- Page 1 Installation Guide Network Video Recorder...
-
Page 2: Table Of Contents
Contents Chapter 1 Appearance ——————————— 1 Front Panel ..............1 Rear Panel ...............2 Chapter 2 Installation ——————————— 4 Package Contents ..........4 Safety Precautions ..........4 Installation Tools ...........7 Hard Drive Installation ........7 Product Installation ..........10 Chapter 3 Hardware Connection —————— 12 Chapter 4 Configuration —————————— 13 Appendix FAQ ———————————————... -
Page 3: Chapter 1 Appearance
Chapter 1 Appearance Front Panel The figure is for demonstration purposes only. Your device may differ in appearance from the depicted. VIGI NVR4016H ■ 16 Channel Network Video Recorder VIGI NVR4016H VIGI NVR4032H ■ 32 Channel Network Video Recorder VIGI NVR4032H VIGI NVR4064H ■... -
Page 4: Rear Panel
■ Alarm In/Out Audio In/Out RS-232 USB 3.0 Grounding Terminal Kensington Power Socket HDMI LAN Ports VGA Security Slot VIGI NVR4016H/VIGI NVR4064H ■ Alarm In/Out Audio In/Out RS-232 eSATA Grounding Terminal Kensington Power Socket HDMI USB 3.0 LAN Ports VGA... -
Page 5: Kensington Security Slot
NVR through the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your NVR and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_... -
Page 6: Chapter 2 Installation
Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items is damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted. - Page 7 Place the device with its bottom surface downward. ■ Site Requirements ■ Temperature/Humidity 32 Channel Network Video Recorder VIGI NVR4032H Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion.
- Page 8 Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, go to https://www.tp-link.com/ support, search the model number of your product and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents:...
-
Page 9: Installation Tools
Installation Site 32 Channel Network Video Recorder VIGI NVR4032H When installing the device on a rack or a flat workbench, attach much importance to the following items: The rack or workbench is flat, stable, and sturdy enough to support the ■... - Page 10 2. Remove the fixing screws to detach the HDD bracket. 3. Match the screws on the HDD with the holes on the NVR. Up to 4 HDDs can be mounted at a time.
- Page 11 4. Install the HDD bracket back to the NVR. 5. Connect the power cables and data cables. 6. Replace the cover and fasten the screws of the NVR.
-
Page 12: Product Installation
Product Installation Desktop Installation ■ To install the device on the desktop, follow the steps: 1. Set the device on a flat surface which is strong enough to support the entire weight of the device with all fittings. 2. Remove the adhesive backing papers from the rubber feet. 3. - Page 13 3. After the brackets are attached to the device, use suitable screws (not provided) to secure the brackets to the rack, as illustrated in the following figure.
-
Page 14: Chapter 3 Hardware Connection
NVR hasn’t been initialized. You can turn it off in Event- Exception Detection-Disk Exception. For VIGI NVR4016H/VIGI NVR4064H, the HDMI2 port and the VGA port cannot ■ be connected to monitors at the same time. If attempted, only the monitor... -
Page 15: Chapter 4 Configuration
Chapter 4 Configuration NVR can add and manage cameras in batches. * Here we use TP-Link cameras as an example. For other camera brands, please refer to their User Manuals to add the cameras. 1. Connect your cameras to the same network as your NVR. - Page 16 Remotely view live video, manage NVR, and get instant alerts. 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add your NVR.
- Page 17 2. Make sure your NVR is in the same network segment as your network devices, or select Auto as the mode to configure the NVR to obtain a dynamic IP address. For more details, please refer to the NVR’s User Guide. If you have more questions, please visit https://www.tp-link.com/support/ faq/2850/.
-
Page 18: Safety Information
Safety Information This device is restricted to indoor use only. • Keep the device away from water, fire, humidity or hot environments. • Do not attempt to disassemble, repair, or modify the device. • Do not use damaged charger or USB cable to charge the device. •... -
Page 19: Eu Declaration Of Conformity
EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ UK Declaration of Conformity... - Page 20 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. To ask questions, find answers, and communicate with TP-Link users or engineers, please join TP-Link Community.
