Pinell SUPERSOUND 102W User Manual

Dab/dab+ / fm / internet radio / podcasts / bluetooth

Advertisement

Quick Links

User Manual
SUPERSOUND 102W
DAB/DAB+ / FM / Internet Radio / Podcasts / Bluetooth

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERSOUND 102W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pinell SUPERSOUND 102W

  • Page 1 User Manual SUPERSOUND 102W DAB/DAB+ / FM / Internet Radio / Podcasts / Bluetooth...
  • Page 2: Safety Instructions

    Safety instructions Please store this instruction manual for future reference. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus.
  • Page 3: Table Of Contents

    Table of Contents Safety instructions .......................... 2 Table of Contents ..........................3 Controls, connectors and display ....................5 Main controls .......................... 5 Connectors ..........................6 Getting started ..........................7 Setup Wizard .......................... 7 Other settings ........................10 Internet radio mode ........................11 Country ..........................
  • Page 4: Carton Contents

    Features This manual describes how to use the Supersound 102W, an advanced but easy-to-use SmartRadio with the following modes: Internet Radio with access to over 60,000 stations by Wi-Fi streaming ‘Listen again’ broadcasts and podcasts Podcasts from a wide range of broadcasters...
  • Page 5: Controls, Connectors And Display

    Controls, connectors and display Main controls PRESET - Long press button 1, 2 or 3+ to preset and save your favorite stations. You can save up to 20 DAB, 20 FM and 20 Internet radio / Podcasts presets. INFO - View more information about the station playing. Press again to cycle through further information.
  • Page 6: Connectors

    Connectors 10 Battery compartment 11 Headphones out 12 DC power in (5V)
  • Page 7: Getting Started

    Getting started Supersound 102W is easy to use. To play DAB or FM radio, all you need is a power source (batteries or 100-240V mains supply). For Internet radio and Podcasts, you also need a broadband Internet connection. Setup Wizard When Supersound 102W is started for the first time, start with selecting your language from the language list.
  • Page 8 Supersound 102W is compatible with all common network protocols and encryption methods, including Wi-Fi Protected Setup (WPS). To connect Supersound 102W to your network, you need a Wi-Fi wireless router, together with password key if set. Select WLAN region/country >Wi-Fi network (SSID), and then select a network from the list.
  • Page 9 When using the network wizard an additional option to Skip WPS is available. Select one and follow the prompts: • Push Button > Supersound 102W prompts you to press the connect button on the router. Then press the SELECT control. • Pin > (code number) Supersound 102W generates an 8-digit code number which you enter into the wireless router, access point.
  • Page 10: Other Settings

    ‘My EQ’ option, with custom bass, and treble settings. Network Supersound 102W remembers the last four wireless networks it has connected to, and automatically tries to connect to whichever one of them it can find. You can see the list of registered networks through MENU > System settings >...
  • Page 11: Internet Radio Mode

    Country, Most popular and Genre. Once you select a station, Supersound 102W connects directly to that station. Select Internet Radio mode Press SOURCE > turn SELECT until the display shows Internet Radio > press SELECT to select.
  • Page 12: Search

    Search You can also search through Internet broadcasts for stations with particular keywords in their title. To search, select MENU > Search. Enter a keyword by selecting characters in turn, then OK. The search entry screens are similar in operation to the Wi-Fi passphrase entry screen.
  • Page 13: Now Playing Information

    Now playing information While the stream is playing, the screen shows its name and description. If artist and track information is available, this is also shown. To view further information, press INFO. Each time you press INFO, another set of information is displayed, cycling through the following details: •...
  • Page 14: Podcasts Mode

    When you select Podcast mode, Supersound 102W contacts the Podcast portal to get a list of available podcasts. Once you select a podcast, Supersound 102W connects directly to that podcast source. Select Internet Radio mode Press SOURCE >...
  • Page 15: Dab Radio Mode

    The first time you select DAB radio mode, or if the station list is empty, Supersound 102W automatically performs a full scan to see what stations are available. You may also need to start a scan manually to update the list of stations for one of the following reasons: Available stations change from time to time.
  • Page 16: Settings

    This can be useful if you are listening to music with a high dynamic range in a noisy environment (for example, classical music while cooking). To change the DRC of the Supersound 102W, select MENU > DRC, and then DRC high, DRC low or DRC off.
  • Page 17: Fm Radio Mode

    Selecting stations To find a station, press and hold 9 or :. The frequency display starts to run as Supersound 102W scans the FM band. Now playing information While an FM station is playing, the screen shows one of the two following sets data: •...
  • Page 18: Bluetooth Mode

    (the device you are streaming from). 2. Turn on the Bluetooth on your enabled device. 3. Select Bluetooth device name “Pinell 102” when it appears on your device’s screen to initiate searching. 4. You can start to play your music files wirelessly. Adjust the volume level on your device.
  • Page 19: Sleep

    Playing screens the remaining sleep time is displayed at the bottom of the screen. To cancel a sleep time, select Sleep OFF from the sleep options using either of the above methods. Note: A sleep time is automatically cancelled if Supersound 102W is put into Standby.
  • Page 20: Software Upgrades And Factory Reset

    Fixes and/or additional features. You can either check manually, or set Supersound 102W to check periodically automatically (this is the default). If Supersound 102W detects that newer software is available, it asks if you want to go ahead with an update.
  • Page 21: Error Messages And Troubleshooting

    Error Messages and Troubleshooting Error messages Message Description Example Failed to Connect key entered, but MAC filtering enabled on router connect router rejects request Format error Cannot recognize file Received.wma, but found that format (independent of the stream wasn’t WMA when network) trying to decode Network error...
  • Page 22: Troubleshooting

    Solutions Network down Check that network is working between a computer and the router Cannot connect Router restricts Obtain the Supersound 102W MAC to network access to listed MAC address from MENU > System addresses settings > Network > View settings and add to router list.
  • Page 23: Technical Specifications

    Technical specifications: Model: Supersound 102W Type: Portable SmartRadio Speaker: 1 x 2,5" full range driver Power: 3W RMS Power Supply: 5V DC or 4x AA alkaline batteries Dimension (mm): W 175 x D 71 x H 106 mm Weight: 0,65 kg Specifications are subject to change without notice.
  • Page 24 Modino AS hereby declares that this device is in compliance with the following directives: 2014/53/EU (RED) 2011/65/EU (RoHS) * Information in this manual is subject to change without notice. Pinell is a label of Modino AS (www.modino.no) Trondheimsveien 183, 2020 Skedsmokorset, Norway (Email: Support@pinell.no)
