Table of Contents

Wellbeing
Set with Straight Spout & Isolation Valves
Installation and Maintenance Instructions
WLC150WS
technical data
Working Pressure Range
Maximum Static Pressure
Maximum Working
Temperature
Inlet Connection
Flow Rate
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00458_19 Jun 2024
1300 369 273 | info@enware.com.au | enware.com.au
Leva 150mm Wall Mounted Mixing
®
Min 50 kPa
Max 500 kPa
800 kPa
85°C (Ceramic disc)
1/2" BSP
5 L/min (WELS 5 Star)
4 L/min (WELS 6 Star)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENWARE Wellbeing Leva WLC150WS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Watts ENWARE Wellbeing Leva WLC150WS

Summary of Contents for Watts ENWARE Wellbeing Leva WLC150WS

  • Page 1 Wellbeing Leva 150mm Wall Mounted Mixing ® Set with Straight Spout & Isolation Valves Installation and Maintenance Instructions WLC150WS technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Static Pressure 800 kPa Maximum Working 85°C (Ceramic disc) Temperature Inlet Connection 1/2”...
