- Page 1 8510 ® „ MesuReuR nuMéRique De RappoRT De TRansfoRMaTion „ DigiTal TRansfoRMeR RaTioMeTeR „ DigiTales pRüfgeRäT DeR übeRseTzungsveRhälTnisse „ conTaToRe DigiTale Del RappoRTo Di TRasfoRMazione „ MeDiDoR De Relación De TRansfoRMación DigiTal Notice de fonctionnement F R A N Ç A I S User's manual E N G L I S H Bedienungsanleitung...
- Page 2 ENGLISH Thank you for purchasing a digital transformer ratiometer DTR 8510. ® For best results from your instrument: „ read these operating instructions carefully, „ comply with the precautions for use. WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger symbol appears. Equipment protected by double insulation.
-
Page 3: Table Of Contents
CONTENTS 1. PRECAUTIONS FOR USE..............................44 1.1. Receiving Your Shipment ............................44 2. PRODUCT FEATURES ................................45 2.1. Description ................................... 45 2.2. Control Features ................................46 2.3. Cable Identification ..............................47 3. SPECIFICATIONS ................................... 48 3.1. DTR 8510 Specifications ............................48 ®... -
Page 4: Precautions For Use
1. PRECAUTIONS FOR USE These safety warnings are provided to ensure the safety of personnel and proper operation of the instrument. „ This instrument is protected from accidental voltages of not more than 50 V with respect to earth. The guaranteed level of protection of this equipment may be compromised if used in a manner not specified by the manufacturer. -
Page 5: Product Features
2. PRODUCT FEATURES 2.1. DESCRIPTION The Digital Transformer Ratiometer DTR 8510 is a lightweight, rugged, portable instrument designed for onsite testing of power, ® potential and current transformers. Operation of the DTR 8510 is fully automatic. No user calibration, range selection, hand cranking or tedious balancing is required. ®... -
Page 6: Control Features
2.2. CONTROL FEATURES USE SPECIFIED CHARGER ONLY USE ONLY ON DE-ENERGIZED TRANSFORMERS OFF/ CHARGE CONTRAST ENTER 50V CAT IV TEST 8510 ® Digital Transformer Ratiometer Display: Displays data, status and control features of the instrument. USB Connector: Allows connection to a computer for instrument configuration set-up and status check, downloading of the stored data using the DataView software and running a test. -
Page 7: Cable Identification
2.3. CABLE IDENTIFICATION Primary (H) Cable: RED INLINE PLUG "H" IDENTIFIER 5 PIN CONNECTOR H CABLE SET "H" IDENTIFIER BLACK INLINE PLUG Secondary (X) Cable: RED INLINE PLUG "X" IDENTIFIER 3 PIN CONNECTOR X CABLE SET "X" IDENTIFIER BLACK INLINE PLUG Each cable is clearly marked. -
Page 8: Specifications
3. SPECIFICATIONS Reference Conditions: 23°C ± 5°C (30 to 50% RH) range. Add 25 ppm/°C from -10 to 18°C and 28 to 50°C to all accuracy specifications. No external electrical or magnetic fields. Output current ≤150 mA for VT/PT and ≤ 50 mA for CT. Calibration cycle is 1 year. -
Page 9: Battery Charger Specifications
ENVIRONMENTAL Operating Temperature -10° to 50°C Storage Temperature -20° to 60°C Relative Humidity 10 to 85% RH @ 35°C Altitude Up to 2000 meters (6560 ft) SAFETy Safety Rating EN 61010-1; 50 V CAT IV; Pollution Degree 2 Double Insulated CE Marking Pending Specifications are subject to change without notice. -
Page 10: Display Functions
4. DISPLAy FUNCTIONS 4.1. PROGRAM FLOW In order to use the instrument efficiently, it is important to understand the program flow. „ Pressing the and keys simultaneously allows going up one level (if there is a level) in the program flow. (Vertical naviga- tion moving up a level). -
Page 11: Set Clock
„ Set Clock: Allows the setting of Time and Date. „ Setup Nameplate: Allows selection and editing of Present Nameplate voltages or ratios. Predefined ratios can only be edited through DataView ® „ Select Test Type: Allows the selection of Test Type (VT/PT or CT). „... -
Page 12: Setup Nameplate
The Set Clock configuration allows you to format the following: Date Format: Allows the formatting of the date. (MM/DD/YY, DD/MM/YY, YY/MM/DD). Figure 4-6 Time Format: Allows the formatting of the time (12 or 24 hours). Figure 4-7 Set Date and Time: Allows the setting of the date and time in the selected format. Note: Time must be set in the 24-hour format. - Page 13 „ Each Measurement Record will record the Present Nameplate along with other associated parameters and will be available when the data is downloaded. „ The Ratio of the nameplate values must be between 1 and 32767. „ The Nameplate needs to be enabled. If the Nameplate is not enabled, the Deviation % will not be reported after the measure- ments.
