MOOKA KJ217 Manual

Package Contents

1× Air Purifier
1× True HEPA Filter
1× User Manual

Specifications

Product	Air Purifier	Model	KJ217
Power Supply	120V 60Hz	Rated Power	32W
Dimensions	310×160×400mm	Weight	3.4kg

PRODUCT OVERVIEW

Control Panel
Housing
Filter
Particle Sensor
Filter Cover
Air Intake
Air Outlet

OPERATION GUIDE

	On/Off Button Turns the air purifier on/off.
	Check Filter Indicator Lights up when the filter should be checked. Depending on how often you use the air purifier, the indicator should turn on within 3-6 months. You may not need to replace your filter yet, but you should check it when turns on. To reset the Check Filter Indicator, press and hold button for 3 seconds. The Check Filter Indicator will turn off.
	Auto Mode Button Turns Auto Mode on/off. Auto Mode uses dust sensor inside the air purifier, to adjust the fan speed automatically based on air quality. For example, if the air quality is bad, the fan will automatically be set to high speed.
	Fan Speed Button Cycles through fan speeds: 1 (low ), 2 (medium), 3 (high).
	Timer Button Cycles through timer options: ---, 2 hours, 4 hours, 6 hours, and 8 hours. Tap the timer button to select a time, after 3 seconds of no operation, the timer starts and the time unit symbol "H" lights up. Once the timer has finished, the air purifier will turn off. Note: To turn off the timer setting, please click the timer button until the "---" mode is displayed on the screen, after 3 seconds of no operation, the timer will turn off.
	Child Lock Button When the air purifier is on, you can lock the display to prevent settings from being accidentally changed. Buttons will not respond to being tapped. Press and hold for 3 seconds to Lock / Unlock the display. Note: The child Lock Indicator will blink when any other button is tapped to indicate that Display Lock is on.
	Sleep Mode Button Turns Sleep Mode on/off. Sleep Mode operates quietly by using a fan speed lower than low speed. Sleep Mode will turn off the display after 3 seconds if no other buttons are tapped. Note: When the display is turned off, tap any button to turn the display back on. If you don't tap another button, the display will turn off again after 3 seconds.

Air Quality Indicator Chart

PM2.5 Range	Air Quality	Indicator Color
0-75	Good	Green
76-150	Moderate	Yellow
>150	Poor	Red

GETTING STARTED

Open the filter cover and remove the filter from inside the air purifier.
Remove the plastic packaging from the filter and place the filter back into the air purifier.
Replace the Filter cover by lining up the cover's feet with the matching slots on the bottom of the housing, Use your thumb to push the four positions of the filter cover into the purifier.
When using the air purifier, allow at least 15 inches / 38 cm of clearance from the front of the air purifier. Keep away from anything that would block air flow, such as curtains.

CARE & MAINTENANCE

Cleaning the Air Purifier

Unplug before cleaning.
Wipe the outside of the air purifier with a soft, dry cloth. If necessary, wipe the housing with a damp cloth, then immediately dry.
Vacuum the inside of the air purifier.
Do not clean with abrasive chemicals or flammable cleaning agents.

Cleaning the Dust Sensor
It is recommended to clean the Dust Sensor every 2 months to help maintain the efficiency of the sensor. If the Air Quality Indicator is red (indicating "Bad" air quality) more than usual, you may need to clean your dust sensor.
Note: How often you clean the dust sensor will depend on the air quality of your environment. If your air is often polluted with dust, dander, smoke, and other particles, you may need to clean your dust sensor more often.

Unplug the air purifier.
Open the filter cover.
Use a clean soft cloth to clean the sensor.

Do not use water, alcohol, gasoline, benzene and any other liquid to clean the sensor. Otherwise, it would cause damage to the sensor.

