Rain Bird IC System Design Manual page 10

Interface Capacities
Wire Path
Driver Board
ICI+ Configuration
Options
Part Numbers
Interface
Configuration
Interface Capacity
*Standard Configuration for most IC Systems
** LINK communication is not compatible with IC System devices. An ICM must be hardwired to an ICI+
wire path, and cannot be connected through a LINK satellite
Flexible Design
The IC System was designed to be as flexible as possible to accommodate the future needs of a golf course.
While each wire path supports 750 ICMs, if the wire path is expected to be at or near maximum capacity,
installing an additional wire path will create additional capacity for future expansion, such as IC CONNECT
products. When designing with multiple wire paths, it is suggested to balance the load between the wire
paths to ensure there is room for future expansion on each wire path.
Example – Total golf course need is 1,100 ICMs. We would suggest you plan on implementing two primary
wire paths with approximately 550 ICMs on each path. The purpose of this is to leave room for expansion
in the future.
10
Maximum of 750 total stations. This may be a combination of hard-wired satellite
or IC stations
Two (2) separate wire paths. Maximum 1,500 stations per driver board
IC System *
(IFX Hybrid Compatible)
HS6020 – 120V
HS6085 – 240V
HS6090 – 100V
Two (2) - 2-Wire driver
boards
3,000 Stations per
interface
IC System-LINK** Hybrid
(North America Only)
HS6099 – 120V Optional:
214111 – 2-wire driver
board
One (1) - LINK driver
board with added 2-Wire
driver board
2,688 LINK Stations and
1,500 2-Wire stations
(IC or Hardwire Satellite)
IC System Design Guide, v2.4
LINK System**
(North America Only)
HS6099 – 120V
North America Only
One (1) - LINK driver
board
2,688 LINK stations