-
Page 14: Select Test Type
NOTE: „ Selecting one transformer from the list will replace the values in the Present Nameplate immediately. The values can then be changed in the Edit mode if needed. „ Selecting Edit will allow the user to modify the values in the Present Nameplate. „... - Page 15 4.3.5. SELECT STORAGE MODE From the top level of Configure Instrument, press the or key until Select Storage Mode appears on the display, then press ENTER. Figure 4-16 Select Auto or Manual using or and press ENTER. The display will return to Configure Instrument > Select Storage Mode.
-
Page 16: Erase Memory
The DTR 8510 improves the quality of measurements in the following ways: ® „ Low noise electronics „ Shielded electronics and cables. „ Differential measurements to reduce common-mode effects. „ Ratiometric calculations to reduce dynamic errors. VT/PT Fast Normal Slow Approx Measurement Time 6.5 S 19 S... -
Page 17: Restoring Factory Defaults
NOTE: The language can also be selected immediately at start up. Press and hold the TesT button while turning the unit ON. After initialization, the instrument will display the currently active language. Release the TesT button. The desired language can now be selected. 4.3.9. - Page 18 Figure 4-21 Press the TEST button to move to second screen, which will display Current and Deviation %. Figure 4-22 Press the TEST button to move to the third screen to display the Date and Time. Figure 4-23 Press the TEST button to move to the fourth screen to display the Primary and Secondary voltages of the Present Nameplate at the time the measurement was made.
-
Page 19: Operation
5. OPERATION WARNING: The DTR 8510 is designed for use on de-energized (“dead”) transformers only. Make sure the test sample is ® completely disconnected from AC power and is fully discharged. 5.1. POWER UP Turn the power switch to the ON position. At power up, the instrument goes through an initialization process: „... - Page 20 - Typical Connection RATIO 2.767 : 1 SECONDARY PRIMARY 19920 : 7200CT BLACK BLACK BLACK BLACK - Alternate Connection RATIO 1.383 : 1 PRIMARY SECONDARY 19920 : 7200CT BLACK BLACK BLACK BLACK Figure 5-2 Connect the Primary (H) and Secondary (X) cables to the appropriate connectors on the DTR 8510 and the transformer under test ®...
-
Page 21: Storing The Measurement Record
In this example, the display will appear as shown below. Figure 5-4 If the H/X were reversed, the instrument will display the following error message and terminate the test. Figure 5-5 NOTE: „ If there were a polarity reversal, the Ratio would be displayed negative and it would be blinking. This means either the con- nections are reversed on a given side or the transformer is wound backwards relative to the marking. -
Page 22: Vt/Pt Excitation Current
5.2.3. VT/PT ExCITATION CURRENT Excitation current, displayed in milli-amperes (mA) is the RMS current in the Primary (H) winding due to test excitation. The load- ing on the Secondary (X) winding due to the DTR 8510 is negligible. ® „ The DTR 8510 uses a maximum of 32 Vrms excitation voltage for testing. -
Page 23: Tips For Making Precise Ratio Measurements
Connect the Primary (H) cable to the appropriate connectors on the DTR 8510 and the transformer under test. Connect the ® Secondary (X) cable as a loop through the current transformer hole as shown in the figure. BLACK BLACK Figure 5-7 Press the TEST button. -
Page 24: Ratio Test - 1:1
5.4. RATIO TEST - 1:1 A simple test can be conducted to test functionality of the DTR 8510. ® Connect the H to X cable and separately connect the H to X . This connection simulates a 1:1 transformer. BLACK BLACK Run VT/PT test. -
Page 25: Connections
6. CONNECTIONS 6.1. CONNECTION DIAGRAMS Make sure that the H lead is always connected such that it does not short to the X or X lead directly or through BLACK earth ground. In the diagrams below, the top three are good connections but the bottom two should be avoided. Measurements - OK HR/HB XR/XB... -
Page 26: Polyphase Connections
6.2. POLyPHASE CONNECTIONS - TRANSFORMER - HIGH XFMR TURNS PHASE VOLTAGE VOLTAGE HIGH VOLTAGE LOW VOLTAGE TYPE RATIO WINDING WINDING WINDING WINDING 1 Ø 1 Ø ∆ ∆ ∆ ∆ √ ∆ H • ∆ √ H • ∆ √ X •... -
Page 27: Dataview ® Software
7. DATAVIEW SOFTWARE ® 7.1. INSTALLING DATAVIEW ® DO NOT CONNECT THE INSTRUMENT TO THE PC BEFORE INSTALLING THE SOFTWARE AND DRIVERS. Text text text text. Minimum Computer Requirements: „ Windows XP / Windows Vista & Windows 7 (32/64 bit) „... - Page 28 „ Documents - Shows a list of instrument related documents that you can view. Adobe Reader is required for viewing PDF ® documents supplied with DataView ® DataView, Version x.xx.xxxx option should be selected by default. Select the desired language and then click on Install. The Installation Wizard window will appear.
