POWER VISION
Installation Guide for:
PV3-1601C / PV3-1602C / PV3-1606C / PV3-1611C
PV3-1618C / PV3-1620C
Model Coverage:
2014-2023 Honda Grom
2019-2023 Honda Monkey
2019-2021 Honda Supercub
2015-2022 Honda CBR300R
2017-2019 Honda CB300F
2019-2023 Honda CB300R
PARTS LIST
1
POWER VISION
1
REFLASH HARNESS
1
USB CABLE
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
2
VELCRO
2
DYNOJET DECAL
1
E.O FRAME LABEL
98200114.12
Advertisement
Related Manuals for Dynojet POWER VISION PV3-1601C
Summary of Contents for Dynojet POWER VISION PV3-1601C
- Page 1 2014-2023 Honda Grom 2019-2023 Honda Monkey 2019-2021 Honda Supercub 2015-2022 Honda CBR300R 2017-2019 Honda CB300F 2019-2023 Honda CB300R PARTS LIST POWER VISION VELCRO REFLASH HARNESS DYNOJET DECAL USB CABLE E.O FRAME LABEL PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 98200114.12...
- Page 2 INTRODUCTION Thank you for purchasing the Power Vision from Dynojet RETURN Research. At Dynojet, our mission is to make every ride the ultimate ride. The Power Vision allows you to tune SCROLL your stock ECU to achieve optimal performance from ENTER your vehicle.
- Page 3 PV3 will only display fi les which directly fi t your vehicle. Note: The Dynojet tune fi le (.djt) is a tune fi le which is different (better than stock performance or the necessary fi le when bolting on an exhaust, for example); the stock fi le (.stk) is the direct duplicate of what the OEM shipped.
- Page 4 VIEWING THE VEHICLE INFORMATION This menu allows you to view the device status (paired/not VEHICLE TOOLS paired), VIN #, Model ID, ECU serial number, tune compat, and VEHICLE INFORMATION checksum compat. DIAGNOSTICS Select Vehicle Tools>Vehicle Information. DELETE DATA LOGS VIEWING THE DIAGNOSTIC CODES This menu allows you to read and clear diagnostic trouble VEHICLE TOOLS codes.
- Page 5 LOGGING DATA The Power Vision is a powerful logging tool to diagnose running issues. Use the Power Vision to log all vehicle operating data and review the data in the Power Core software. Troubleshoot an issue with excessive knock or a throttle blade closure by keeping the Power Vision mounted to view and record channels.
- Page 6 UPDATING THE DEVICE This menu allows you to update the device with the latest fi rmware. UPDATE DEVICE Go to www.dynojet.com. PV3_5.16.8297.41698.dfu From the top navigation menu, select Support>Downloads. Click Power Vision 3. Click the Firmware drop-down and download the Power Vision 3 Firmware for Honda.
- Page 7 Click Update to load the current fi rmware. If the Update button is grayed out, your Power Vision already has the latest fi rmware. Click Restore to reload all original Dynojet tune and stock fi les. Click Get Tunes to open the Dynojet Tune Finder. Follow the instructions to Upload your PV_Info.txt fi...
- Page 8 TRUTH TRUTH IN IN PERFORMANCE PERFORMANCE 800-992-4993 - DYNOJET.COM © 2019-2024 DYNOJET RESEARCH ALL RIGHTS RESERVED...