When Should I Replace the Filter?
The True HEPA / Activated Carbon Filter should be replaced every 3-6 months. You may need to replace your filter earlier or later depending on how often you use your air purifier. Using your air purifier in an environment with relatively high pollution may mean you will need to replace the filter more often, even if the Check Filter Indicator is off.
You may need to replace your filter if you notice:

The air purifier does not effectively filter certain odors anymore.
Increased noise when the air purifier is on.
Decreased airflow from the top of the air purifier.
Unusual odors.
The HEPA filter is visibly dusty or discolored after removing the filter.

To maintain the performance of your air purifier, only use official mooka filters. For more information, contact Customer Support.

Storage
If not using the air purifier for an extended period of time, wrap both the air purifier and the filter in plastic packaging and store in a dry place to avoid moisture damage.

TROUBLESHOOTING

Problem	Possible Solution
Air purifier will not turn on	Plug in the air purifier.
	Check to see if the power cord is damaged. If it is, stop using the air purifier and contact Customer Support.
	Plug the air purifier into a different outlet.
	The air purifier may be malfunctioning. Contact Customer Support.
Strange smell coming from the air purifier	Clean the filter, or replace if necessary.
	Contact Customer Support.
	Make sure not to use your air purifier in an area with high humidity or while diffusing essential oils.
Air Quality Indicator always stays green or yellow, even when the air quality is poor.	Clean the dust sensor.
	The dust sensor detects airborne particles, but it cannot detect gas. Make sure there aren't gasses polluting the air.
Air Quality Indicator always stays red	Clean the dust sensor.
Air Quality Indicator always stays red	If you're using an ultrasonic humidifier near the air purifier, the mist may affect the accuracy of the dust sensor. The dust sensor will detect the large mist particles, and the Air Quality Indicator may turn red. Avoid using an ultrasonic humidifier near the air purifier.
Airflow is significantly reduced	Make sure the filter is removed from its packaging and properly in place.
	Tap speed button to increase the fan speed.
	Leave 15 inches / 38 cm of clearance from the front of the air purifier.
	Replace the filter.
Air purifier makes an unusual noise	Make sure the filter is properly in place with plastic packaging removed.
	Make sure the air purifier is operating on a hard, flat, level surface.
	Replace the filter.
	The air purifier may be damaged, or a foreign object may be inside. Stop using the air purifier and contact Customer Support. Do not try to repair the air purifier. Contact Customer Support.
Poor air purification quality	Tap speed button to increase the fan speed.
	Make sure no objects are blocking the front, sides, or top of the air purifier.
	Make sure the filter is removed from its packaging and properly in place.
	Close doors and windows while using the air purifier.
	If the room is too larger, air purification will take longer.
	Replace the filter.

Note: If your problem is not listed, please contact Customer Support.

SAFETY INFORMATION

Do not use without removing the plastic wrap from the filter. The air purifier will not filter air and may overheat, causing a fire hazard.
Do not use your air purifier outdoors. Keep your air purifier away from water, wet or damp areas. Never place in water or liquid.
Do not use in excessively humid areas. Keep your air purifier away from heat sources.
Do not use where combustible gases, vapors, metallic dust, aerosol (spray) products, or fumes from industrial oil are present.
Do not block any air flow that is coming in/out of the air purifier.
Do not sit or place heavy objects on the air purifier.
Do not use your air purifier if it is damaged or not working correctly, or if the cord or plug is damaged.
Do not try to repair it yourself. Please contact customer support.
Keep the inside of the air purifier dry. To prevent moisture buildup, avoid placing in rooms with major temperature changes or underneath air conditioners.
Keep 5 ft/1.5 m away from where oxygen is being administered.
Supervise children when they are near the air purifier.
Always unplug your air purifier before servicing (such as changing the filter).
This appliance is not intended for used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Plug & Cord

Never place the cord near any heat source.
Do not cover the cord with a rug, carpet, or other covering. Do not place the cord under furniture or appliances.
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature.
This air purifier uses standard US 120V, 60Hz outlets. If using in a different area, check for compatibility.
