- Page 1 XOVV_KSE WALL MOUNT MODELS XOVV236KSE - XOVV242KSE - XOVV248KSE I worked really hard on this manual - so please read it...
- Page 3 Or simply scan here to be taken to registra- tion page. REGISTRATION HELPS YOU BY - Ensuring warranty coverage should you need service Providing ownership verification for insurance purposes Let’ s XO notify you in the event of product changes or recalls. - 3 -...
-
Page 4: Where Things Are
where things are 5 - 11 GETTING READY Safety and Precautions Planning Ductwork Install Examples Dimensions 12 - 15 THE INSTALL Mounting Height Installing Electrical Connections MAINTENANCE 16 - 18 Filters Cleaning Light Replacement OPERATING The Push Button Controls 20 - 21 PARTS &... -
Page 5: Safety First
safety first IMPORTANT SAFETY INSTRUCTIONS FOR RESIDENTIAL USE ONLY READ AND SAVE THESE INSTRUCTIONS PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING. IMPORTANT: Save these Instructions for the Local Electrical Inspectors use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference. -
Page 6: Installation Instructions
greasy spillovers that may ignite. Heat oils slowly on low or medium settings. B. Always turn hood ON when cooking with high heat. C. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter. D. Use proper pan size. Always use cookware appropriate for the size of the surface element. - Page 7 code authorities. C. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. D. Ducted fans must always be vented to the outdoors. E. This unit must be grounded. WARNING - TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. WARNING - UNDER CERTAIN CIRCUMSTANCES DOMESTIC APPLIANCES MAY BE DANGEROUS.
- Page 8 a few simple rules to plan your ductwork THIS HOOD IS DESIGNED TO USE AN 8” ROUND DUCT - IT MAY BE TRANSITIONED TO A 4” X 14” RECTANGULAR DUCT NEVER REDUCE DUCT SIZE. UNDERSIZED DUCTING SEVERELY RESTRICTS AIR FLOW AND HARMS PERFORMANCE. (Example: the area of an 8”...
- Page 9 estimating total equivalent feet in a duct CAUSING AIR TO CHANGE DIRECTION CAUSES TURBULENCE AND RESTRICTS FLOW IN A SYSTEM. IF USING FLEXIBLE METAL DUCT - INCREASE ALL MULTIPLIERS BY 50% (12 BECOMES 18 - ETC.) THIS EASY TO USE WORKSHEET IS FOR 1000 CFM OR LESS. UNDER “QTY USED”...
-
Page 10: Typical Installation Examples
typical installation examples WALL EXHAUST ROOF EXHAUST GRID EXHAUST R E C I R C U L A T I O N EXHAUST MUST BE RE- TURNED TO THE SPACE - 10 -... - Page 11 dimensions › Front of hood › Side of hood 12" 19" 24" “A” MODEL XOVV236KSE 36” XOVV242KSE Vented: Min 16” - Max 31” 42” XOVV248KSE 48” › Top of hood - 11 -...
-
Page 12: Highs And Lows
highs and lows RECOMMENDED MOUNTING HEIGHT ABOVE GAS AND ELECTRIC COOKTOPS 27” to 32” All range hoods have a recommended range of installation height over the cooking surface. It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard;... -
Page 13: Installation
installation - Before fixing the hood to the wall, proceed with the installation of the fringe H and secure it with screws O. - 13 -... - Page 14 installation - Insert screws “A” and dowels into the wall according to the measurements indicated on the drilling template, taking care not to tighten them completely (fig. X). - Position the unit on the wall by hooking it onto the screws “A” previously inserted. - Securely fasten the hood with safety screws “C”.
- Page 15 installation - Fasten bracket D to the wall so that it is aligned with the hood with screws C. - Fasten the decorative chimneys to the hood with screws G. - Slide the upper decorative chimney onto bracket D and fasten it with screws E. - 15 -...
-
Page 16: Electrical Connection
electrical connection 1. Route the power cord to the junction box. 2. Using listed conduit fittings and connectors, connect the power supply to the box and each line to the appropriate wire following this color convention: BLACK = HOT LEG WHITE = NEUTRAL GREEN/YELLOW = GROUND Polarity must be observed. -
Page 17: Maintenance
maintenance To remove the oil collector tray “H”, unscrew the three knobs “G” and pull downwards. Clean the tank and reassemble it by performing the reverse operation. - 17 -... -
Page 18: Cleaning Stainless Steel
maintenance Regular cleaning and maintenance is the key to long life and peak performance of any equipment. • The anti-grease filter is used to trap any grease particles suspended in the air, therefore is subject to saturation (the time it takes for the filter to become saturated depends on the way in which the appliance is used). -
Page 19: Led Light Replacement
maintenance continued XOPSPK6509 LED LIGHT REPLACEMENT To replace the bulbs, rotate the lamp anticlo- ckwise as shown in Figure. Replace the bulbs with new ones of the same type. - 19 -... -
Page 20: Power Boost
Your XO range hood is controlled by these electronic push buttons which illuminate when activated. BUTTON : Press the button once to switch on the light BUTTON 0: Turns both the Blower and Lights On and Off BUTTON 1: Blower motor operates on LOW speed. - Page 21 access parts & accessories RECIRCULATION KITS FILTERS REPLACEMENT LIGHTS REMOTE CONTROLS ALL OF THESE PARTS AND MORE ARE AVAILABLE, SIMPLY VISIT WWW.XOAPPLIANCE.COM and click on PARTS STORE OR CALL US AT 973-403-8900 - 21 -...
- Page 22 XO and upon proper installation and start-up in accordance with the instruction packet supplied with each XO unit. XO’s obligation under this warranty is limited to a period of two (2) years from the date of original purchase.
