Dual Lever Triflow
• U.1470LS Kitchen Faucet
• U.1469LS Bar Faucet
FILTERED
IN
O
1/4"
3/8"
Temp Range:
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
The Country Kitchen Collection
Installation & User Guide
O
HOLE
COLD IN
1/2"
HOT IN
1/2"
3 Lever Triflow
• U.1475LS Kitchen Faucet
• U.1474LS Bar Faucet
1.3/8"
HOT IN
1/2"
O
1.3/8"
HOLE
FILTERED
IN
COLD IN
1/2"
Advertisement
Related Manuals for Rohl TRIFLOW Country Kitchen U.1470LS
Summary of Contents for Rohl TRIFLOW Country Kitchen U.1470LS
- Page 1 The Country Kitchen Collection Installation & User Guide Dual Lever Triflow 3 Lever Triflow • U.1470LS Kitchen Faucet • U.1475LS Kitchen Faucet • U.1469LS Bar Faucet • U.1474LS Bar Faucet FILTERED 1.3/8" 1/4" HOLE 3/8" 1.3/8" HOLE FILTERED HOT IN 1/2"...
- Page 2 The Country Triflow Collection Installation & User Guide Congratulations on the purchase of your Triflow Kitchen Product. Correctly installed and with sensible care, this product will give you many years of trouble free service. IMPORTANT INFORMATION The following are instructions for the 9½" kitchen faucet and 6½" bar faucet for the dual lever and 3 lever Triflow.
- Page 3 Connect the flexible hoses to the water inlets Filter Lever Volume and the filtered supply. Refer to guide supplied On/Off Control with the filter unit for installation. • U.1470LS • U.1469LS Hot/Cold Mixer 1/4" Supply Cold Supply • U.1475LS WORK SURFACE •...
- Page 4 All products supplied by ROHL carry warranties against manufacturing defects. Perrin & Rowe products carry a Limited Lifetime Warranty. ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative product) to replace those which have proven defective in materials or workmanship.
