- Page 1 AP - AB1228 Shanghai Anping Static Technology Co.,Ltd High Self- speed balancing Intelligent Self-Balancing Static Elimination Ion Bar A P & T...
- Page 2 Suitable for electronics, optoelectronics, semiconductor and other industries Effectively solve the problems caused by static electricity Static removal Prevent adhesion Prevent material Prevent static Prevent blockage of objects splash electricity of feeder...
-
Page 3: Product Profile
D i s c harg e s p ee d i s t wo t im e s c o mpare to traditio n a l stru c tu re ◈ Product Profile AP-AB1228 air source anti-shock pulse AC ion bar is the bar type static elimination device that is developed by shanghai anping static technology co., ltd. for eliminating the static on the surface of objects. - Page 4 Intelligent networking Multiple networking methods to monitor the working status of ion bar online communication wireless communication RS485 communication IMS monitoring software USB Cable Male to Male AP-DY6703 IMS monitoring software...
-
Page 5: Intelligent Remote Control
Intelligent Remote Control Ion balance / ion output frequency adjustable ◈ The output ratio of positive and negative ions is adjustable, which can be used to adjust the ion balance voltage. Positive high voltage Positive high voltage amplitude amplitude The negative ion output increases with the （Positive high voltage）... - Page 6 Intelligent Remote Control Ion balance/ion output frequency adjustable Button Function instructions Function Symbol Operation instructions Unlock Unlock before adjusting operating parameters. Device starts running when power is on. Press "STOP" to standby and no Run / Pause high voltage output. Press "RUN" again and the device will start working. ①...
- Page 7 Pulse AC The effect of static eliminating is better compare to power frequency AC ion bar ◈ Pulse AC VS traditional AC The pulsed AC method alternately applies "+" and "-" high voltage to one electrode needle to generate two polar ions. Compared with the AC method, the ion generation efficiency is higher.Electrostatic elmiination ability can be fully plated on matter for short or long distance.Beside,frequency adjustable so the working distanceis extended.
- Page 8 11.9 14.5 17.1 19.8 22.4 Discharge time distribution diagram of AP-AB1228 with 500mm Ion balance voltage distribution diagram of AP-AB1228 bar length at 0.3MPa air pressure with 500mm bar length at 0.3MPa air pressure Test standard：ANSI/ESD.STM3.1，SJ/T 11446—2013 Test instrument：Trek charge flat panel tester Test voltage：±1000V →...
- Page 9 Features Safe / Easy to use / Durable ▍ Electric shock proof ▍ Discharge parts replaced easily Avoid injuires from accidental human contact. Easy to replace, standard configured tungsten needle, long time ionization ability. ▍ It's convenient to replace ▍ Low balance voltage, excellent the discharge components balance reliability It can be replaced by rotating the needle...
-
Page 10: Network Monitoring
Features Safe / Easy to use / Durable ▍ Airflow acceleration structure ▍ Intelligent remote control Ion nozzle has airflow acceleration Adjust ion balance and output frequency. structure which can realize 2 times discharge speed more than traditional structure. communication wireless communication RS485... -
Page 11: Product Specifications
Product Specifications Product Appearance / Product Parameter / Product Size ◈ Product Appearance Code switch Status indicator light RJ45 power interface ∅ 8 Intake throttle valve connector Needle holder and electrode needle Grounding studs Working status indicator light Network port cable function information RJ45 interface Setting information of operating frequency coding switch... -
Page 12: Product Size
Product Specifications Product Details / Product Parameter / Product Size ◈ Product Size Unit：mm Frequency code switch Status indicator light 65 68 RJ45 interface 300,350,400...3000mm(Needle spacing 50mm) ∅ 8 Intake throttle valve connector Installation slot Grounding studs Working status indicator 304 stainless steel three-combination M5 pan head... -
Page 13: Product Parameter
Product Specifications Product Details / Product Parameter / Product Size ◈ Product Parameter Model AP-AB1228 Input voltage DC 24V Input current ＜ 600mA Power Working voltage ±4000V~±7000V Ion emission Pulse AC Emitter electrode Tungsten Discharge structure Resistance coupling Output frequency 0.1,0.5,1,5,10,30,55,65,105Hz；(EX-Work setting：55Hz) -
Page 14: Use Of The Product
Use of the product Installation Step / Installation Position / Packaging Accessories ◈ Installation Step Step one Equipment Grounding Adjustable brack Terminal Step two Grounding studs Yellow-Green Bracket installation Ground Wire Take out the ion bar, adapter power supply, power Connect one end of the yellow-green ground wire to supply network cable , stainless steel mounting brackets the grounding bolt of the ion bar and the other end to... -
Page 15: Installation Position
Use of the product Installation Step / Installation Position / Packaging Accessories ◈ Installation Position Place the ion bar in the work area where static electricity is to be eliminated and the installation angle is perpendicular to the surface of the charged body. The working frequency and installation distance can refer to the following table according to the respective electrostatic safety and process control requirements. -
Page 16: Packaging Accessories
◈ Packaging accessories Name Picture Part No. Specification Quantity Power Adapter AP2930003 GRT-240200 DC24V 2A P/N:1/2+ 5/6- Port metal PE National standard power 8YXG25110 Standard:1.8m, optional:3m/5m cord Double ended crystal 8WXI00004 Standard:2.5m, 5m/10m:optional head black shield cable Single-ended crystal head FFUTP CAT.5E 26AWG 4Pair Jacket 8WXI00002 optional... -
Page 17: Troubleshooting
Unauthorized disassembly of the product is strictly prohibited, internal maintenance and repair must be performed by professionals. The product is strictly prohibited to touch liquid during use, otherwise an abnormality may occur and cause electric shock or fire. Power must be turned off during inspecting or replacing the product, otherwise it may cause electric shock or fire. The product is ventilated with dry and clean air or nitrogen which will work abnormally or be damaged if the gas source contains water or grease. - Page 18 After-sales service AP-AB1228 intelligent self-balancing static removal ion bar has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction. AP&T makes a commitment to the customer that any defective parts inspected by AP&T will be repaired or replaced free of charge within one year from the date of purchase.
- Page 19 SPECIALITY CREATES VALUE Professional electrostatic intelligent monitoring/analysis and elimination solution provider Shanghai Anping Static Technology Co.,Ltd Tel：021-6451 7676 Website：www.ap-static.com Address：3-4/F,Building 27,No.69,Guiqing Road,Shanghai,China...
