MOOKA TL2867 Manual

WHAT'S IN THE BOX?

Name	Quantity
Air Purifier	1
Filter	1
User Manual	1
Adapter	1

Specifications

Product Name	Air Purifier
Model	TL2867
Power Supply	DC24V
Rated Power	18W
Dimensions	315x105x342mm
Item Weight	2 5kg

PRODUCT OVERVIEW

Air Outlet
Control Panel
Air Inlet
Sensor Inlet
Power Adapter Input
Power Adapter

OPERATION GUIDE

Power on/off
In the off state, press the power button to start the purifier. After power on, it enters the auto mode by default, and the auto mode indicator light is on 30 seconds later the sensor starts to detect the air quality. Press the power button to select fan speed or turn off the machine.

Fan speed adjustment
When the air purifier is on, press S1 Power button to select different fan speed. In order, they are automatic mode, low speed mode, high speed mode and sleep mode

Auto mode
Short press S1 button to select the Auto mode, the purifier will automatically adjust the fan speed according to the PM2.5 concentration.

Air quality	PM2.5	Light color
Good	0-75ug/m3	Blue
Moderate	75-150ug/m3	Yellow
Bad	> 150ug/m3	Red

The fan speed level in automatic transmission is adjusted according to the air quality. The speed of the purifier in automatic mode is divided into three levels

Filter reset
The red filter indicator flashes when the filter has been used for 1500 hours, which means the stops flashing to reset the filter life counter. filter needs to be replaced.
After replacing the filter, press and hold the Power button for 3-5 seconds until the red indicator stops flashing to reset the filter life counter.

GETTING STARTED

Turn the two plastic swivel buttons of the base to the left and right respectively.
Take out the filter and remove the filter bag.
Put the filter back to the original position
Turn the two plastic swivel buttons left and right to reset. Check that it is locked before connecting to the power supply.

Note: In order to achieve the best purification effect, the four sides of the purifier need to be more than 60cm / 23.6in away from the wall

ABOUT THE FILTER

The mooka air purifier Uses a 3-stage filtration system to purify air.
ABOUT THE FILTER

Nylon Pre Filter
H13 HEPA Efficient Filter
Activated Carbon Filter

DIAGRAM OF PURIFICATION

CLEANING & MAINTENANCE

Cleaning the Air Purifier

Unplug before cleaning.
Wipe the outside of the air purifier with a soft, dry cloth. If necessary, wipe the housing with a damp cloth, then immediately dry
Vacuum the inside of the air purifier.
Do not clean with abrasive chemicals or flammable cleaning agents

Cleaning the Dust Sensor inlet
It is recommended to clean the Dust Sensor inlet every 2 months to help maintain the efficiency of the sensor. If the Air Quality indicator is red (indicating "Bad" air quality) more than usual, you may need to clean your dust sensor inlet
Note: How often you clean the dust sensor inlet will depend on the air quality of your environment. If your air is often polluted with dust, dander, smoke, and other particles, you may need to clean your dust sensor inlet more often
Cleaning the Dust Sensor inlet

Unplug the air purifier.
Clean the sensor inlet with a clean soft cloth or vacuum
Make sure the sensor inlet is not blocked

When Should I Replace the Filter?
The True HEPA Filter should be replaced every 3-6 months.
You may need to replace your filter earlier or later depending on how often you use your air purifier. Using your air purifier in an environment with relatively high pollution may mean you will need to replace the filter more often, even if the Check Filter Indicator is off.
You may need to replace your filter if you notice:

The air purifier does not effectively filter certain odors anymore
Increased noise when the air purifier is on.
Decreased airflow from the top of the air purifier.
Unusual odors
The HEPA filter is visibly dusty or discolored after removing the filter.

To maintain the performance of your air purifier, only use official mooka filters. For more information, contact Customer Support.

Storage Guide
If not using the air purifier for an extended period of time, wrap both the air purifier and the filter in plastic packaging and store in a dry place to avoid moisture damage.

TROUBLESHOOTING

Problem	Possible Solution
Air purifier will not turn on	Plug in the air purifier.
	Check to see if the power cord is damaged If it is, stop using the air purifier and contact Customer Support
	Plug the air purifier into a different outlet
	The air purifier may be malfunctioning Contact Customer Support
Strange smell coming from the air purifier	Clean the filter, or replace if necessary
	Contact Customer Support
	Make sure not to use your air purifier in an area with high humidity or while diffusing essential oils
Air Quality Indicator always stays blue or yellow, even when the air quality is poor.	Clean the dust sensor inlet.
	The dust sensor detects airborne particles, but it cannot detect gas. Make sure there aren't gasses polluting the air.
Air Quality Indicator always stays red	Clean the dust sensor inlet.
Air Quality Indicator always stays red	If you're using an ultrasonic humidifier near the air purifier, the mist may affect the accuracy of the dust sensor. The dust sensor will detect the large mist particles, and the Air Quality Indicator may turn red Avoid using an ultrasonic humidifier near the air purifier
Airflow is significantly reduced	Make sure the filter is removed from its packaging and properly in place
	Tap speed button to increase the fan speed
	Leave 23.6 inches / 60 cm of clearance from the front of the air purifier.
	Replace the filter.
Air purifier makes an unusual noise	Make sure the filter is properly in place with plastic packaging removed.
	Make sure the air purifier is operating on a hard, flat, level surface.
	Replace the filter.
	The air purifier may be damaged, or a foreign object may be inside. Stop using the air purifier and contact Customer Support. Do not try to repair the air purifier. Contact Customer Support
Poor air purification quality	Tap speed button to increase the fan speed
	Make sure no objects are blocking the front, sides, or top of the air purifier
	Make sure the filter is removed from its packaging and properly in place
	Close doors and windows while using the air purifier.
	f the room is too larger, air purification will take longer.
	Replace the filter.

Note: If your problem is not listed, please contact Customer Support

IMPORTANT SAFEGUARDS

Do not use without removing the plastic wrap from the filter. The air purifier will not filter air and may overheat, causing a fire hazard
Do not use your air purifier outdoors. Keep your air purifier away from water, wet or damp areas Never place in water or liquid
Do not use in excessively humid areas. Keep your air purifier away from heat sources
Do not use where combustible gases, vapors, metallic dust, aerosol (spray) products, or fumes from industrial oil are present.
Do not block any air flow that is coming in/out of the air purifier.
DO not sit or place heavy objects on the air purifier.
Do not use your air purifier if it is damaged or not working correctly, or if the cord or plug is damaged
Do not try to repair it yourself. Please contact customer support
Keep the inside of the air purifier dry. To prevent moisture buildup, avoid placing in rooms with major temperature changes or underneath air conditioners
Keep 5 ft/ 1.5 m away from where oxygen is being administered.
Supervise children when they are near the air purifier.
Always unplug your air purifier before servicing (such as changing the filter)
Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard

SAVE THESE INSTRUCTIONS
