / and Cooling MDS (motion detection sensor) control UX type Details Detail Whether to...
- Page 49 Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24 Whether to use UV LED / whether to use BLE Onboarding / Forcing FAN Operation for Heating Function whether to allow fan speed control during auto mode / and Cooling MDS (motion detection sensor) control UX type Use (Fan: Fan speed and power saving mode can Disuse...
- Page 50 Installation Procedure (*1) Height difference: The difference of the height between the target indoor unit and the indoor unit installed at the lowest place. For example, When the target indoor unit is installed 131.23 ft. (40 m) higher than the indoor unit installed at the lowest place, set the option to 1.
- Page 51 Changing the addresses and options individually When you want to change the value of a specific option, refer to the following table and follow the steps in Common steps for setting the addresses and options on page 31. Option SEG1 SEG2 SEG3 SEG4...
- Page 52 Installation Procedure For controlling AC LAMP (On/Off) R-32 CHECK : CN833(YELLOW) AC LAMP AC POWER SUPPLY 208~240VAC (50/60Hz) ※ Use of the WIRE HARNESS included in the product manual To Main PBA VSTAT10P-1 For controlling EXTERNAL ALARM (On/Off) R-32 CHECK : CN833(YELLOW) EXTERNAL ALARM ※...
-
Page 53: Performing Final Check And Trial Operation
Performing final check and trial operation To complete the installation, perform the following checks and tests to ensure that the air conditioner operates correctly. Check the followings. • Strength of the installation site • Tightness of pipe connection to detect a gas leak •... -
Page 54: Appendix
Appendix Troubleshooting Detection of errors • If an error occurs during the operation, an LED flickers and the operation is stopped except the LED. • If you re-operate the air conditioner, it operates normally at first, then detect an error again. LED Display on the receiver &... - Page 55 Indoor unit display indications Condition of the indoor unit Error code Yellow Ice blue Blue green No communication occurs between the indoor and outdoor units for 2 minutes. E101 Communication error received from the outdoor unit E102 Error of 3 minute tracking on the outdoor unit E202 The number of the installed indoor units that is transmitted via E201...