-
Page 29: Opening The Control Panel
Shortcuts for DataView and each instrument control panel selected during the installation process have been added to your ® desktop. NOTE: If you connected your instrument to the computer before installing the software and drivers, you may need to use the Add/Remove Hardware utility to remove the instrument driver before repeating the process. -
Page 30: Using The Control Panel
Select Configure Instrument. The Select Instrument dialog box will appear. Figure 7-6 Select DTR and press OK. The Connection dialog box will appear (see Fig. 7-4). The Connection window specifies the connected instrument in the communications drop-down list. If multiple units are attached, select the desired unit with its associated serial number from the drop-down list. Once the desired instrument has been selected, click OK and the DTR 8510 Control Panel and Configuration window will open ®... -
Page 31: Configuring The Dtr ® 8510
Print All Tests - Prints all the tests in the selected Object Print - Prints the selected real-time window Print Preview All Tests - Provides a preview of all tests to be printed Print Setup - Displays a Print Setup window allowing you to select a destination printer and change various printing options Exit - Closes the control panel Edit Edit - Edits the session information for the selected test in the opened *.icp file... -
Page 32: Running A Test
Date Format: Allows selection of the Date Format as MM/DD/YY or DD/MM/YY or YY/MM/DD. Time format: Allows selection of Time format as 24-hour or 12-hour format. Default Test Type: Allows selection of VT/PT or CT test. Default Test Mode: Allows selection of test for Ratio only or Cont/Ratio (Continuity and Ratio) mode. Default Storage Mode: Allows selection of storage of each Measurement Record in Manual or Automatic mode. -
Page 33: Downloading A Test
NOTE: „ If the DTR 8510 is in Autosave mode, the connection to the computer will disable the automatic saving of the Measurement ® Record. „ If the Test needs to be cancelled while testing is in progress, press the TEST button on the instrument or CANCEL button on the screen. -
Page 34: Saving The Measurement Records
7.7. SAVING THE MEASUREMENT RECORDS Select Save or Save As from the File menu. The Save As dialog box will appear: Figure 7-13 Save the file in the default location of “My Documents\DataView\DataFiles\DTR” or select a different folder to save to. 7.8. - Page 35 NOTE: „ All downloaded files and reports are saved in the default location of “My Documents” or “Documents” for each user. „ DataView and Control Panel (CP) are fully integrated programs for instrument control and data analysis/report generation. ® CP can download the Measurement Records previously stored in the DTR 8510 memory.
-
Page 36: Maintenance
8. MAINTENANCE The manufacturer cannot be held liable for any accident that occurs following a repair not performed by its cus- tomer service department or by an approved repairer. 8.1. CHARGING THE BATTERIES The DTR 8510 is supplied with an external smart charging unit. In order to charge the NiMH battery packs, the instrument switch ®... -
Page 37: Cleaning
The smart charger has the following features: „ Multiple charge detection methods -dV (typical) and dT/dt. Typically, the indication that the battery is fully charged is detected by a slight drop in its voltage (-dV). However, if the batteries are unused for a long time, they may display the same drop in voltage in the early part of the charge cycle even if they are not fully charged. -
Page 38: Metrological Check
This instrument should be checked at least once a year. For checking and calibration, contact one of our accredited metrology laboratories (information and contact details available on request), at our Chauvin Arnoux subsidiary or the branch in your country. 8.4. REPAIR... -
Page 39: Appendix: Display Messages
9. APPENDIx: DISPLAy MESSAGES Check for H<>x Cable Reversal The DTR 8510 may have detected a potentially hazardous step-up condition while attempting to test the transformer as con- ® nected. Verify connections. High Excitation Current Check test cable connections for inadvertent short circuits. Check for shorted transformer windings. Low Battery As the batteries are drained during use, the green LED will begin to flash when the battery voltage reaches a pre-determined threshold. -
Page 40: Warranty
10. WARRANTy Except as otherwise stated, our warranty is valid for twelve months starting from the date on which the equipment was sold. Extract from our General Conditions of Sale provided on request. The warranty does not apply in the following cases: „... -
Page 41: To Order
11. TO ORDER Digital Transformer Ratiometer DTR 8510 ......................P01157702 ® Delivered with a carrying bag containing : „ a power cord, „ a set of measuring cables, „ an external battery charger 90-260V, „ a battery user instruction sheet, „... - Page 42 Tel: +86 21 65 21 51 96 - Fax: +86 21 65 21 61 07 SCANDINAVIA - CA Mätsystem AB USA - Chauvin Arnoux Inc - d.b.a AEMC Instruments Box 4501 - SE 18304 TÄBY 200 Foxborough Blvd. - Foxborough - MA 02035...
