VRF (Variable Refrigerant Flow)
User manual
VVCD***S6-5P
• Thank you for purchasing this Lennox Product.
• Before operating this unit, please read this manual carefully and retain it for future reference.
DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 1
DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 1
2025-01-10 오후 1:38:18
2025-01-10 오후 1:38:18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lennox VVCD S6-5P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung Lennox VVCD S6-5P Series

Summary of Contents for Samsung Lennox VVCD S6-5P Series

  • Page 1 VRF (Variable Refrigerant Flow) User manual VVCD***S6-5P • Thank you for purchasing this Lennox Product. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 1 DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 1 2025-01-10 오후 1:38:18 2025-01-10 오후...

  • Page 2: Table Of Contents

    Contents Safety Information Safety Information At a Glance Indoor Unit Overview Cleaning and Maintaining Maintaining the Air Conditioner Periodical checks Appendix SmartThings app Troubleshooting Operation Features Operating temperature and humidity Regulatory Notice 2 English DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 2 DB68-13479A-00_IB_VRF R32 MPAHU_AA_EN_.indd 2 2025-01-10 오후...

  • Page 3: Safety Information

    Safety Information Safety Information California Proposition 65 Warning (US) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to operate the extensive features and functions of your new appliance safely and efficiently. Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual.

  • Page 4: Flammable Materials

    Safety Information WARNING Hazards or unsafe practices may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. Follow directions. Do NOT attempt. Make sure the machine is grounded to prevent electric shock. Cut off the power supply.

  • Page 5: Installation

    INSTALLATION WARNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. • Extending the power line may result in electric shock or fire. •...
  • Page 6 Safety Information Do not install this appliance near a heater, or flammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not install this appliance in a location where gas may leak. •...
  • Page 7 When installing the outdoor unit , make sure to connect the draining hose so that draining is performed correctly. • The water generated during the heating operation by the outdoor unit may overflow and result in property damage. In winter, if a block of ice falls, it may result in injury, death or property damage.
  • Page 8 Safety Information FOR USING WARNING If the appliance is flooded, please contact your nearest service center. • Failing to do so may result in electric shock or fire. If the appliance generates a strange noise,or a burning smell of smoke, cut off the power supply immediately and contact the nearest service center.
  • Page 9 Do not touch the circuit breaker with wet hands. • This may result in electric shock. Do not turn the air conditioner off with the circuit breaker while it is operating. • Turning the air conditioner off and then on again with the circuit breaker may cause a spark and result in electric shock or fire.
  • Page 10 Safety Information Do not use this air conditioner for long periods in badly ventilated locations or near infirm people. • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Lennox.
  • Page 11 When the air conditioner does not operate properly for cooling or heating, there is a possibility of refrigerant leakage. If there is any leakage, stop operation, ventilate the room, and consult your dealer to recharge the refrigerant. The refrigerant is not harmful. However, if it comes in contact with fire, it may generate harmful gases and there is a risk of fire.
  • Page 12 Safety Information Do not apply a strong impact to the remote controller and do not disassemble the remote controller. Do not touch the pipes connected to the product. • This may result in burns or injury. Do not cut or burn the refrigerant container or piping. Do not point the air direction to a fireplace or heater.

  • Page 13: For Cleaning

    FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops.

  • Page 14: At A Glance

    At a Glance Indoor Unit Overview Indoor Unit Overview Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. Air intake Air outlet NOTE...

  • Page 15: Cleaning And Maintaining

    Maintaining the Air Conditioner If the air conditioner will not be used for an extended time, dry the air conditioner to maintain it in the best condition. 1 Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and then turn off the power. There may be internal damage if moisture is left in components.

  • Page 16: Appendix

    (with at least 2 GB RAM) and iOS 12.0 or later. The 2 Turning off "Switch to mobile data" at app is optimized for iPhone 6s or later and Samsung "Settings > Wi-Fi" on your Smartphone smartphones (Galaxy S and Note series).
  • Page 17 Select NOTE You can add a product you want to connect to • If you already have a Samsung account, log in by selecting it manually or by selecting "Scan to the account. If you have a smartphone that nearby".

  • Page 18: Open Source Announcement

    Open Source Announcement • If a Samsung account-related country error occurs while connecting to your product, log out of your current Samsung account, log in to your The software included in this product contains open previous Samsung account, and then delete all source software.

  • Page 19: Troubleshooting

    Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution • Connect an R-32-capable wired remote control. The product does not work. * VSTAT04P-1 Error E694 * R-32-capable wired remote controls should be purchased separately. •...
  • Page 20 Troubleshooting Problem Solution • This error occurs when the R-32 refrigerant sensor has a malfunction or the sensor’s life has expired. • Display "E116" or "E698" when a sensor failure occurs The product does not • The R-32 sensor’s lifespan is 10 years. work.
  • Page 21 Problem Solution • Check whether the wireless controller is charged. Charge the controller if needed. The wireless remote • Make sure that nothing is blocking the remote control sensor. control does not • Check whether any strong lighting sources are near the air conditioner. Strong operate.
  • Page 22 Troubleshooting Problem Solution • Close the windows and doors to maximize the cooling and heating efficiencies. • If the Cool mode is stopped and then started immediately, cool air comes out after about 3 minutes to protect the compressor of the outdoor unit. The air is not cool or warm enough.
  • Page 23 I found a failure app and then try adding the device again. message in 99 percent of device addition • If your phone is not a Samsung product, check that you process. have entered a wrong Wi-Fi password. Try adding devices Adding device(s) again.

  • Page 24: Operation Features

    Operation Features Operation Features Operating temperature and humidity When using the air conditioner follow the operating temperature and humidity ranges. Mode Outdoor temperature Indoor temperature Indoor humidity Cool mode 64°F to 86°F (18°C to 30°C) 80% or less Depending on the outdoor unit Heat mode 86°F (30°C) or less specifications...

  • Page 25: Regulatory Notice

    Regulatory Notice FCC Notice FCC CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This appliance contains the transmitter module. This device complies with Part 15 of FCC Rules. Operation is Subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation.

  • Page 26: Ic Radiation Exposure Statement

    Regulatory Notice IC Notice This appliance contains the transmitter module. The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions : (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
