- Page 1 Mini-Split User manual MMDD***S6-1P, MDDD***S6-1P • Thank you for purchasing this Lennox Product. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Cleaning and Maintenance Cleaning and Maintaining Cleaning the air filter Periodical maintenance Appendix SmartThings app Troubleshooting Operation Features 2 English... -
Page 3: Safety Information
Safety Information California Proposition 65 Warning (US) Cancer and Reproductive Harm - WARNING: www.P65Warnings.ca.gov. Before using your new mini-split, please read this manual thoroughly to ensure that you know how to operate the extensive features and functions of your new appliance safely and efficiently. Because the following operating instructions cover various models, the characteristics of your mini-split may differ slightly from those described in this manual. - Page 4 Safety Information This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Fcc Caution
Symbol Meaning Flammable gas flammable materials Refrigerant Refrigerant safety group Safety Group Read operating manual Refer to operating manual Read service manual FCC Notice FCC CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 6: Fcc Radiation Exposure Statement
Safety Information (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation. For products available in the US and Canadian markets, only channels 1~11 are available. You cannot select other channels. FCC STATEMENT: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC... -
Page 7: Ic Radiation Exposure Statement
This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antennas must not be co-located or operated in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. -
Page 8: Installation
Safety Information INSTALLATION WARNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. • Extending the power line may result in electric shock or fire. •... - Page 9 • If the outdoor unit falls, it may result in injury, death or property damage. This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. • Failure to do so may result in electric shock, fire, an explosion, or other problems with the product.
- Page 10 Safety Information FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact your nearest service center. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 11 In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power line. Do not touch the appliance or power line. • Do not use a ventilating fan. • A spark may result in an explosion or fire. To reinstall the mini-split, please contact your nearest service center.
- Page 12 Safety Information • This may result in electric shock or burns. Do not insert your fingers or foreign substances into the outlet when the mini-split is operating, or the front panel is closing. • Take special care that children do not injure themselves by inserting their fingers into the product.
- Page 13 • Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse. • Failing to do so may result in electric shock, fire, problems with the product, or injury. CAUTION Do not place objects or devices under the indoor unit. •...
- Page 14 Safety Information • This may result in electric shock, fire, problems with the product, or injury. Do not operate the appliance with wet hands. • This may result in electric shock. Do not spray volatile material such as insecticide onto the surface of the appliance.
-
Page 15: For Cleaning
FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops. -
Page 16: At A Glance
At a Glance Indoor Unit Overview MMDD***S6-1P Air filter (Return air inlet) Ceiling Air intake Air outlet MDDD***S6-1P Return air inlet Note: this unit does not have an air filter from the factory Ceiling Air intake Air outlet NOTE • Your mini-split and display may look slightly different from the illustration shown above depending on your model. -
Page 17: Cleaning And Maintenance
Cleaning and Maintenance Cleaning the air filter For the best performance from your mini-split, clean it periodically. When cleaning, make sure to unplug from the unit for the user’s safety. When cleaning the filter, make sure to unplug the power from the unit. A washable foam based Air filter captures large particles from the air. - Page 18 Cleaning and Maintenance Resetting the air filter (Wired and wireless remote controls are optional.) After cleaning and reassembling the air filter, be sure to reset the filter-cleaning reminder as follows : Option • Indoor unit with the wired controller: a. Press the button to display the Option menu.
- Page 19 • Indoor unit with the wireless remote control: In operation ▶ ▶ Select ▶ ▶ Settings. Select ▶ ▶ Filter reset. ▶ CAUTION • The filter reset indicator blinks when the air filter should be cleaned. • Although the filter cleaning indicator ( ) does not light, be sure to set the "Filter Reset"...
-
Page 20: Periodical Maintenance
Cleaning and Maintenance Periodic maintenance If the mini-split will not be used for an extended period, dry the mini-split to maintain it in the best condition. 1. Dry the mini-split thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug. There may be internal damage if moisture is left in components. -
Page 21: Appendix
(with at least 2 GB RAM) and iOS 12.0 or later. The to the network. app is optimized for iPhone 6s or later and Samsung smartphones (Galaxy S and Note series). Advanced... - Page 22 Select NOTE You can add a product you want to connect to • If you already have a Samsung account, log in by selecting it manually or by selecting "Scan to the account. If you have a smartphone that nearby".
-
Page 23: Open Source Announcement
AES is recommended. New Wi-Fi authentication specifications and Wi-Fi non-standard authentication methods are not supported. • The product supports the IEEE802.11 b/g/n (2.4 GHz) communication protocol. (Samsung recommends IEEE802.11n.) • If your Internet service provider permanently has registered the MAC address (a unique... -
Page 24: Troubleshooting
Troubleshooting Refer to the following chart if the mini-split operates abnormally. This may save time and unnecessary expense. Problem Solution The mini-split • Because of the protective mechanism, the appliance does not start does not operate operating immediately to keep the unit from overloading. The mini- immediately after it split will start in 3 minutes. - Page 25 Problem Solution • Ensure the remote control is charged. • Make sure that nothing is blocking the remote control sensor. The wireless remote • Check whether any strong lighting sources are near the mini-split. control does not operate. Strong light that comes from fluorescent bulbs or neon signs may interfere with the remote control.
- Page 26 Troubleshooting Problem Solution • Both cooling and heating do not operate in the Fan mode. Select the Cool, Heat, Auto, or Dry mode. • Check whether the air filter is blocked with dirt. A dusty filter may decrease the cooling and heating efficiencies. Clean the air filter frequently.
- Page 27 99% and a message appears saying that adding • If your phone is not a Samsung product, check that Adding device(s) the device has failed. you have entered the wrong Wi-Fi password. Try adding devices again.
-
Page 28: Operation Features
Operation Features Operating temperature and humidity Indoor unit / Outdoor unit : M*DD***S6-1P / MMLD***S6S-1P Indoor Outdoor Indoor Model Mode If out of conditions temperature temperature humidity 64°F to 90°F 0°F to 122°F Condensation may occur on the Cooling 80% or less (18°C to 32°C) (-18°C to 50°C) indoor unit with the risk of either... - Page 29 Indoor unit / Outdoor unit : MDDD***S6-1P / MMPD***S6S-1P Indoor Outdoor Indoor Mode If out of conditions temperature temperature humidity 64°F to 90°F 0°F to 122°F Condensation may occur on the Cooling 80% or less (18°C to 32°C) (-18°C to 50°C) indoor unit with the risk of either water blow-off or drops on the floor.
- Page 30 Register Product to Receive enhance warranty and view product documentation : https://www.warrantyyourway.com/ QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.lennox.com for homeowners, AMERICA 800-953-6669 www.lennoxpros.com for dealer/contractor...
