POWER VISION
Installation Guide for: PV3-1621C
Model Coverage:
2020-2024 Honda Rubicon/Foreman/TRX520
PARTS LIST
1
POWER VISION
1
REFLASH HARNESS
1
USB CABLE
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
2
VELCRO
2
DYNOJET DECAL
1
E.O FRAME LABEL
98200149.04
Advertisement
Related Manuals for Dynojet POWER VISION PV3-1621C
Summary of Contents for Dynojet POWER VISION PV3-1621C
- Page 1 POWER VISION Installation Guide for: PV3-1621C Model Coverage: 2020-2024 Honda Rubicon/Foreman/TRX520 PARTS LIST POWER VISION VELCRO REFLASH HARNESS DYNOJET DECAL USB CABLE E.O FRAME LABEL PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 98200149.04...
- Page 2 INTRODUCTION Thank you for purchasing the Power Vision from Dynojet RETURN Research. At Dynojet, our mission is to make every ride the ultimate ride. The Power Vision allows you to tune SCROLL your stock ECU to achieve optimal performance from ENTER your vehicle.
- Page 3 PV3 will only display fi les which directly fi t your vehicle. Note: The Dynojet tune fi le (.djt) is a tune fi le which is different (better than stock performance or the necessary fi le when bolting on an exhaust, for example); the stock fi le (.stk) is the direct duplicate of what the OEM shipped.
- Page 4 VIEWING THE VEHICLE INFORMATION This menu allows you to view the device status (paired/not VEHICLE TOOLS paired), VIN #, Model ID, ECU serial number, tune compat, and VEHICLE INFORMATION checksum compat. DIAGNOSTICS Select Vehicle Tools>Vehicle Information. DELETE DATA LOGS VIEWING THE DIAGNOSTIC CODES This menu allows you to read and clear diagnostic trouble VEHICLE TOOLS codes.
- Page 5 CONFIGURING GAUGES Make your Power Vision device yours; display the channels you want to see with four user-customizable full-color gauge screens. Each gauge screen has one, two, or four confi gurable channels. Monitor channels such as Wideband, AFR, and Boost. Sample gauges shown here;...
- Page 6 DELETING DATA LOGS This menu allows you to delete data logs. VEHICLE TOOLS Select Vehicle Tools>Delete Data Log. DIAGNOSTICS Select a specifi c log to delete or select *Delete All Logs*. DELETE DATA LOGS RESTORE ECU VIEWING THE DEVICE INFORMATION This menu allows you to view the device fi...
- Page 7 UPDATING THE DEVICE This menu allows you to update the device with the latest fi rmware. Go to www.dynojet.com. From the top navigation menu, select Support>Downloads. Click Power Vision 3. Click the Firmware drop-down and download the Power Vision 3 Firmware for Honda.
- Page 8 Click Update to load the current fi rmware. If the Update button is grayed out, your Power Vision already has the latest fi rmware. Click Restore to reload all original Dynojet tune and stock fi les. Click Get Tunes to open the Dynojet Tune Finder. Follow the instructions to Upload your PV_Info.txt fi...
- Page 9 TRUTH TRUTH IN IN PERFORMANCE PERFORMANCE 800-992-4993 - DYNOJET.COM © 2019-2024 DYNOJET RESEARCH ALL RIGHTS RESERVED...
